Torex VDC Series Manual

Double dump valve
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
VDC
Double dump valve

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VDC Series and is the answer not in the manual?

Questions and answers

Related Manuals for Torex VDC Series

Summary of Contents for Torex VDC Series

  • Page 1 Double dump valve...
  • Page 2 Certified Company All the products described in this catalogue have been manufactured according to the operating methods defined by the TOREX S.p.A. Quality System The Company's Quality System, certified in July 2004 in conformity with international standards ISO 9001:2000 is capable of ensuring that the entire production process, from formulation of the order to technical assistance after delivery, is done in an appropriate controlled manner to ensure the quality standard of the product.

  • Page 3: Table Of Contents

    Sommario TECHNICAL CATALOGUE 1. INTRODUCTION ......................2 Type ..........................2 Description ........................2 Application sector ......................2 Contraindications ......................2 Operating temperatures ....................2 2. GENERAL LAYOUT ....................3 General layout of VDC with counterweight ............... 3 General layout of motor-operated VDC ................4 General layout of pneumatic VDC ..................
  • Page 4 TO320 - EN - Ed. 04.09 OPERATION AND MAINTENANCE 1. INTRODUCTION ......................2 Type ..........................2 Description ........................2 Application sector ......................2 Contraindications ......................2 Operating temperatures ....................2 2. SCOPE AND IMPORTANCE OF THE MANUAL ............3 3. WARRANTY CONDITIONS ..................3 4.
  • Page 5 12.2 Motor-operated VDC ...................... 20 12.3 Pneumatic VDC ......................21 12.4 Valve body ........................23 12.5 Motor-operated VDC ...................... 24 12.6 Pneumatic VDC ......................27 12.7 Valve body ........................33 12.8 Maintenance ........................35 13. CLEANING ........................ 36 14. NOISE ........................37 15.
  • Page 6 TO320 - EN - Ed. 04.09 3. PLATE 3 - DRIVE UNIT .................... 12 VDC 200 ......................... 13 VDC 250 ......................... 14 VDC 315 ......................... 15 VDC 400 ......................... 16 VDC 500 ......................... 17 Spares Kit Tables......................18 4. PLATE 4 - PNEUMATICS ..................19 VDC 200 .........................

  • Page 7: Technical Catalogue

    Double dump valve TECHNICAL CATALOGUE...

  • Page 8: Introduction

    TO320 T - EN - Ed. 04.09 INTRODUCTION Type Description Double dump valve Application sector The double dump valves are ideal for controlled unloading of powder or granular materials; they are mostly suitable for de-dusting and for heavy-duty applications in all industrial sectors. Designed for operating require- ments such as: high temperatures, highly abrasive materials and /or materials with large grain size.

  • Page 9: General Layout

    1 - Technical Catalogue GENERAL LAYOUT General layout of VDC with counterweight In VDC with counterweight, the opening of the plate depends on the weight of the material. The force of the material on the plate must overcome the force exerted by the weight on the lever. The working is not regular over time.

  • Page 10: General Layout Of Motor-Operated Vdc

    TO320 T - EN - Ed. 04.09 General layout of motor-operated VDC The activation of the closure plates is brought about by means of the gear motor, and they are opened by means of a spring. This system (as compared to the gravity system) makes it possible to maintain regular operation also with variable product loads.

  • Page 11: General Layout Of Pneumatic Vdc

    1 - Technical Catalogue General layout of pneumatic VDC The opening and closure of the plates is brought about by means of cylinders. The opening/closure duration can be preset according to one's requirements. Like the motor-operated VDC, it is possible to maintain regular operation also with variable product loads.

  • Page 12: Technical Data

    TO320 T - EN - Ed. 04.09 TECHNICAL DATA Ambient Process Differential Wt. of VDC Wt. of mo- Wt. of Maximum Type Temp. Temp. pressure with counter- tor-operated pneumatic pc. size (°C) (°C) (bar) weight (kg) VDC (kg) VDC (kg) (Ø...
  • Page 13 1 - Technical Catalogue VDC with gear motor or pneumatic drive, 600 cycles/h Volumetric capacity 35000 30000 25000 VDC200 VDC250 20000 VDC315 VDC400 15000 VDC500 10000 5000 FILLING COEFFICIENT The filling coefficient varies according to the flowability of material, the preset flow rate and the type of conveyor upline of the VDC.

  • Page 14: Solenoid Valves Technical Data (Vdc With Pneumatic Drive)

    TO320 T - EN - Ed. 04.09 Solenoid valves technical data (VDC with pneumatic drive) Type: ....................5/2 monostable with spring return Protection degree: ........................IP65 Operating pressure: ......................2.5 - 8 bar Nominal flow rate: ....................620 NI/min (6bar) Connections: ........................1/8” ISO228 Operating environment temperature: ................-10°C +50°C Operating fluid temperature: .....................5°C + 50°C Solenoid valves supply voltage and power: ..............24V AC (8VA) Solenoid valves diagram...

  • Page 15: Code Key

    1 - Technical Catalogue Code key 0 Seals with Teflon-coated packing gland 1 Fe flap 2 AISI 304 flap 3 AISI 316 flap 4 Fe flap covered with wear-proof rubber 5 HARDOX flap 1Hopper made of carbon steel 2 Hopper made of AISI 304 2 Hopper made of AISI 316 4 Hopper made of Fe covered with wear-proof rubber...

  • Page 16: Finish

    TO320 T - EN - Ed. 04.09 Finish STANDARD Finish Paint INTERNAL Powder paint 80 µm EXTERNAL Powder paint 80 µm ShAdE none Caterpillar yellow* RAL 1013 pearl white RAL 1015 light ivory RAL 5010 gentian blue* RAL 5015 sky blue RAL 6011 reseda green RAL 7035...

  • Page 17: Shade

    1 - Technical Catalogue Shade “ENVIRONMENT-FRIENDLY” RAL SHADES WITHOUT CHROMIUM AND LEAD 1000 1001 1002 1011 1014 1019 3005 3007 3009 3027 4001 4004 4005 4006 4007 4008 5000 5001 5002 5003 5004 5005 5507 5008 5009 5011 5012 5013 5014 5017 6000 6003 6004 6006 6012 6013 6015 6016 6019 6020 6021 6022 6025 6026 6027 6028 6033 6034 6034 7000 7002 7003 7004 7005 7006 7007 7008 7009 7010 7011 7012 7013 7015 7016 7021 7022 7023 7023 7024 7025 7026 7030 7031 7033 7034 7036 7037 7038 7039 7040 7042 7043 7044...

  • Page 18: Dimensions

    TO320 T - EN - Ed. 04.09 DIMENSIONS Double dump valve - with counterweight B1 B2 Type 315 157,5 157,5 315 157,5 157,5 410 375 187,5 187,5 375 187,5 187,5 440 545 272,5 272,5 545 272,5 272,5 615 630 1074 655 327,5 327,5 720 915 400 515 1098 328 770 1224 655 327,5 327,5 1 - Technical Catalogue...

  • Page 19: Motor-Operated Double Dump Valve

    1 - Technical Catalogue Motor-operated double dump valve B1 B2 Type 315 157,5 157,5 315 157,5 157,5 410 600 215,5 384,5 720 375 187,5 187,5 375 187,5 187,5 440 600 215,5 384,5 720 857 293,5 563,5 665 545 272,5 272,5 545 272,5 272,5 615 1018 1074 655 327,5 327,5 655 327,5 327,5 720 1116 1224...

  • Page 20: Pneumatic Double Dump Valve

    TO320 T - EN - Ed. 04.09 Pneumatic double dump valve B1 B2 Type 315 157,5 157,5 315 157,5 157,5 410 375 187,5 187,5 375 187,5 187,5 440 545 272,5 272,5 545 272,5 272,5 615 1148 540 1074 655 327,5 327,5 655 327,5 327,5 720 1246 846 1063 408 655 1224...

  • Page 21: Flanges

    1 - Technical Catalogue Flanges VDC400 VDC500 VDC200 VDC250 VDC315 Type N° E 46,6 93,3 12,5 12,5 64,1 128,3 12,5 The VDC can be coupled with the following WAM holes. WAM holes couplings Machine Q200 Q250 Q300 Q400 Q500 TO320 T - EN - Ed. 04.09...

  • Page 22: Accessories

    TO320 T - EN - Ed. 04.09 ACCESSORIES Rotation indicator A rotation indicator kit based on a capacitive sensor is available for checking the opening of the VDC flap. Rotation indicator parts Guard Blade Indicator fixing plate Capacitive sensor Sensor protection Dimensions Type 200-250-315...

  • Page 23: Order Form

    ORDER FORM Modulo d’ordine DITTA ORDINE CODICE MACCHINA DATA Tipo materiale Prodotto Pezzatura materiale Peso specifico Umidit Temperatura materiale Caratteristiche materiale Scorrevole Adesivo Igroscopico Abrasivo Esplosivo Infiammabile Luogo utilizzo Interno Esterno Tipo installazione Filtro Coclea Tramoggia Altro Grandezza valvola VDC200 VDC 250 VDC315 VDC400...

  • Page 25: Operation And Maintenance

    Double dump valve OPERATION AND MAINTENANCE...

  • Page 26: Introduction

    TO320 M - EN - Ed. 04.09 INTRODUCTION Type Description Double dump valve Application sector The double dump valves are ideal for controlled unloading of powder or granular materials; they are mostly suitable for de-dusting and for heavy-duty applications in all industrial sectors. Designed for operating require- ments such as: high temperatures, highly abrasive materials and /or materials with large grain size.

  • Page 27: Scope And Importance Of The Manual

    VDC, the workers concerned must have read this Manual carefully. If the Manual is lost, damaged or becomes illegible, download a copy from the TOREX® website and check the date of the latest version.

  • Page 28: Warnings

    TO320 M - EN - Ed. 04.09 WARNINGS The manufacturer shall not accept responsibility for safety of persons or objects and failure in the working of the product if the operations involved in loading/unloading from trucks, transport, position- ing at the site, use, repairs, maintenance, etc. are not carried out in compliance with the warnings described in this Manual.
  • Page 29 2 - Operation and maintenance IT IS FORBIDDEN • to use the machine without the protection and safety devices listed in the Manual • to use the machine if there are considerable operating anomalies (excessive noise - vibrations - etc.) •...
  • Page 30 TO320 M - EN - Ed. 04.09 • Use of the equipment, even partial, by personnel not expressly authorized by the Company man- agement is forbidden. • The workshop manager and foreman are responsible for training and ensuring training of the per- sonnel who will be using the equiment.

  • Page 31: Packing

    2 - Operation and maintenance PACKING The double dump valve is usually delivered on a suitable-sized pallet and fixed to it by means of bolts to prevent sudden movements and imbalance. The double dump valve is covered with heat-shrink wrapping for protection during transport. Depending on the dimensions of the pallet and the double dump valve, more than one machine can be packed on the same pallet.

  • Page 32: Unloading And Handling

    TO320 M - EN - Ed. 04.09 UNLOADING AND HANDLING On receiving the goods, check to make sure the type and quantity correspond to the data in the order confirmation. Damage, if any, must be immediately communicated in writing in the space provided for the purpose in the waybill.

  • Page 33: Weights

    2 - Operation and maintenance Weights Counterweight Type Weight (kg) Motor-operated Type Weight (kg) Pneumatic Type Weight (kg) TO320 M - EN - Ed. 04.09...

  • Page 34: Storage

    TO320 M - EN - Ed. 04.09 STORAGE Storage prior to installation • To store the machine correctly for long shutdowns, fill the gear motor completely with oil, if present, clean the inside parts of the machine thoroughly; • Avoid damp, salty environments as far as possible; •...

  • Page 35: Operating Diagram

    2 - Operation and maintenance OPERATING DIAGRAM Flaps opening sequence Phase 1 Phase 2 Direction of gear motor crank rotation Direction of rotation anticlockwise TO320 M - EN - Ed. 04.09...

  • Page 36: Installation

    TO320 M - EN - Ed. 04.09 INSTALLATION 10.1 Mechanical connections Before carrying out any operation on the machine, make sure it is in safety condition! The machine is delivered completely assembled, and only needs to be installed and bolted firmly to the valve inlet flange and (if envisaged for the plant) also to the outlet flange.

  • Page 37: Pneumatic Connections (Vdc With Pneumatic Drive)

    2 - Operation and maintenance 10.2 Pneumatic connections (VDC with pneumatic drive) 10.2.1 Compressed air requisites The compressed air which must enable the various utilities must have certain features: • Clean: free of impurities • Dehumidified: it is, however, advisable to provide for a condensate separator; •...

  • Page 38: Electrical Connections

    TO320 M - EN - Ed. 04.09 10.3 Electrical connections Before carrying out any operation on the machine, make sure it is in safety condition! The connection between the valve electric motor and mains must always be done by specialist per- sonnel.
  • Page 39 2 - Operation and maintenance Junction box layout DESCRIPTION OF CONNECTIONS SOLENOID VALVE COMMON WIRE SOLENOID VALVE COMMON WIRE UPPER CYL. SOLENOID VALVE LOWER CYL. SOLENOID VALVE PRESSURE SWITCH OPEN FLAP UPP. CYL. LIMIT SWITCH CLOSED FLAP UPP. CYL. LIMIT SWITCH OPEN FLAP LOW.
  • Page 40 TO320 M - EN - Ed. 04.09 Wiring diagram THREE-PHASE MOTORS The windings of the standard motors can be connected in two ways: • star connection (Fig. 1) • delta connection (Fig. 2) STAR CONNECTION The star connection is obtained by connecting together terminals W2, U2, V2 and powering terminals U1, V1, W1.

  • Page 41: Switching On Procedure

    2 - Operation and maintenance SWITCHING ON PROCEDURE Before carrying out any operation on the machine, make sure it is in safety condition! Before starting up the machine, make sure the installation and connections to the external power supplies have been carried out completely and correctly according to the methods described below in brief: 1.
  • Page 42 In the pneumatic VDC the work sequence is preset by the user to control the opening/closing times of both flaps. Torex recommends a 10 cycles/minute work sequence. The user must make the solenoid valve connections in the terminal board present onboard the ma- chine.

  • Page 43: Maintenance

    2 - Operation and maintenance MAINTENANCE Before carrying out any operation on the machine, make sure it is in safety condition! IT IS HAZARDOUS TO WORK WITH THE LIMBS INSIDE THE VDC; THEREFORE IT IS NECES- SARY TO DISCONNECT THE ELECTRICITY SUPPLY FROM THE MAIN SWITCH PROVIDED WITH SAFETY KEY AGAINST ACCIDENTAL START-UP THE KEY MUST BE KEPT IN THE CUSTODY OF THE PERSON IN CHARGE OF THE OPERA- TION...
  • Page 44 TO320 M - EN - Ed. 04.09 12.2 Motor-operated VDC 12.2.1 Disassembly order 1. Disconnect all the electric supply connections; 2. Remove screw (33) and washers (32-31) which fix guard (30) to drive unit support (20); 3. Slacken screws (26) which fix the reduction gear flange to drive unit support (20) and remove the gear motor-motor (25-24) together with crank (14);...
  • Page 45 2 - Operation and maintenance 12.3 Pneumatic VDC 12.3.1 Disassembly order 12.3.1.1 Guard disassembly 1. Disconnect all the electrical and pneumatic sup- ply connections; 2. Remove screw (23) and washers (22-21) which fix the pneumatic control unit (25) and guard (24) to drive unit support (16);...
  • Page 46 TO320 M - EN - Ed. 04.09 12.3.1.3 Disassembling the cylinders Part. B Solo per VDC400-500 Part. B 1. Slacken screws (13) and fix cylinder (7) to the posterior hinge (12), remove the seeger rings present on hinge (12) and remove the hinge from the cylinder; 2.
  • Page 47 2 - Operation and maintenance 12.4 Valve body 12.4.1 Separating the bodies 1. Slacken screws (28) and remove washers (29-30) which fix the body by means of nuts (31); 2. Separate the two valve bodies. 12.4.2 Disassembling the body 8 9 1013 14 11 12 15 16 17 1.

  • Page 48: Motor-Operated Vdc

    TO320 M - EN - Ed. 04.09 12.5 Motor-operated VDC 12.5.1 Levers assembly order 1. Fit lever (1) on the shaft of the VDC ensuring that the key present on the shaft is centred in relation to the lever; 2. Fit grub screw (10) on the lever; 3.
  • Page 49 2 - Operation and maintenance 12.5.3 Drive unit assembly order 22 21 1. Fit bearing (12) and washer (13) on pin (11); 2. Screw pin (11) on crank (14) and insert the key in the crank seat; 3. Insert crank (14) in the hollow shaft of reduction gear (24); 4.
  • Page 50 TO320 M - EN - Ed. 04.09 6. Check to ensure alignment between bearing (14) and the two levers for opening the flaps (See drawing below). If the two levers are not aligned with the bearing, slacken the grub screws for fixing the levers (see point 2 motor-operated VDC levers assembly), align the levers to the bearings of the crank and fit the fixing grub screws.

  • Page 51: Pneumatic Vdc

    2 - Operation and maintenance 12.6 Pneumatic VDC 12.6.1 Levers assembly order 1. Insert lever (1) in the double dump valve shaft, checking to make sure the key is centred with respect to the lever; 2. Fit grub screw (2) on lever (1) to lock it; 3.
  • Page 52 TO320 M - EN - Ed. 04.09 12.6.2 Cylinders assembly order 1. Take cylinder (7) and screw the swivel joint (5) on the head of the cylinder rod; 2. Take limit switch (8), position it near the maximum and minimum extension of the rod, lock it by means of the fixing screws meant for the purpose;...
  • Page 53 2 - Operation and maintenance 12.6.3 Order for mounting the cylinders on the body 1. Position the rear support (15) on the holes present on the drive unit plate (16); 2. Fit screws (14) on drive unit plate (16) for fixing the rear cylinder support (15) 3.
  • Page 54 TO320 M - EN - Ed. 04.09 12.6.4 Pneumatic connections Take the pneumatic control unit and make the connections by means of a Ø8mm tube as shown in the diagram above. Input No.8 is the power supply for the pneumatic control panel. A 5 bar input pressure is recom- mended.
  • Page 55 2 - Operation and maintenance 12.6.5 Electrical connections Before carrying out any operation on the machine, make sure it is in safety condition! The wiring diagram for connecting the VDC utilities is shown below. DESCRIPTION OF CONNECTIONS SOLENOID VALVE COMMON WIRE SOLENOID VALVE COMMON WIRE UPPER CYL.
  • Page 56 TO320 M - EN - Ed. 04.09 12.6.6 Guard closure 1. Position guard (24) near the drive unit plate; Take care to avoid pressing or bending the tubes which connect the cylinders to the pneumatic control panel!!! 2. Fix the guard to the drive unit support by means of screws (23) and the respective washers (21- 22);...

  • Page 57: Valve Body

    2 - Operation and maintenance 12.7 Valve body 12.7.1 Assembling the body 8 9 1013 14 11 12 15 16 17 1. Insert the packing gland rings (8) on both sides of the valve body (1); 2. Insert the packing gland rings (9), positioning these to fit flush with the packing rings (8); 3.
  • Page 58 SHELL TIVELA OIL SC320 ESSO S220 MOBIL GLYGOYLE 30 CASTROL ALPHASYN PG320 BP ENERGOIL SG-XP320 NOTE: The TOREX valves can be equipped with different reduction gears while at the same time keeping the valve efficiency unchanged. 2 - Operation and maintenance...

  • Page 59: Maintenance

    2 - Operation and maintenance 12.8 Maintenance Before carrying out any operation on the machine, make sure it is in safety condition! 12.8.1 Daily maintenance -At the end of the day's work, empty the valve; -Check daily for signs of overheating, vibrations and abnormal noise 12.8.2 Weekly maintenance -Check the gear motor oil level;...

  • Page 60: Cleaning

    TO320 M - EN - Ed. 04.09 CLEANING Before carrying out any operation on the machine, make sure it is in safety condition!. While removing the dust present on the machine take care to avoid spreading it in the sur- rounding atmosphere.

  • Page 61: Noise

    2 - Operation and maintenance NOISE The noise level depends on various factors such as dimensions, kind of material and filling coef- ficient. The noise emitted by the VDC is howeverwithin 80 dB(A), the value measured at a distance of 1 m, in the most unfavourable position.

  • Page 62: Possible Problems

    TO320 M - EN - Ed. 04.09 POSSIbLE PRObLEMS Minor problems can be solved without consulting a specialist. A list of the most common problems with the possible causes and remedies is given below. PROBLEM SOLUTION • Check to make sure the switch setting is cor- rect;...

  • Page 63: Check-List In Case Of Fault

    2 - Operation and maintenance CHECK-LIST IN CASE OF FAULT 1) General questions Description of problem a) Does the VDC start up without problems after long shutdowns? b) Do the atmospheric conditions seem to contribute to the problem? 2) Checking the electrical part a) Are supply current variations possible because a number of machines are started up at the same time? b) Is the plant equipped with a current generator?

  • Page 64: Residual Risks

    TO320 M - EN - Ed. 04.09 RESIDUAL RISKS Although certain risks have been eliminated at the origin in the VDC design and construction phase, certain residual risks still persist for which warning signs and instructions are required for the opera- tors and special measures have to be adopted in the use of the machine.

  • Page 65: Noise, Vibrations

    2 - Operation and maintenance It is therefore the installer’s responsibility to place warning notices which (if the hazard exists) indi- cate the hazard due to the presence of very hot surfaces and the obligation for the operator to use personal protection devices, such as safety gloves.

  • Page 67: Spare Parts Catalogue

    Double dump valve SPARE PARTS CATALOGUE...

  • Page 68: Plate 1 - Body

    TO320 R - EN - Ed. 04.09 PLATE 1 - BODY 3 - Spare Parts Catalogue...

  • Page 69: Vdc 200

    3 - Spare Parts Catalogue VDC 200 Pos. Quantity Description Code Body High temp. gasket Hopper See Table 1 M10x30 ISO10462 TPSEI Screw Ø10 DIN 7980 Split washer M10 ISO 4032 Nut Shaft Packing gland Stuffing box M10x45 ISO 4017 HH Screw Spring retainer plate “UCF 206”...

  • Page 70: Vdc 250

    TO320 R - EN - Ed. 04.09 VDC 250 Pos. Quantity Description Code Body High temp. gasket Hopper See Table 1 M10x30 ISO10462 TPSEI Screw Ø10 DIN 7980 Split washer M10 ISO 4032 Nut Shaft Packing gland Stuffing box M10x45 ISO 4017 HH Screw Spring retainer plate “UCF 206”...

  • Page 71: Vdc 315

    3 - Spare Parts Catalogue VDC 315 Pos. Quantity Description Code Body High temp. gasket Hopper See Table 1 M10x30 ISO10462 TPSEI Screw Ø10 DIN 7980 Washer M10 ISO 4032 Nut Shaft Packing gland Stuffing box M10x45 ISO 4017 HH Screw Spring retainer plate “UCF 206”...

  • Page 72: Vdc 400

    TO320 R - EN - Ed. 04.09 VDC 400 Pos. Quantity Description Code Body High temp. gasket Hopper See Table 1 M10x30 ISO10462 TPSEI Screw Ø10 DIN 7980 Split washer M10 ISO 4032 Nut Shaft Packing gland Stuffing box M12x60 ISO 4017 HH Screw Spring retainer plate “UCF 208”...

  • Page 73: Vdc 500

    3 - Spare Parts Catalogue VDC 500 Pos. Quantity Description Code Body High temp. gasket Hopper See Table 1 M10x30 ISO10462 TPSEI Screw Ø10 DIN 7980 Split washer M10 ISO 4032 Nut Shaft Packing gland Stuffing box M12x60 ISO 4017 HH Screw Spring retainer plate “UCF 208”...

  • Page 74: Code" Reference Table

    TO320 R - EN - Ed. 04.09 “Code” reference Table Table 1 Hopper (3) Machine/Materials Steel AISI 304 AISI 316 Hardox 400 Polyurethane 20600191A 20600192A 20600193A See Tab.1.1 coat. 20600191P 20600201A 20600202A 20600203A See Tab.1.1 coat. 20600201P 20600211A 20600212A 20600213A See Tab.1.1 coat. 20600211P 20600221A 20600222A 20600223A See Tab.1.1 coat.
  • Page 75 3 - Spare Parts Catalogue Table 2 Flap (23) Machine/Materials Steel AISI 304 AISI 316 Hardox 400 Polyurethane 20600261A 20600262A 20600263A 20600267A 20600261P 20600271A 20600272A 20600273A 20600277A 20600271P 20600281A 20600282A 20600283A 20600287A 20600281P 20600291A 20600292A 20600293A 20600297A 20600291P 20600301A 20600302A 20600303A 20600307A 20600301P Table 3...

  • Page 76: Plate 2 - Counterweight

    TO320 R - EN - Ed. 04.09 Plate 2 - Counterweight 3 - Spare Parts Catalogue...

  • Page 77: Vdc 200

    3 - Spare Parts Catalogue VDC 200 Pos. Quantity Description Code Lever for counterweight M10x12 ISO 4027 ECEI Grub screw Counterweight M8 ISO 4032 Nut M8x30 ISO 4017 HH Screw VDC 250 Pos. Quantity Description Code Lever for counterweight M10x12 ISO 4027 ECEI Grub screw Counterweight M8 ISO 4032 Nut M8x30 ISO 4017 HH Screw...

  • Page 78: Plate 3 - Drive Unit

    TO320 R - EN - Ed. 04.09 Plate 3 - Drive Unit 3 - Spare Parts Catalogue...

  • Page 79: Vdc 200

    3 - Spare Parts Catalogue VDC 200 Pos. Quantity Description Code Lever for shaft Spacer 12x34x14 bearing (type 62201 2RS) M12 autoblock nut DIN 985 Spacer for bearing (SKF ZW 12x17 th.2) Ø12.5x48 UNI 6593 Disk washer Spring 20953611B Ø12 ISO 7089 Flat washer M12x70 ISO 4017 HH Screw M10x12 ISO 4027 ECEI Grub screw Pin for bearing...

  • Page 80: Vdc 250

    TO320 R - EN - Ed. 04.09 VDC 250 Pos. Quantity Description Code Lever for shaft Spacer 12x34x14 bearing (type 62201 2RS) M12 autoblock nut DIN 985 Spacer for bearing (SKF ZW 12x17 th.2) Ø12.5x48 UNI 6593 Disk washer Spring 20953611B Ø12 ISO 7089 Flat washer M12x70 ISO 4017 HH Screw...

  • Page 81: Vdc 315

    3 - Spare Parts Catalogue VDC 315 Pos. Quantity Description Code Lever for shaft Spacer 12x34x14 bearing (type 62201 2RS) M12 autoblock nut DIN 985 Spacer for bearing (SKF ZW 12x17 th.2) Ø12.5x48 UNI 6593 Disk washer Spring 20953621B Ø12 ISO 7089 Flat washer M12x70 ISO 4017 HH Screw M10x12 ISO 4027 ECEI Grub screw Pin for bearing...

  • Page 82: Vdc 400

    TO320 R - EN - Ed. 04.09 VDC 400 Pos. Quantity Description Code Lever for shaft Spacer 12x34x14 bearing (type 62201 2RS) M12 autoblock nut DIN 985 Spacer for bearing (SKF ZW 12x17 th.2) Ø12.5x48 UNI 6593 Disk washer Spring 20953631B Ø12 ISO 7089 Flat washer M12x70 ISO 4017 HH Screw...

  • Page 83: Vdc 500

    3 - Spare Parts Catalogue VDC 500 Pos. Quantity Description Code Lever for shaft Spacer 12x34x14 bearing (type 62201 2RS) M12 autoblock nut DIN 985 Spacer for bearing (SKF ZW 12x17 th.2) Ø12.5x48 UNI 6593 Disk washer Spring 20953641C Ø12 ISO 7089 Flat washer M12x70 ISO 4017 HH Screw M10x12 ISO 4027 ECEI Grub screw Pin for bearing...

  • Page 84: Spares Kit Tables

    TO320 R - EN - Ed. 04.09 Spares Kit Tables Table 4 Levers-crank kit Machine/Materials Code 200-250 13007001A 13007011A 13007021A 13007031A NOTE The Kits contain the following parts: 1 - 2 - 3 - 4 - 5 - 6 - 8 - 9 - 10 - 11 - 12 - 13 - 14 3 - Spare Parts Catalogue...

  • Page 85: Plate 4 - Pneumatics

    3 - Spare Parts Catalogue Plate 4 - Pneumatics TO320 R - EN - Ed. 04.09...

  • Page 86: Vdc 200

    TO320 R - EN - Ed. 04.09 VDC 200 Pos. Quantity Description Code Lever for shaft M10x12 ISO 4027 ECEI Grub screw M12 autoblock nut DIN 985 Pin for cylinder Swivel joint Seeger ring Ø10 DIN 471 Ø25 cylinder 100 mm stroke ISO 6432 Sensor for cylinder 1/8"...

  • Page 87: Vdc 250

    3 - Spare Parts Catalogue VDC 250 Pos. Quantity Description Code Lever for shaft M10x12 ISO 4027 ECEI Grub screw M12 autoblock nut DIN 985 Pin for cylinder Swivel joint Seeger ring Ø10 DIN 471 Ø25 cylinder 100 mm stroke ISO 6432 Sensor for cylinder 1/8"...

  • Page 88: Vdc 315

    TO320 R - EN - Ed. 04.09 VDC 315 Pos. Quantity Description Code Lever for shaft M10x12 ISO 4027 ECEI Grub screw M12 autoblock nut DIN 985 Pin for cylinder Swivel joint Seeger ring Ø10 DIN 471 Ø25 cylinder 125 mm stroke ISO 6432 Sensor for cylinder 1/8"...

  • Page 89: Vdc 400

    3 - Spare Parts Catalogue VDC 400 Pos. Quantity Description Code Lever for shaft M10x12 ISO 4027 ECEI Grub screw M12 autoblock nut DIN 985 Pin for cylinder Swivel joint Seeger ring Ø10 DIN 471 Ø32 cylinder 160 mm stroke ISO 6431 Sensor for cylinder 1/8"...

  • Page 90: Vdc 500

    TO320 R - EN - Ed. 04.09 VDC 500 Pos. Quantity Description Code Lever for shaft M10x12 ISO 4027 ECEI Grub screw M12 autoblock nut DIN 985 Pin for cylinder Swivel joint Seeger ring Ø10 DIN 471 Ø32 cylinder 160 mm stroke ISO 6431 Sensor for cylinder 1/8"...

  • Page 91: Cylinders Kit Table

    3 - Spare Parts Catalogue Cylinders Kit Table Table 5 Cylinders Kit Machine/Materials Code 200-250 13328001A 13328011A 400-500 13328021A The kits shown in the Table contain: 200-250-315 the following parts: 3-4-5-6-7-8-9-12 400-500 the following parts: 3-4-5-6-7-8-9-10-12 TO320 R - EN - Ed. 04.09...

  • Page 92: Plate 5 - Rotation Indicator

    TO320 R - EN - Ed. 04.09 Plate 5 - Rotation indicator 3 - Spare Parts Catalogue...

  • Page 93: Vdc 200

    3 - Spare Parts Catalogue VDC 200 Pos. Quantity Description Code Sensor unit guard Ø5 DIN 7980 Split washer M5x10 ISO 4017 HH Screw M8x16 ISO 4017 HH Screw Ø8 DIN 7980 Split washer Blade M12x40 ISO 4017 HH Screw Ø12 DIN 7980 Split washer Ø12x36 UNI 6593 Disk washer Rotation sensor connection...

  • Page 94: Vdc 315

    TO320 R - EN - Ed. 04.09 VDC 315 Pos. Quantity Description Code Sensor unit guard Ø5 DIN 7980 Split washer M5x10 ISO 4017 HH Screw M8x16 ISO 4017 HH Screw Ø8 DIN 7980 Split washer Blade M12x40 ISO 4017 HH Screw Ø12 DIN 7980 Split washer Ø12x36 UNI 6593 Disk washer Rotation sensor connection...

  • Page 95: Vdc 500

    3 - Spare Parts Catalogue VDC 500 Pos. Quantity Description Code Sensor unit guard Ø5 DIN 7980 Split washer M5x10 ISO 4017 HH Screw M8x16 ISO 4017 HH Screw Ø8 DIN 7980 Split washer Blade M12x40 ISO 4017 HH Screw Ø12 DIN 7980 Split washer Ø12x36 UNI 6593 Disk washer Rotation sensor connection...
  • Page 96 NOTE: The data given in this Catalogue are not binding and may undergo changes at any time + 39 / 059 / 8080811 TOREX S.p.A. Via Canaletto, 139/A + 39 / 059 / 908204 I - 41030 San Prospero torex@torex.it e-mail www.torex.it...
