ASSEMBLY INSTRUCTIONS
Before You Begin:
Please identify all component parts and hardware pieces required before you begin. Carefully remove all of the
components from the packaging and set aside for assembly. Assemble on a soft surface to prevent scratching
during assembly.
Caution:
Tighten all components securely before use. Failure to do so may result in personal injury.
DO NOT use any sharp objects to open plastic wrapped components as damage to product or components may
result.
Warning:
CHOKING HAZARD - Small Parts. Adult Assembly Required.
DO NOT ALLOW CHILDREN TO CLIMB ON FURNITURE
Serious or fatal injuries can occur from furniture tipping over. You must install Tipping Restraint Hardware (where
included) to help prevent the unit from tipping and causing accidental injury, instability, death or damage. The
tipping restraint is intended only as a safety measure, it is not a substitute for proper adult supervision.
To help prevent furniture from tipping over it must be permanently attached to the wall. Anti-Tip Safety Wall
Straps suitable for the unit weight and wall materials (if not included) should be purchased and installed.
Customer Service Email:
Rocking Adirondack Chair
CustomerExperience@belnick.com
JJ-C14709-NV-GG / JJ-C14709-WH-GG / JJ-C14709-BK-GG / JJ-C14709-GY-GG
Modern All-Weather
I
Phone: 866-552-2810
Tlumleyou.foryourpurchase!
Advertisement
Table of Contents
Summary of Contents for Belnick JJ-C14709-NV-GG
- Page 1 To help prevent furniture from tipping over it must be permanently attached to the wall. Anti-Tip Safety Wall Straps suitable for the unit weight and wall materials (if not included) should be purchased and installed. Customer Service Email: CustomerExperience@belnick.com Phone: 866-552-2810 JJ-C14709-NV-GG / JJ-C14709-WH-GG / JJ-C14709-BK-GG / JJ-C14709-GY-GG...
- Page 3 PARTS Left Leg Right Leg Backrest � Front Crossbeam Seat Rear Crossbeam Left Arm 2PCS Right Arm Rockers Hardware Included �- cc @mm1 1 m m111 m mm1rn1u1-BB pm@11 1 1 m 1 1 1 1 1 1 1 1 1 1 1 111 1 m111 1 m 1 111 1 - AA �...
- Page 4 STEP 1: Attach the Left Leg (Part E) and Right Leg (Part F) to the Seat (Part B) using (6) M6*60 Bolt and Nut Sets (Part CC). Hand tighten bolts. M6*60 Bolt Seat Left Leg M6*60 Bolt and Nut Sets Right Leg STEP 2: Attach the front of the Rockers (Part J) to the Left and Right Legs (Parts E&F) and Front Crossbeam (Part G) using (2) M6*60 Bolts (Part BB).
