mercor EXi-F Operation And Maintenance Manual

Pressure differential system kit for smoke and heat control systems

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Ul. Grzegorza z Sanoka 2

80 – 408 Gdańsk

phone (0-58) 341 42 45

tel./fax (0-58) 341 39 85

OPERATION AND MAINTENANCE MANUAL

mcr EXi-F pressure differential system kit for smoke and

heat control systems

No EXi-F 005

2022

FIRE VENTILATION SYSTEM DEPARTMENT

Table of Contents

Need help?

Do you have a question about the EXi-F and is the answer not in the manual?

Questions and answers

Summary of Contents for mercor EXi-F

Page 1 Ul. Grzegorza z Sanoka 2 80 – 408 Gdańsk phone (0-58) 341 42 45 tel./fax (0-58) 341 39 85 OPERATION AND MAINTENANCE MANUAL mcr EXi-F pressure differential system kit for smoke and heat control systems No EXi-F 005 2022 FIRE VENTILATION SYSTEM DEPARTMENT...
Page 2: Table Of Contents
5.5. D ..............................26 UCT SMOKE DETECTOR 6. TRANSPORT AND STORAGE ............................27 7. MAINTENANCE AND SERVICING ..........................27 8. WARRANTY TERMS AND CONDITIONS........................27 Page 2 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 3: Introduction
1. INTRODUCTION _________________________________________________ This operation and maintenance manual (OMM) provides information on applications, design, operation, installation and maintenance of mcr EXi-F smoke control system for escape routes. This manual also includes additional information on operating conditions, maintenance and warranty terms and conditions.
Page 4: System Applications
EXi-F system can be used in staircases with protected lobbies and is compatible with systems including at least one pressure transmitter per protected area. mcr EXi-F system consists of a configured set of devices preventing smoke ingress to the protected area by increasing pressure. Constant...
Page 5: Operation
The system is managed by mcr Omega control unit (CU) including all the required components (e.g. mcr ICR positive pressure regulator). Positive-pressure mcr EXi-F system is activated automatically via SAP signal or manually via CU or the manual control panel. After detecting the fire in the building, the air dampers of the air supply units are activated, and the air supply unit is activated with a delay (necessary to open the shut-off dampers).
Page 6 EXi-F positive pressure smoke control system Fig. 2. Example positive pressure mcr EXi-F system Page 6 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 7 Omega control unit CORRIDOR LIFT WELL Fig. 4. Example positive pressure system for lift shaft Page 7 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 8: System Selection Guide
3.3. System selection guide ___________________________________________ mcr EXi-F systems should be installed in accordance with the design developed for a specific building to one of the following design requirements:  PN-EN 12101-6:2007 Smoke and heat control systems. Part 6: Specification for pressure differential systems.
Page 9 EXi-F positive pressure smoke control system Fig. 5. Example mcr EXi-F system control configuration diagram Operation __________________________________________________________ Page 9 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 10 EXi-F positive pressure smoke control system The automatics used in mcr Omega unit control, supply, monitor and visualize operation of all mcr EXi-F kit components. Fig. 6. mcr Omega control unit - general view Main control unit (CU) tasks:  power supply, control and monitoring of the air supply fans for positive pressure via signals from the fire alarm control panel (FACP), ...
Page 11 Fig. 7. mcr ICR pressure regulator - general view Page 11 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 12 After installing and checking the correct operation of all system components, the system starts the adaptation procedure. Pressure regulator operation parameters and adaptation procedure are performed by „MERCOR” or an authorized service centre. The control unit cooperates with the fire control panels as per the following procedure: receive...
Page 13: Mcr Exi-Fair Supply Units
EXi-F air supply units include mcr Monsun E1 series axial fans in a box type housing. Air supply fans are characterized by high efficiency at low pressures. The task of the fans is to transport the appropriate amount of air to ensure that the design requirements are met.
Page 14 For vertical installation indoors, the unit is mounted on the supporting structure and connected to the air supply system in accordance with the design requirements. mcr EXI-F air supply units include multi-blade dampers with actuator. The rotary mechanism of the damper include gears and bearings or steel rods.
Page 15 1000 mcr EXi-F 71-2S 1000 mcr EXi-F 63-1S Fig. 9. Dimensions and weights of mcr EXi-F air supply kit with fan in box housing Page 15 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 16 1100 8 mcr EXi-F 63-1S-H Fig. 10. Dimensions and weights of mcr EXi-F air supply kit with fan in box housing Fig. 11. Example mcr EXi-F air supply unit in wall-mounted version (installation indoors) (1 - fan in a box housing, 2 - flexible connection, 3 - damper with actuator, 4 - air intake, 5 - vibro-isolating pad or...
Page 17: Differential Pressure Transmitter
Fig. 12. Example mcr EXi-F air supply unit in wall-mounted version (installation outdoors) (1 - fan in a box housing, 2 - flexible connection, 3 - damper with actuator, 4 - air intake, 5 - vibro-isolating pad or shock absorbers, 6 - smoke detector, 7 - supporting structure, 8 - protective mesh) Fig.
Page 18 Pressure line connectors. Connectors outside the Pressure connection enclosure, dia. 6 (mm) Differential interface, distributed system, galvanic Output separation mcr BUS driver Sensor range Pressure -500 ÷ +500 (Pa) Page 18 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 19: Auxiliary Components Of Mcr Exi-F System
POWER is always on when the power is supplied to the device. STATUS is always on when awaiting an event or flashing when indicating fire. 4.3. Auxiliary components of mcr EXi-F system ________________ 4.3.1. Intake vent switching system _____________________________________________ If the air inlets are at the roof level, two air inlets are required, distant from each other and facing different direction to avoid leeward position in relation to the smoke source.
Page 20: Duct Smoke Detector Ug-3-A4
Fig. 16. Example mcr EXi-F air intake unit in roof-mounted version with two intake vents (1 - fan, 2 – intake vent, 3 - vibration damper, 3 - flexible connector, 4 – dampers with actuators in two intake vent configuration, 5 - duct smoke detectors in external version) 4.3.2.
Page 21: Manual Control Panel (Mcp)
 alarm – red light ON indicates alarm,  lock – blinking yellow light indicates manual lock,  air inlet fan operation - green light ON indicates air supply unit operation Page 21 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 22: Wiring System
Fig. 19. Example manual control panel view. 5. WIRING SYSTEM _________________________________________________ .1. mcr Omega control supply unit The control unit is used for controlling and monitoring mcr EXi-F pressure differential system components. Main automatics system tasks:  power supply, control and monitoring of the air supply fans for positive pressure via signals from the fire alarm control panel (FACP), ...
Page 23: Mcr Exi-Fair Supply Units
Omega unit up to 50 m 5.2. mcr EXI-F air supply units mcr EXI-F air supply units can be fitted with service switches for cutting off fan power supply before inspection or maintenance.
Page 24: Mcr Ics Pressure Transmitters
ICS pressure transmitter to the outlet box, avoiding flow restrictions. Use fittings and lead the pressure line in the RL type conduits, flush or surface-mounted, as an additional protection against mechanical damage. Page 24 / 28 „MERCOR” S.A. – Specifications are subject to change without notice. Version DTR_EXIF_EN_20220516...
Page 25: Damper Actuators
Protect the ends of the hydraulic lines against accidental blocking. Use back boxes with pre-drilled holes in the cover. 5.4. Damper actuators mcr EXI-F air supply units are also available with multi-blade dampers with Belimo BLF/BF/BFL/BFN, BLE/BE, NMQ/LMQ/SMQ, NF/SF or Mercor MF/MLF Page 25 / 28 „MERCOR”...
Page 26: Duct Smoke Detector
Fig. 24. Wiring diagram for Belimo BLF/BF/BFL/BFN, MF/MLF, NF/SF actuator (shut-off damper for mcr EXI-F air supply units) Belimo BE actuators (no spring return) are used in dampers in the intake vent switching system Fig. 25. Wiring diagram for Belimo BE/BLE actuator in two-intake vent switching system 5.5.
Page 27: Transport And Storage
058/ 341 42 45 ext. 170 or fax 058/ 341 39 85 office hours 8 – 16 (Mon-Fri). 8. WARRANTY TERMS AND CONDITIONS ______________________________ „MERCOR” S.A. provides a 12-month quality guarantee for all its products from the date of purchase, unless otherwise stated in the purchase contract.
Page 28  devices or their components if the data plate or any warranty seals are removed or broken. Warranty claims should be made to „MERCOR” S.A. within 7 days from the date the defect was identified. Warranty claims can be made at: phone: 58/341-42-45, fax: 58/341-39-85, e-mail: reklamacje@mercor.com.pl...
