Haier AS072AZNBA Operation Manual

Split type room air conditioner
Hide thumbs

Advertisement

AS072AZNBA
AU072ABNCA
(HSU-07CG03/R1)
AS092AMNBA
AU092ABNCA
(HSU-09CG03/R1)
AS122AYNBA
AU122ABNCA
(HSU-12CG03/R1)
AS162ATNBA
AU162AFNBA
(HSU-16CG03/R1)
AS182ASNBA
AU182AFNDA
(HSU-18CG03/R1)
AS222AJNBA
AU222AHNBA
(HSU-22CG03/R1)
Please read this operation manual before using the air conditioner.
No.0010544375

Advertisement

loading

  Related Manuals for Haier AS072AZNBA

  Summary of Contents for Haier AS072AZNBA

  • Page 1 AS072AZNBA AU072ABNCA (HSU-07CG03/R1) AS092AMNBA AU092ABNCA (HSU-09CG03/R1) AS122AYNBA AU122ABNCA (HSU-12CG03/R1) AS162ATNBA AU162AFNBA (HSU-16CG03/R1) AS182ASNBA AU182AFNDA (HSU-18CG03/R1) AS222AJNBA AU222AHNBA (HSU-22CG03/R1) Please read this operation manual before using the air conditioner. No.0010544375...
  • Page 2: Table Of Contents

    Contents Cautions Parts and functions Operation Maintenance Trouble shooting 6-13 14-16...
  • Page 3: Cautions

    Cautions The cardboard box may be broken or cut into...
  • Page 4 07,09,12 16,18 Series Type 3G1.5mm +2x0.75mm 3G2.5mm +3x0.75mm 4G1.5mm...
  • Page 5: Parts And Functions

    Inlet grille Air filter Vertical flap Use remote controller to adjust up and down air flow. (Don't adjust it manually.) For models: AS072AZNBA (HSU-07CG03/R1) Inlet grille Air filter Vertical flap Use remote controller to adjust up and down air flow.
  • Page 7: Parts And Functions

    Parts and Functions Operation TEMP SWING MODE CLOCK TIMER RESET CODE 25. SET Used to confirm timer and clock settings 26. HOUR Used to set clock and timer settings 27. LOCK Used to lock buttons and LCD display NOTE:(1)The following functions and related displays are not available :HEALTH display,AUXILIARY HEAT display,POWER/SOFT display. (2)If the Air condition don't have the function,press code B can cause it not available.
  • Page 8: Operation

    Operation Remote controller's operation When in use, put the signal transmission head directly to the receiver hole on the indoor unit. The distance between the signal transmission head and the receiver hole should be within 7m without any obstacle as well. Don't throw the controller, prevent it from being damaged.
  • Page 9 SWING TEMP MODE SLEEP CLOCK TIMER LOCK RESET CODE...
  • Page 10: Cool And Dry Operation

    Operation COOL and DRY operation Recommendations: Use COOL in summer. Use DRY in spring, autumn and in damp climate. (1) Unit start Press ON/OFF button, unit starts. Previous operation status appears on display. (Not Timer setting) Power indicator on indoor unit lights up. (2) Select operation mode Press MODE button.
  • Page 11 Operation (5) Air flow direction adjustment After operation mode is selected, vertical flap will open automatically according to the mode. Referring to the Fig. COOL Level About 10 Up and down (Use remote controller) Press SWING button, vertical flap will move within the range shown in the Fig.
  • Page 12: Timer Operation

    Operation TIMER operation Set Clock correctly before starting Timer operation(referring to page 5) You can let unit start or stop automatically at following times: Before you wake up in the morning, or get back from outside or after you fall asleep at night. TIMER ON/OFF (1)After unit start, select your desired operation mode.
  • Page 13 Operation TIMER ON-OFF (1)After unit start, select your desired operation mode Operation mode will be displayed on LCD. Power indicator on indoor unit lights up. (2) Press TIMER button to change TIMER mode. Every time the button is pressed, display changes as follows: TIMER ON TIMER OFF Select TIMER ON-OFF.
  • Page 14 Operation Comfortable SLEEP Before going to bed at night, you can simply press the SLEEP button and unit will bring you a sound sleep in selected mode. In COOL ,DRY mode One hour after SLEEP mode starts, temp. will become 1 C higher than temp.
  • Page 15 More than 23 CONTINUOUS If an air conditioner is a model cooling . Cooling when the room temperature at the start of operation is above 23 Test operation: Use this switch in the test operation when the room temperature is less 16 C, do not use it in the normal operation.
  • Page 16: Maintenance

    Maintenance Different models have different appearance. Cleaning of unit casing Cleaning of remote controller Cleaning of air filter 1.Open inlet grille by pulling it upward. 3.Clean the filter Use a vacuum cleaner to remove dust, or wash the filter with water. After washing, dry the filter completely in the shade.
  • Page 17 Maintenance Replacement of Electrostatic Filter Detach the Air filters. Detach the Electrostatic Filters. Be careful with fins. Replace the old filter with new one into the frame. Open the frame of the filter. Attach the Electrostatic Filters. Attach the Air Filters. Close the inlet grille.
  • Page 18 Maintenance Better use of air conditioner Proper room temperature. Closing of doors and windows during operation. Never fail to observe the followings Do not sprinkle water over the unit.. Do not pull power plug. Cleaning of the air filter. Proper temperature Effective use of the timer.
  • Page 19: Trouble Shooting

    When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
