- Page 1 Netelligent 1108 100Base-TX Repeater User Guide...
-
Page 2: User Guide
1996 Compaq Computer Corporation. All rights reserved. Printed in the U.S.A. Compaq Registered United States Patent and Trademark Office. Netelligent is a trademark of Compaq Computer Corporation. Compaq Netelligent 1108 100Base-TX Repeater User Guide Second Edition (April 1996) Part Number 185813-002... -
Page 3: Federal Communications Commission Notice
......Federal Communications Commission Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: European Union Notice
This equipment complies with EMC directive 89/336/EEC (ITE), which includes EN 50082-1: IEC 801-2 (Electrostatic Discharge) IEC 801-3 (Radiated Immunity) IEC 801-4 (Electrical Fast Transient/Burst) EN55101-4 (Conducted Immunity) (not currently required) European Union Notice Safety Immunity Netelligent 1108 100Base-T Repeater User Guide... -
Page 5: Table Of Contents
Electrical Requirements ...2-1 Spatial Requirements ...2-2 Twisted-Pair (UTP/STP) Wire Requirements ...2-3 System Planning Charts ...2-5 Hub Setup and Cabling Chart...2-5 Rack Inventory Chart ...2-6 Chapter 3 Installing the Hub Mounting the Hub...3-1 Attaching the Rubber Feet...3-1 Netelligent 1108 100Base-TX Repeater User Guide... - Page 6 Rack-Mounting the Hub...3-1 Connecting Twisted-Pair Cable...3-2 Setting the Uplink Switch ...3-3 Interconnecting Hubs ...3-4 Connecting Power...3-4 Appendix A Specifications Electrical Specifications...A-1 Ports and Connectors...A-1 LED Indicators...A-1 Controls ...A-1 Power Requirements ...A-1 Power Consumption ...A-1 Power Cord (USA) ...A-1 Physical Specifications ...A-2 Dimensions ...A-2...
-
Page 7: Preface
Provides instructions for installing and powering up the repeater and for interconnecting repeaters. Appendix A specifications. Glossary Provides terms used throughout this guide, as well as general networking terms. Includes the repeater's electrical, physical, and environmental Netelligent 1108 100Base-TX Repeater User Guide... -
Page 8: Introduction
Chapter 1 Introduction The Compaq Netelligent 1108 100Base-TX Repeater (Part No. 267022-001) provides a high-speed solution to increasingly heavy network traffic and slow data throughput. The repeater uses the IEEE 802.3u, 100Base-TX standard to increase the speed of network transmissions by a factor of about 10. This enhanced performance greatly improves your network's efficiency. -
Page 9: Hub Components
1108 100Base-TX Repeater (Part No. 267022-001) Shielded AC power cord Compaq Netelligent 1108 100Base-TX Repeater User Guide Hub Components This section provides an overview of the repeater's components including the LED indicators, RJ-45 ports, and uplink switch. Figure 1-1 shows the repeater front panel and back panel. -
Page 10: Led Indicators
Flashing green indicates that there is activity at one or Flashing yellow indicates that the repeater detects a Steady green indicates that a link condition is present. indicates that there is activity at the port. Alternately UPLINK MDI-X Netelligent 1108 100Base-TX Repeater User Guide... -
Page 11: Uplink Switch
Introduction RJ-45 Ports The repeater has eight RJ-45 ports that let you connect UTP or STP cabling to workstations and servers in an Ethernet network. Uplink Switch The uplink switch enables the 8th port on the repeater to function as either a standard IN RJ-45 port or an uplinkable OUT”... -
Page 12: Planning Hub Installation
Environmental Requirements Be sure the operating environment for the repeater is within the following ranges: Temperature: 32 to 120 F (0 to 49 C) Humidity: 5% to 95% (non-condensing) Altitude: 0 to 10,000 feet Netelligent 1108 100Base-TX Repeater User Guide... -
Page 13: Electrical Requirements
Planning Hub Installation Electrical Requirements The electrical requirements for a repeater are as follows: Voltage: 100 to 240 VAC Frequency: 50 to 60 Hz Power: 0.25 to 0.5 Amps maximum CAUTION: grounded outlet. Do not use a three-to-two pronged adapter at the outlet. - Page 14 Pin 1 at the server, Pin 2 at the repeater connects to Pin 2 at the server, and so on. Figure 2-1 shows the locations of pins on a standard RJ-45 plug on a twisted-pair cable. Netelligent 1108 100Base-TX Repeater User Guide...
- Page 15 Planning Hub Installation Pins Figure 2-1. RJ-45 Plug Pin Locations Table 2-1 shows the wiring in a straight-through and crossover twisted-pair cable. (Pins 4, 5, 7, and 8 are not used.) Twisted Pair Number Twisted Pair Number Twisted-Pair Cable RJ-45 Plug...
-
Page 16: System Planning Charts
100Base-TX Repeater Setup and Cabling Chart Unit Number Building Location Rack Mount Table Mount Uplink Switch Setting MDI-X (default) MDI (uplinkable) Figure 2-2. Hub Setup and Cabling Chart Date Port Connects To Netelligent 1108 100Base-TX Repeater User Guide... -
Page 17: Rack Inventory Chart
Planning Hub Installation Use this chart to record the components installed in a particular rack. Wiring Closet Number Rack Number Installer Figure 2-3. Rack Inventory Chart Rack Inventory Chart Date Example 100Base-TX Repeater 100Base-TX Repeater... -
Page 18: Attaching The Rubber Feet
This kit includes two side mounting brackets and eight screws to secure the brackets. To attach the brackets, position them as shown in Figure 3-1. Then secure the brackets with the screws supplied with the mounting kit. Netelligent 1108 100Base-TX Repeater User Guide... -
Page 19: Connecting Twisted-Pair Cable
......Installing the Hub Figure 3-1. Attaching the Mounting Brackets After you attach both mounting brackets, position the bracket slots over the desired holes on the rack (Figure 3-2). - Page 20 Figure 3-3. Connecting Twisted-Pair Cable 100Base-TX Repeater UPLINK MDI-X 100Base-TX-Equipped Netelligent 1108 100Base-TX Repeater User Guide Workstation...
-
Page 21: Setting The Uplink Switch
Installing the Hub Setting the Uplink Switch The uplink switch lets you convert the repeater's 8th RJ-45 port to an uplinkable port so that you can interconnect two repeaters without the need for special crossover cables. The default setting for the switch is MDI-X (Media Dependent Interface-Reversed that is, standard repeater port). -
Page 22: Connecting Power
NOTE: The power outlet should be near the repeater and easily accessible. UPLINK MDI-X UPLINK MDI-X UPLINK MDI-X UPLINK Switch Set to MDI Position Netelligent 1108 100Base-TX Repeater User Guide... -
Page 23: Disconnecting Power
......Installing the Hub Power Cord Connector Figure 3-6. Connecting the Power Cord When you plug in the power cable, the PWR LED lights steady green. -
Page 24: Appendix A Specifications Electrical Specifications
Two-position (MDI/MDI-X) uplink switch Power Requirements Voltage: 100 to 240 VAC Frequency: 60 to 50 Hz Power: 0.25 to 0.5 Amps maximum Power Consumption Maximum: 16.2 W Power Cord (USA) Shielded 1.8 meters (6 feet), 10 Amps Netelligent 1108 100Base-TX Repeater User Guide... -
Page 25: Physical Specifications
Specifications Physical Specifications Dimensions 1.75 x 17 x 8.5 inches, 4.44 x 43.18 x 21.59 cm (HxWxD) Weight 4 pounds (1.81 kg) Environmental Specifications Operating Environment 32 to 120 F (0 to 49 C) 5% to 95% humidity (non-condensing) Storage Environment 32 to 151 F (0 to 66 C) 5% to 95% humidity (non-condensing) 0 to 30,000 feet altitude (0 to 9 kilometers) -
Page 26: Glossary
Ethernet, operates on different cable types (for example, UTP, coax, fiber). adapter See NIC. AUI (attachment unit interface) See transceiver cable. backplane The data bus connections used to interconnect different communication modules inside a networking concentrator. Netelligent 1108 100Base-TX Repeater User Guide... - Page 27 bridge A program running on a computer connecting two LANs that allows traffic from one network to be exchanged with the other network. The networks can be the same or different (for example, Ethernet and Token Ring). carrier sense The monitoring of a local area network by a node to determine if another node is transmitting.
- Page 28 Refers to the ability of a module, switch, or repeater to be added or removed from a stack without removing power from the switch or repeater. jabbering Continuous transmission from a node, generally as a result of a hardware or firmware failure. Netelligent 1108 100Base-TX Repeater User Guide...
- Page 29 Local Area Network (LAN) A communication system which covers a limited geographical area, as distinguished from a Wide Area Network which spans a wide geographical area. Light Emitting Diode (LED) A device that emits light at a power level well within guidelines for eye safety.
- Page 30 RS-232 lines generally include transmit, receive, ground, and various control lines. RS-485 Recommended standard 485 defines a standard way of transferring serial information by wire using differential line drivers and receivers. Netelligent 1108 100Base-TX Repeater User Guide...
- Page 31 RJ-45 A connector used for 10Base-T wiring (unshielded twisted-pair Ethernet). router A device used to connect two or more networks at the Network layer of the ISO-OSI reference model. The router must understand the communication protocols being used because it uses information provided by the protocols in each packet to determine how to route the packets.
- Page 32 Any building communications wiring system. See also 66-type wiring environment. wiring closet A room, closet, or cabinet where station cable is terminated on crossconnect blocks and where the building communications system can be administered. Netelligent 1108 100Base-TX Repeater User Guide...
-
Page 33: Index
MDI 3-4 MDI-X 3-4 Mounting 3-1 Mounting brackets, attaching 3-2 Network interface card 1-4 OUT 1-4 Planning charts 2-5 Ports RJ-45 1-1 Power 1-3, 2-2 connecting 3-5 cord 2-2, 3-5 disconnecting 3-6 outlet 2-2, 3-5 Netelligent 1108 100Base-TX Repeater User Guide... - Page 34 I-2 Index requirements 2-2 Power LED 1-3 Rack-mounting repeater 3-1 Requirements electrical 2-1 environmental 2-1 spatial 2-2 RJ-45 1-1 RJ-45 ports 1-2–1-4, 1-2 RKIT02 3-1 Rubber feet, attaching 3-1 Segment 1-4, 3-4 STP 1-1, 1-4, 2-3, 3-2 Straight-through (uncrossed) connection 1-4 Temperature ranges 2-1 Twisted-pair connecting 3-2...
