NOTICE: NOTICE: Meyer Products LLC reserves thje right, under its continuing product imporvement program, to change construction, design, details, specifications, and prices without notice or without incurring any obligation. Meyer Products LLC assumes no responsibility for installations not made in accordance with these instructions. Table of Contents General Information ............................................1 Black Iron Parts Lists .............................................2-3...
Page 4
Black Iron Parts List Item Part Description Item Part Description 41620 DE SOS E73 7.5-9.0 41622 • Accessory Box 05818 Lift Ram 1.75 x 8” 23025 •• Power Cable 07772 • L.H. Ram with Hose & Fittings 07178 •• Trip Spring 05887 ••...
E73 Hydraulics Hydraulic Solenoid Color Coil Wire Color Code: Raise Motor Solenoid + “B” Solenoid Motor White Note: Note: Ground wire for each coil is Lower “A” Solenoid Black Black with a White Stripe Left Angle Motor Solenoid Right Angle Motor Solenoid + “C”...
Wiring Harnesses & Controller Vehicle Side Harness Vehicle Side Harness 1) Route the 12 pin connector into vehicle’s cab and plug into controller. 2) Route the 16 pin connector to the front of the vehicle and plug into the plow side harness. 3) Route the 4 pin connector to rear of vehicle and plug into vehicle’s trailer harness using the trailer adapter harness.
Plow Assembly & Adjustments Adjustable Clevis Adjustable Clevis Nite Saber LED Lights Nite Saber LED Lights The 14700 adjustable clevis The 14700 adjustable clevis is now standard with all Standard Operating Sys- See seperate Nite Saber LED instructions for further information. tem black iron packages.
Page 9
Plow Assembly & Adjustments Trip Spring Adjustment Trip Spring Adjustment Lift Chains Lift Chains Attach Eye Bolts to Moldboard and Trip Springs to Pivot Bar, making certain Attach the Lift Chain to the Lift Arm through the two hooks on the lift locknuts are positioned as shown below.
Mounting Plow NOTE: NOTE: Pictures may vary based on model A. Pull vehicle into plow E. E. Remove crankstand assembly and push plow from a-frame. assembly forward an inch or two. B. B. Twist handles on both sides to engage spring loaded pins.
Dismounting Plow A. Press down button until float light turns blue. E. E. Adjust crankstand until the crankstand comes in contact with the ground and then turn 1 to 2 revolutions. B. Push lift arm down until there is slack in the chain. F.
