- Page 1 INSTALLATION INSTRUCTIONS 105 Broadway St. Belvue, KS 66407 Phone: 800-669-9867 Fax: 800-393-6699 by Sapa www.onyxcollection.com 800-643-1514 www.alumaxshowerdoor.com ProLine PL80 HEAVY FRAMELESS BARN DOOR BATH ENCLOSURE PL80-0522...
- Page 2 Page 2 of 12...
- Page 3 Notes: Total width of shower door unit 7 / 8 ” –This is a two person installation. The width of the Door unit's base is 2 1/16" Fixe Panel (F) FOOT PRINT - Consider these measurements before drilling. SILICONE SILICONE All marks made on tile, marble or berglass should be made lightly in pencil so they can be removed after the installation is complete.
- Page 4 Stationary panel Bottom Channel MIDPOINT OF • Mark the center point (side to side) of the sill along the centerline established in step one. • Make a line 15/16” outside of the centerline. • Place Bottom Channel over this Line & drill a hole through both predrilled holes in the Bottom Channel.
- Page 5 Door Panel – Mount the roller assemblies to the Door Panel [P], making sure that the Roller Back Plate [Q], the Back Plate Sleeve [R] and the Back Plate Gasket [S] are to the outside. The Back Plate Gasket has the large holes. Place a Mid Plate Gasket [T] and the Mid Plate [U] on the inside of the glass and secure the Roller Plate [V] to the entire assembly with the Roller Screws [W].
- Page 6 Fixed Panel Installation - Lift the Fixed Panel and set it in the Bottom Channel with the edge as tight to the wall as possible. Loosen the Set Screws in the wall mount sleeves and slide them over the Wall Mount Blocks. Snug the Set Screws into the block (DO NOT TIGHTEN).
- Page 7 Seal Installation – Cut the Bulb Vinyl [JJ] and the Panel Seal [KK] to the vertical length of your Door Glass. Press the Bulb Vinyl on the strike side of the Door Glass and the Panel Seal on the other, below the Header Bar.
-
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS 105 Broadway St. Belvue, KS 66407 Phone: 800-669-9867 Fax: 800-393-6699 by Sapa www.onyxcollection.com 800-643-1514 www.alumaxshowerdoor.com Barn Door OPTIONAL RETURN PANEL Page 8 of 12... - Page 9 PL RETURN PARTS LIST A SC-658 Wall Jamb B Wall Jamb Screw C Wall Jamb Anchor D Bottom Channel Anchor F Bottom Channel G Bottom Channel Screw I Glass Return Panel Page 9 of 12...
- Page 10 Notes: This is a two person installation. All marks made on tile, marble or fiberglass should be made lightly in pencil so they can be removed after the installation is complete. An optional method is to use masking tape on the walls and sill that can be removed as the installation progresses.
- Page 11 Channel Installation – Put a little silicone in the glass anchors. Then, install the Channel using the Screws [G] provided. Wall Jamb Installation – Mount the SC-658 Wall Jamb [A] to the return wall. Page 11 of 12...
- Page 12 Return Panel Installation – Run a bead of silicone in the center of the the SC-658 Wall Jamb, and into the Bottom Channel. Then, orient the Glass Return Panel so that the return mount hole is toward the front of the enclosure. Slide the vertical edge of the glass into the siliconed SC-658 wall jamb.
