Kvaser U100S-X2 User's Guide
Copyright 2020-2022 Kvaser AB, Mölndal, Sweden
https://www.kvaser.com
th
Printed Sunday 29
May, 2022
We believe that the information contained herein was accurate in all respects at the time of printing.
Kvaser AB cannot, however, assume any responsibility for errors or omissions in this text. Also note
that the information in this document is subject to change without notice and should not be construed
as a commitment by Kvaser AB.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kvaser U100S-X2
Summary of Contents for Kvaser U100S-X2
- Page 1 We believe that the information contained herein was accurate in all respects at the time of printing. Kvaser AB cannot, however, assume any responsibility for errors or omissions in this text. Also note that the information in this document is subject to change without notice and should not be construed...
- Page 2 Kvaser U100S-X2 User’s Guide 2 (24) (This page is intentionally left blank.) Kvaser AB, Mölndal, Sweden — www.kvaser.com...
-
Page 3: Table Of Contents
3.2 USB connection ......3.3 Kvaser MagiSync ...... -
Page 4: About This Manual
Kvaser U100S-X2 User’s Guide 4 (24) 1 About this manual This manual is intended for Kvaser U100S-X2 users. This document contains a description of the hardware’s properties and general instructions for connecting the device to a computer. Kvaser AB, Mölndal, Sweden — www.kvaser.com... -
Page 5: Introduction
2.1 Welcome to Kvaser U100S-X2 Figure 1: Kvaser U100S-X2 Kvaser U100S-X2 is a small, yet powerful, CAN to USB interface. It provides real-time transmission and reception of standard and extended CAN messages on the bus with a high timestamp precision, and is compatible with applications that use Kvaser’s CANlib. -
Page 6: Major Features Of Kvaser U100S-X2
Industrial grade temperature range, −40 C to +85 C. 20 000 msg/s, each timestamped with a resolution of 1 µs. Kvaser MagiSync – automatic time synchronization (see Section 3.3, Kvaser MagiSync, on Page 8 for more details). Fully compatible with applications written for other Kvaser CAN hardware with Kvaser CANlib. -
Page 7: Kvaser U100S-X2 Hardware
3.1 Hardware installation The Kvaser U100S-X2 may be inserted in any free USB socket on the host computer. You do not need to switch the power off before inserting or removing the device. For the Kvaser U100S-X2 to communicate with the host computer, a compatible version of the Kvaser driver and firmware must be installed. -
Page 8: Kvaser Magisync
Figure 3: An example setup where all devices are synchronized via MagiSync. For this to work the Kvaser USB interfaces must reside on the same USB root hub. If they do not they will not be synchronized, see Figure 3 and Figure 4 on Page 9. -
Page 9: Can Connection
3.4 CAN connection The Kvaser U100S-X2 has one CAN channel. The CAN connector for the Kvaser U100S-X2 is the 5-pole M12 plug (see Figure 5) which has the pinning described in Table 2. Figure 5: M12 5-pole CAN connector. -
Page 10: Can Bus Termination
To save yourself a lot of trouble, always terminate the CAN bus properly. 3.6 Power supply The Kvaser U100S-X2 is powered through the USB connector. Make sure the USB power source can supply enough current (500 mA). If using a USB hub, choose an externally powered one to be safe. -
Page 11: Led Indicators
11 (24) 3.7 LED Indicators A Kvaser U100S-X2 device has two traffic LED bars where part of each LED bar is also used as a status area. The TX LED Bar has a status area towards the USB end of the bar, and the RX LED bar has a status area towards the CAN end of the bar. -
Page 12: Interface Mode
Table 5: LED inidications in interface mode. The Kvaser U100S-X2 has one TX LED Bar and one RX LED Bar. Each LED Bar has a status area, the TX LED Bar has a status area towards the USB end of the bar, and the RX LED bar has a status area towards the CAN end of the bar. -
Page 13: The T Programming Language
3.9 The t programming language The Kvaser t programming language is event oriented and modelled after C. It can be used to customize the behavior of the Kvaser U100S-X2 and other Kvaser t capable devices. Kvaser AB, Mölndal, Sweden — www.kvaser.com... -
Page 14: Restrictions In T Functionality
These events can be, for example, the arrival of specific CAN messages or a timer expiration. Like any Kvaser CAN interface, the Kvaser U100S-X2 can be used via CANlib on a host computer. The addition of t programs running directly on the Kvaser U100S-X2 makes it possible to react much quicker to CAN bus events (for example to speed up file transfer protocols or to simulate missing hardware). - Page 15 Predefined t Program Related Functions filterDropMessage Predefined Logger Related Functions loggerStatus loggerStart loggerStop timeGetDate Other Predefined Functions Table 6: Functionality in the t language (v3.10) that is not supported by Kvaser U100S-X2. Kvaser AB, Mölndal, Sweden — www.kvaser.com...
-
Page 16: Updating The Firmware
To check the current firmware version, open “Kvaser Device Guide” which can be found in the Control Panel. Select “Kvaser U100S-X2” in the tree view to the left, and click on the channel. The firmware revision information now appears in the right half of the window. -
Page 17: Technical Data
Kvaser U100S-X2 User’s Guide 17 (24) 3.12 Technical data In Table 8 below you will find the technical specifications of Kvaser U100S-X2. CAN Channels CAN Connector 5-pole M12 plug CAN Transceivers ADM3055E (Compliant with ISO 11898-2) CAN Controller Built into the processor. -
Page 18: Troubleshooting
18 (24) 4 Troubleshooting Use “Kvaser Device Guide” in the Control Panel to verify that the computer can communicate with the Kvaser U100S-X2. If the firmware version shown is all zeros, there are communication problems. If the LED Bar or the status indication is not flashing or does not light up at all, check the power supply. -
Page 19: Safety Instructions
5 Safety Instructions 5.1 Intended Use Kvaser CAN Interfaces are used to connect computer systems to CAN buses. The Kvaser U100S-X2 is intended for connection to a computer via the USB interface. 5.2 Usage Warning WARNING FOR ALL USERS WARNING! - YOUR USE OF THIS DEVICE MUST BE DONE WITH CAUTION AND A FULL... -
Page 20: Disposal And Recycling Information
20 (24) 6 Disposal and Recycling Information When this product reaches its end of life, please dispose of it according to your local environmental laws and guidelines. For information about Kvaser’s recycling programs, visit: https://www.kvaser.com/en/kvaser/recycling-policy.html Kvaser AB, Mölndal, Sweden — www.kvaser.com... -
Page 21: Legal Acknowledgements
EN 55032 (2015 + A11:2020) EN 55035 (2017 + A11:2020) EN IEC 63000 (2018) Signed for and on behalf of: 2022-04-01 M¨ o lndal Place of issue Date of issue Claes Haglund, Supply Chain and Quality director Kvaser AB, Mölndal, Sweden — www.kvaser.com... -
Page 22: Fcc Regulatory Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. RESPONSIBLE PARTY (IN USA) NAME: Kvaser Inc. 23881 Via Fabricante, Suite 503 Mission Viejo, CA 92691 Internet contact: support@kvaser.com Kvaser AB, Mölndal, Sweden — www.kvaser.com... -
Page 23: Patents, Copyrights And Trademarks
MagiSync is a trademark of Kvaser AB. DeviceNet is a trademark of Open DeviceNet Vendor Association, Inc. NMEA 2000 is the registered trademark of the National Marine Electronics Association, Inc. For information about Kvaser related CAN patents, see www.kvaser.com/patent. Kvaser AB, Mölndal, Sweden — www.kvaser.com... -
Page 24: Document Revision History
8 Document Revision History Version history for document UG_98241_U100S-X2: Revision Date Changes 2021-09-07 Initial version 2022-01-24 Added connector types to Technical Data section, updated EU Declaration of Conformity. 2022-04-01 Minor textual changes, updated EU Declaration of Conformity. Kvaser AB, Mölndal, Sweden — www.kvaser.com...
