Summary of Contents for Lite-Puter DP-8DA
- Page 1 User Manual DP-8DA 8-Channel Dimming Pack (EDX/DMX TO Analog Decoder) DP-8DA [EUM-C]...
-
Page 2: Table Of Contents
2 OPERATIONS ..............................6 2-1 ID NO. S ..............................6 2-2 S ..............................6 CENE 2-3 C ............................... 6 HANNEL 2-4 DMX ............................6 ADDRESS SET 2-5 Z ..............................7 2-6 V ............................... 7 ERSION LIMITED WARRANTY ............................8 DP-8DA [EUM-C]... -
Page 3: Before Installation
ECP panel. 1-2 Specifications ■ Power Supply: DC 12V (optional 12V adaptor) ■ Output spec: 8 channel/0~10V DC ■ Protocol: DMX-512/EDX ■ Signal Connector: 4 pin terminal ■ Dimension: 130(W) x 85(D) x 59(H) mm ■ Weight: 295g approximate DP-8DA [EUM-C]... -
Page 4: Dimensions
1-3 Dimensions 1-4 Functions DP-8DA [EUM-C]... - Page 5 LCD display screen Function zone: 【ENT】 — enter 【FUNC】— function 【◀】, 【▶】, — option shift 【▲】 、 【▼】— option/parameter adjust 8-channel 0-10V DC output EDX/DMX Port Program download interface 12V DC input (Please Note: AC to DC adapter is optional.) DP-8DA [EUM-C]...
-
Page 6: Diagram
CX-1C LD-1025 LD-1025 LD-1025 LD-1025 ECP-103 About EDX cable line: The digital signal wiring is basically the same as RS-485 wiring. If you are not familiar with RS-485 wiring, please check EDX wiring guide on Lite-Puter’s website: http://www.liteputer.com.tw/tech_guide.asp DP-8DA [EUM-C]... -
Page 7: Operations
【▲】/【▼】 again to set channel. Press【ENT】to save and exit. DP-8DA is able to set 6 sets of scenes that can control 8-channel outputs. 2-3 Channel Set Press 【 FUNC】 to enter menu, press 【 ▲】 / 【 ▼】 to select F3： EDIT CH. Press 【 ENT】 to enter channel 【▶】... -
Page 8: Zone Set
SUB ZONE which can be set to 255(Max.). SUB_ZON：Channel start number of a specific zone. For example, if SUB_ZONE=003, CH003 of ECP-103 corresponds to the first channel of DP-8DA. 2-6 Version Press 【FUNC】 to enter menu, press 【▲】 / 【▼】 to select F6：VERSION . Press 【ENT】 to enter. After check version press【FUNC】to exit. -
Page 9: Limited Warranty
2. Lite-Puter guarantees to keep Lite-Puter’s from manufacturing defects within a year since the distributing date. 3. Lite-Puter does not offer on-site service. If the defects appears in Lite-Puter’s product, please deliver the product to local distributors or to Taipei headquarters.
