- Page 1 COMPACT8 ANALOGUE PREAMPLIFIERS & MIXERS Installation Analogue Mixer USER MANUAL 50-0109-0102 COMPACT8 EN...
-
Page 2: Table Of Contents
INDEX IMPORTANT REMARK......................3 IMPORTANT SAFETY INSTRUCTIONS ................4 IMPORTANT NOTE ........................5 INTRODUCTION ........................5 INSTALLATION.......................... 6 5.1. Placement and mounting ......................6 5.2. Connectable Signal Sources ....................7 OPERATION AND USAGE ...................... 8 6.1. Start up ............................8 6.2. -
Page 3: Important Remark
IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 5: Important Note
IMPORTANT NOTE Thank you for choosing our Ecler COMPACT8, Installation Analogue Mixer! VERY IMPORTANT It is to carefully read this manual and to fully understand its contents before any connection in order to maximize your use and get the best performance from this equipment. -
Page 6: Installation
All channels feature a lever switch input selector, independent gain control for each channel and 3-band tone controls with semiparametric adjustment for the mid-band. (Center frequency adjustable, fixed Q) All inputs are PFL capable in order to visually (through the VU meters) and acoustically (through headphones) monitor any signal connected to the inputs of the unit. -
Page 7: Connectable Signal Sources
5.2. Connectable Signal Sources • Turntables / Phono: They must be fitted with a magnetic cartridge with nominal output level between -60dBV and -20dBV (1 to 100 mV). The PHONO (38) inputs of the COMPACT 8 have a high headroom (margin before saturation) and it can handle higher output cartridges than what is usual. -
Page 8: Operation And Usage
OPERATION AND USAGE 6.1. Start up Power up the mixer by pushing the POWER (15) switch. The green pilot-light, integrated into the switch itself, will immediately light up. Although the noise generated by powering up the COMPACT 8 is reduced to a bare minimum and is nearly null with the OUT (17 and 20) controls down, it is always advisable not to forget about this power-up sequence: sound sources, mixer, equalizers, active filters and power amplifiers. -
Page 9: Channel Indicators
6.4. Channel indicators Each of the 8 input channels features two indicators. The green SP LED (4) shows the presence of signal on the currently selected input. The indicator lights up at a threshold of –40dBV. The red PEAK LED (3) warns about the risk of saturation, that is exceeding the recommended signal input level limit. -
Page 10: Considerations
The balanced circuit simulates an output transformer, so if you wish to use OUT 1 in non- balanced mode, you should short circuit the unused pin to ground. Otherwise, the signal will not have an appropriate level and quality. The OUT 2 output (33) is non-balanced or asymmetrical. The COMPACT 8 has one recording output REC (36), which is pre-talkover, i.e. -
Page 11: Function List
FUNCTION LIST 1 Input sensitivity adjust, GAIN 20 Volume control OUTPUT1, OUT 1 2 Input selector 21 Headphones volume control, VOL 3 LED indicator, PEAK 22 Stereo jack, headphones 4 LED indicator, SP 23 Microphone balanced input, MICRO 8 5 LED indicator, PFL 24 LED indicator, TALKOVER ON 6 Treble control, TREB 25 Talkover switch... -
Page 12: Technical Characteristics
TECHNICAL CHARACTERISTICS COMPACT8 Inputs Sensitivity nom/Impedance LINE (A-B-AUX) 0dBV/50k PHONO -40dBV/50k MICRO (BAL) -50dBV/>1k MICRO ATT (BAL) -30dBV/>1k Outputs Level/Minimum Load OUT 1 (BAL) 0dBV/600 1V *(+6dB 2V) OUT 2 0dBV/2.2k 1V *(+6dB 2V) 0dBV/10k HEADPHONES 200mW/200 Frequency Response LINE 10Hz÷30kHz -1dB... -
Page 13: Diagrams
DIAGRAMS 10.1 Configuration Diagram... -
Page 14: Block Diagram
10.2 Block Diagram MIC-R MIC-L CTR-PFL PFL-R PFL-L PGM-R PGM-L PHANTOM... - Page 15 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. For technical queries contact your supplier, distributor or complete the contact form on our website, Support / Technical requests. Motors, 166‐168 08038 Barcelona ‐ Spain ‐ (+34) 932238403 | information@ecler.com www.ecler.com...
