Warnings and Safety ................................................................................................................................2
Unpacking...................................................................................................................................................2
Operation....................................................................................................................................................4
Maintenance and Troubleshooting.........................................................................................................6
1
Advertisement
Summary of Contents for AMP Kohler Series
- Page 1 Warnings and Safety ………………………………………………………………………………………………………………..2 Unpacking…………………………………………………………………………………………………………………………………2 Operation………………………………………………………………………………………………………………………………….4 Maintenance and Troubleshooting……………………………………………………………………………………………6...
- Page 2 • Electric shock: Operating equipment in wet conditions or near water can cause electric shock. • Not For Breathing Air: AMP compressors are NOT designed, intended, or approved for supplying breathing air. No compressed air should be used for breathing unless air is treated in accordance with applicable standards.
- Page 3 Compressor Pump requires 30SAE oil. Fill to middle or top of red dot in sight glass. Do not overfill or this will cause damage and oil spills. For all Engine related information please refer to separate manual provided for Kohler rh265-3124 engine. MINIMUM DISTANCE FOR CLEARANCE IS 3 FEET FOR ALL COMBUSTIBLE MATERIAL FOR OUTDOOR USE ONLY!
- Page 4 OPERATION INSTRUCTIONS UNDERSTANDING YOUR AIR COMPRESSOR • Hose and Regulator Use 3/8-inch hose and regulator that has a minimum rating that exceeds the maximum working pressure of the compressor. The amount of air pressure released at the hose outlet is controlled by the regulator. •...
- Page 5 • Gently Pull starter grip slowly until resistance is felt. • Pull cord briskly • Return starter cord gently into the recoil housing. • Move throttle choke lever to desired rpms. • Close the unloader valve You may need to pull recoil start multiple times before engine starts. Please refer to Kohler Engine manual for troubleshooting.
-
Page 6: Maintenance And Troubleshooting
Maintenance & Troubleshooting... - Page 7 • RELEASE ALLPRESSURE FROM THE SYSTEM • NEVER EVER ATTEMPT TO REPAIR OR BEFORE ATTEMPTING TO PERFORM ANY MODIFY A TANK! MAINTENANCE. •DRIVE BELT BELTS TEND TO STRETCH AS A • BEFORE EACH USE. CHECK THEAIR FILTER, RESULT OF NORMAL USE. THE BELT WILL THE OIL LEVEL, AND THE GASOLINE SUPPLY DEFLECT ABOUT 1/2 INCH WITH FIVE POUNDS BEFORE STARTING THE ENGINE.
-
Page 8: Troubleshooting
TROUBLESHOOTING For all questions call AMP at 877-601-2823 Problem Possible Cause Solution 1.) Ignition switch or On/Off switch is turned off or 1.) Turn ignition switch or on/off switch on Throttle Lever is not in correct position. 2.) Turn fuel valve on 2.) Fuel valve is turned off... - Page 9 FOR ENGINE MANUALS PLEASE VISIT KOHLERENGINES.COM Visit Americanmotorproducts.net for further information about your AKAC120 AMP Kohler Series Air Compressor. Including features and troubleshooting documents. 2013 Lamar Dr. Round Rock, TX 78664 Phone: 877-601-2823 Email: customerservice@ampgenerators.com...
