MYERS MTS433723NG Owner's Manual

OWNER'S MANUAL
CONTENTS:
Page 1 Specifications
2 Warning Information
3 Troubleshooting
4-5 Parts Diagram and List
Mount push handle (Part #5) to the same side
of the cart as the locking casters using the
four stove bolts, washers, and nuts provided.
Using 13mm socket completely tighten all nuts.
SERVICE CART WEIGHT CAPACITY
Total Load of Cart with
All Accessories ...............................500 LBS
Top Tray/Slide Top ...........................75 LBS
Top Surface with Slides Open .............75 LBS
Drawer Load (each) .........................75 LBS
PLEASE NOTE: Loading cart beyond rated
capacity may cause structural damage to
the cart as well as personal and /or property
damage. Please educate your customers to
the dangers of overloading. Do not attempt to
push cart with items on the top lid.
MTS433723NG
SLIDING TOP CART (NEON GREEN)
SPECIFICATIONS
Total Height ....................................43.27"
Width w/out handle/slides closed .......36.9"
Width w/handle/slides closed ............40.9"
Width w/handle/slides open ..............72.9"
Total Depth .....................................22.92"
Lockable Volume ...........................22,552"
Slides (each) ..................................90 LBS
4" Drawer Height ................................3.5"
4" Drawer Width ..................................29"
4" Drawer Depth ..................................17"
7" Drawer Height ................................6.5"
7" Drawer Width ..................................29"
7" Drawer Depth ..................................17"
1
PROFESSIONAL 5 DRAWER
CASTERS
Ground to Brace......................................6"
Caster Nominal .......................................5"
Width ..............................................1.93"
Swivel, Non-Locking ........................... 2 Qty
Swivel, Locking ................................. 2 Qty
Capacity Each ................................265 LBS
Ground Clearance ...............................5.88"
Lockable Volume ......................... 22,552"³
© Copyright 2021, Myers Tire Supply ®
MTS433723NG
Rev. 9/9/21
