Enlite EN-BN1240EM Manual

BACK ENTRY
1
WIRING
6
SIDE ENTRY
1
WIRING
6 7
EN-BN1240EM, EN-BN1240EMR, EN-BN1545EM & EN-BN1545EMR
e
Class I
2 2
1
2
Press down on diffuser at
one end and pull edge of the
diffuser upwards to unclip
7
Brown – (PL) Permanent Live,
Blue – (N) Neutral,
Brown –(SL) Switch Live
e
Green/Yellow – Earth.
2 2
1
2
Press down on diffuser at
one end and pull edge of the
diffuser upwards to unclip
8
Brown – (PL) Permanent Live,
Blue – (N) Neutral,
Brown –(SL) Switch Live
Green/Yellow – e Earth.
3 4
8
3 4
9
Knockout.
(For side cable entry a
20mm gland is required)
5
1
2
9 10
Test Button and
Emergency Test Light
5
1
2
10
Test Button and
Emergency Test Light
