WA10F5S4 Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register DC68-03272Q-00 F500S_W3050_WA11F5_BEST+BETTER-03272M-02_EN.indd 1...
contents SAFETY INSTRUCTIONS Important safety precautions SETTING UP YOUR WASHER Description of part Checking before washing and caring for garments How to wash automatically depends on the laundry Control Panel MANUAL FUNCTIONS Manual functions INSTALLATION & MAINTENANCE Environment Levelling Connecting the water supply hose Assembling the rat protection panel (option) How to connect the drain hose (option) Calibration mode...
setting up your washer DESCRIPTION OF PART The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Water supply hose (Cold) Water supply hose (Hot) Be sure to keep the lid closed during washing and spinning.
CHECKING BEFORE WASHING AND CARING FOR GARMENTS Must follow the checkpoints in order to avoid machine problems or damages on garments. • If the below problems are caused by customer’s faults, separate service fee will be charged. Checkpoints Before Starting Washing Check if the clothes are bleaching or not.
Page 8
setting up your washer CARING FOR CLOTHES BEFORE WASHING Take out personal belongings from pockets. • Caution, Check the pockets! Hairpins and coins cause damages to clothes and washing machine. They make noise and problems to the machine. Must check the pocket. If pants zippers are open while washing, the spin basket may be damaged.
HOW TO WASH AUTOMATICALLY DEPENDS ON THE LAUNDRY Before starting washing, check the following; • Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose. Washing for the fi...
setting up your washer CONTROL PANEL For more details, see control panel of your washing machine. Displays the remaining wash time. Digital Displays the reserved delay end time. graphic Displays the error state if a problem occurs in the washing machine so that you display can take action.
Page 11
Magic Wash You can control the strength of water fl ow (High-Mid-Low) when washing by (Option) conventional motor. Press this button repeatedly to cycle through the water temperature and Air Turbo option: Temp./Option Cold > Cold, Air Turbo > Cold/Hot > Cold/Hot, Air Turbo > Hot > Hot, Air Turbo Press this button once to operate.
Page 12
setting up your washer CHILD LOCK This function is for protecting children, the elderly and the frail. 1. Press the Power button. 2. To activate the Child Lock function, press and hold both the Rinse and Spin buttons down simultaneously for 3 seconds. (If the Child Lock function is activated, the Child Lock icon blinks.) 3.
Page 13
Downloading the Samsung Smart Washer app Download the Samsung Smart Washer app to your mobile phone from the Android market or Apple App store and install it. You can easily fi nd it by searching for “Samsung Smart Washer”. Using the Smart Check function 1.
manual functions Possible to select the function for each program. (Example) For a simple washing as the little dirt program : Power Select the little dirt program Wash Start/Pause Press the Power button. WASH ONLY Press the Wash button. Press the Start/Pause button.
installation & maintenance The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. ENVIRONMENT Leave some space Maintain at least 10 cm between the washer and the wall. Place the washer on a sturdy fl at surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs.
installation & maintenance 4. Connect the water supply hose to the adaptor. Pull down the part (c) of the water supply hose. When the part (c) is released, the hose is automatically connected to the adaptor making a ‘click’ sound. 5.
HOW TO CONNECT THE DRAIN HOSE (OPTION) IN CASE OF PUMP-DRAINED WASHER cap-hose Take out the cap-hose and connect the Be sure to join tightly the drain hose into the outlet-hose. (option) drain outlet on the back of the machine. Drain hose Hose guide Be sure to join tightly the drain hose into the...
Make sure that you install your washing machine correctly by running the Rinse+Spin cycle after the installation is complete. CALIBRATION MODE Your Samsung washing machine detects the laundry weight automatically. For more accurate weight detection, please run Calibration Mode after the installation. To run Calibration Mode, follow these steps: 1.
ADDING FABRIC SOFTENER 1. When the proper amount (one time dose) of fabric softener is stored in the softener inlet, it is automatically added during the last rinse cycle. 2. Do not add detergent, bleach or starch into the softener inlet. 3.
installation & maintenance CLEANING THE PUMP FILTER (OPTION) 1. Place a rag or towel under the wash fi lter to avoid wetting the fl oor, and rotate the fi lter counterclockwise and pull it out. 2. Remove any dirt from the fi lter. 3.
Page 23
PROBLEM CHECK The water leaks at the water supply Did you press the Start/Pause button after selecting the water hose connector. supply? If the Start/Pause button is not pressed, water is not supplied. Press the Start/Pause button. Is the faucet closed? ...
specifi cation The energy label specifications have been determined by using the following program according to UAE.S 5010 2:2013. - The program is "energy test course". 24_specifi cation...
Page 50
. مصاوملا تسمية الطلقة قد مت حتديدهل بلستخدام البرنلمج التللي وفقل ل 0105 3102:2 اﻻملراا العربيه افتحده The energy label specifications have been determined by using the following program according to UAE.S 5010 2:2013. ) - هذا البرنلمج هص ( دورة اختبلر الطلقه - The program is "energy test course".
