MICRO-POWER SMC-HF 3200 User Manual page 16

Symbol indication in SMC-HF 8000
○ ●
Off On
Red Yellow Green Blue
○ ○ ○
○ ○ ○
○ ○ ○
○ ○ ●
○ ○
☼
○ ● ○
○ ● ●
○ ○
☼
● ○ ○
● ○ ●
● ○
☼
● ● ●
● ●
☼
● ●
☼
●
☼ ☼
○ ●
☼
● ○
☼
○
☼ ☼
☼ ☼ ☼
16
☼
Flashing
Indication
○
Not connected to mains power supply
●
Connected to mains power supply. Waiting for battery.
☼
Option. Connected to mains power supply. Remote start off.
No battery connected.
○
Charging complete. Maintenance charging.
○
Pause. Battery connected.
○
Main charging
○
Additional charging
☼
Option. Remote start off. Battery connected.
○
Charging fault, non-specific.
○
Time limit exceeded. Charging interrupted.
○
High battery voltage. Charging interrupted.
○
Phase error. Charging interrupted.
○
High charger temperature. Reduced charging current.
○
Very low battery voltage.
Lower than 1.5V/c. Charging interrupted.
○
Option. Low battery voltage. Low current phase.
○
Low charging temperature or sensor fault. Charging interrupted.
○
Maximum number of recharged Ah exceeded.
Charging interrupted.
○
Regulating fault. Charging interrupted.
○
No charging curve selected.
