Install Generator
(This step is for rear mounts for other mounting options
see page three)
Warning Module Connections
The cable
exiting the
warning
module
with the
bare wires
goes to the
machine for
power
Note: Zip Ties included for attaching the
cables to the frame of the machine.
Making the Connection to the Generator
Connect Warning Module (Plug) to Generator (Receptacle).
(For weather shield mounts the connection is already made
inside the weather shield)
Silent Zone Adjust
•
Factory set to ≈30 in.
•
To decrease the size, unscrew the
cap from the Cab Silencer.
•
Activate a PAD and turn on truck.
•
Using a 3/32" slotted screwdriver,
turn the Pot until the PAD silences at
the desired location.
•
Replace cap.
Ensure the Silent Zone does not
extend outside of the vehicle
DDAC20040rev3.8
DDAC MFG System Installation Guide
Model #; DDAC-PDS-SYS-2
Install the Generator on top
of the overhead guard and
at least 4" from the frame.
should be as far from the
strobe light as possible.
the U-Bolts to secure the
Generator to the overhead
guard.
U-Bolt Assembly
The cable
exiting the
warning
module
with the
connector
goes to the
Generator
All adjustments in Steps 7-9 need to be done by a professional.
www.hitnot.com
Install Warning Module
Connection to generator
should be pointed up
Place adhesive side of the
It
Warning Module to the frame
Use
of the forklift (frame must be cleaned before
applying adhesive) where it can be seen and heard
by the operator.
Making the connection to machine power
Connect to a switched and fused (10A min) circuit.
DO NOT APPLY VOLTAGE TO THE INCORRECT WIRES, IT MAY
In order to avoid battery, drain while
the vehicle is off, connect Cab Silencer
to a switched and fused (5A min)
circuit.
Place the Cab Silencer within
≈30" of the Operator's PAD
away from the generator. The best
location is behind the operator's seat.
The Cab Silencer will blind the CAM if
installed on the overhead
Volume Adjust
• The clear plastic cover on the Warning Module can
be turned to reduce the sound.
• Ensure all other MFGs and PADs within 90
ft are off. Remove the Clear Pull Tab and
Power on the range adjust tool within 4ft
of MFG. The warning module will sound.
Press the Red switch to increase the
volume of the warning module and the
Black switch to decrease the volume of
the warning module.
Range Adjust Tool will NOT Work in the
Use supplied Zip ties
to secure above and
below the warning
module.
An optional Auxiliary Light ( Light Only
Warning Module) can be connected to
the Generator to provide an additional
visual alert.
RESULT IN HARDWARE DAMAGE.
Cab Silencer
AND
4ft
guard.
using Range Adjust Tool
Silent Zone.
Average
Current:0.5A
Peak Surge
Current: 15A
03/15/2022
