Please read this manual carefully before operation.

The Below Sentence may or may not comply with Your TV Model.

Attention:

This Product Is Qualiﬁed for the BEE Start Rating in the Default Mode

Set in the TV (Standard Mode Mostly).

The Objective of Star labeling Program is designed to promote energy

eﬃcient products & practices.

When the television is initially Set Up, It Is Designed to meet the BEE

star labeling requirements while maintaining optimum picture quality.

• Changes to certain functionalities of this television (TV Guide,

Picture/Sound, etc.) may change the power consumption.

• Depending Upon Such Changed Settings, (E.g. User Mode),

the power consumption may vary which possibly could exceed

the stated Energy Consumption.

To Reset the TV to Star Rating Qualiﬁed Settings please perform a

Factory Reset from the TV menu

Table of Contents

Need help?

Do you have a question about the L43A2000FHD and is the answer not in the manual?

Questions and answers

Aradhya

April 24, 2025

Bina remote ke t v kaise on kare

Summary of Contents for Micromax L43A2000FHD

Page 1 Please read this manual carefully before operation. The Below Sentence may or may not comply with Your TV Model. Attention: This Product Is Qualiﬁed for the BEE Start Rating in the Default Mode Set in the TV (Standard Mode Mostly). The Objective of Star labeling Program is designed to promote energy eﬃcient products &...
Page 2: Regulatory Information
Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning ﬂash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage”...
Page 3: Important Warnings And Cautions
Warning IMPORTANT WARNINGS AND CAUTIONS! Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. BUT IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD.
Page 4 Warning 11. Wall mounting---When mounting the product on a wall, be sure to install the product according to the method recommended by the manufacturer. This is a safety feature. 12. Stand--- Do not place the product on an unstable trolley, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product.
Page 5 Warning Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: - Using cabinets or stands recommended by the manufacturer of the television set.
Page 6: Important Safety Instructions
Safety Instructions IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 7. Do not block any ventilation 2. Keep these instructions. openings. Ventilation should not be impeded by covering the ventilation 3. Heed all warnings. openings with items such as 4. Follow all instructions. newspapers, table-cloths, curtains etc.
Page 7 Safety Instructions 10. Protect the power cord from being 13. For added protection for this walked on or pinched particularly at product during a lightning storm, or plugs, convenience receptacles, when it is left unattended and and the point where they exit from unused for long periods of time, the apparatus.
Page 8: Main Unit Control
Main Unit Control Front Panel Power Key: Turn On/Oﬀ TV Channel+/-: Change Channels Vol+/Vol - : Increase & Decrease Volume Source: Change Input Source Remote sensor Menu: Open Menu Function Power Indicator Rear & Sides Panel COAXIAL PC AUDIO HDMI1 HDMI2 HDMI: HDMI port.
Page 9: Connection And Setup
Connection and Setup Connection Turn oﬀ and unplug all components before making connections. Do not turn on the TV until connection setup is completed. High or Standard Input Connector Video Connection Audio Connection Deﬁnition Quality 480P Composite video (SD content) Audio L/R connector HDMI cable carries...
Page 10 Connection and Setup Cable Installation Before the installation and use, please read carefully the relevant content in “Warning and Safety instructions”. 1. Take the TV from the wrapping package and put it in a drafty and ﬂat place. NOTE: ➢When you plug or unplug the TV, computer or other equipment, you must make sure that the AC power has been already shut down;...
Page 11: Getting Started
Getting Started Using the Remote Control When using the remote control, aim it at remote sensor on the television. If there is an object between the remote control and the remote sensor on the unit, the unit may not operate. * Point the remote control at the REMOTE SENSOR located on the television.
Page 12: Remote Control
Remote Control The buttons of the original remote control are as following: Deﬁnition of the buttons on remote control: POWER: Switch on or oﬀ TV set. INFO: Show info of current program. NUMBER BUTTONS: Key in the alphanumeric digits to switch to the designated channel directly.
Page 13: Basic Operation
Basic Operation Turning on and oﬀ the TV • Turn on the TV Connect the TV to your mains socket. If TV has a power switch, turn it on ﬁrstly. In standby mode, press Power button on the remote to turn on the TV. Press the button at the lower-left side of back panel to turn on the TV.
Page 14: Menu Operation
Menu Operation Main Menu Operation Before using the TV follow the steps below to learn how to navigate the menu in order to select and adjust diﬀ erent functions. The access step may diﬀ er depending on the selected menu. Press MENU button to display the main menu.
Page 15 Menu Operation ■ Programme Edit Press the▲/▼ buttons select the Programme Edit, then press the ENTER button to enter sub-menu. First press the▲/▼buttons to highlight the channel you want to delete, skip, rename or Move, then: Press the RED button to delete the channel. Press the GREEN button to rename the channel.
Page 16 Menu Operation Sound Menu Sound Mode: You can select a sound mode to suit your personal preferences. ﬁve-stage equalization setting can be adjusted when the sound mode is set to User. ■ Five-stage equalization setting: Press the ▲ /▼button to select: 120 HZ, 200Hz500 HZ, 3 KHZ or 12 KHZ, and then press the left / right button to adjust the frequency equalization of the sound.
Page 17 Menu Operation Setup Menu ■ OSD Language: Select your preferred On Screen Display language. ■ Aspect Ratio: You can select the picture size which best corresponds to your viewing requirements. ■ Key Lock: Lock or unlock the key panel buttons on the TV. Press the◄/►...
Page 18 It can play PHOTO, MUSIC, MOVIE or TEXT ﬁles. Photo Format Support: JPEG, BMP, PNG. Music Format Support: MP3, M4A（AAC）. Movie Format Support: MPG. Text Format Support: TXT. Micromax Doesn’t Guarantee a Support for all the External Devices & Codec’s available in the market.
Page 19 Menu Operation • Main Operating Interface • Basic operation 1. Use the ◄/► buttons to select PHOTO, MUSIC, MOVIE or TEXT. Press ENTER Button enter sub-menu. 2. Use the arrow buttons and ENTER button to enter the desired disk. Press ENTER To open the folder.
Page 20 Menu Operation When playing Music ﬁles: ＊Use the◄/► buttons, then press ENTER to select a function such as Previous, Next, play, pause the on-screen toolbar. or EXIT buttons to exit playback & go back to ﬁle list page. ＊Press When playing Movie ﬁles: Press the INFO button on the remote control to hide/display the on-screen toolbar.
Page 21: Important Unique Buttons
Important Unique Buttons Channel List Press LIST button to display the Channel List. Press the ▲/▼ buttons to select the channel and press ENTER to watch it. Press LIST/EXIT button to exit the channel list. Favorite List Press button to display the Favorite List. (You should setup your favorite channels in Program Edit menu) Press the ▲/▼...
Page 22: Troubleshooting Guide
Troubleshooting Guide Troubleshooting When you meet the following common problems, you might diagnose and get the solutions without contacting with the technicians. Symptoms Possible Reason Solutions 1.The power cord is not plugged in 1.Plug the power cord in No picture, no sound, and no indicator light on 2.The power is oﬀ...
Page 23 Troubleshooting Guide Plug the HDMI cable again HDMI source, with snow The source generate is not pixel of full screen standard 1. Make sure the positive and the negative polarities are correct. The remote control does Batteries are improperly installed or 2.
Page 24: Base Stand Installation
Base Stand Installation...
Page 25 1. Drill the holes as illustrated and insert the Gitti (Plastic Anchors) 2. Fix the wall bracket with screw onto the Gitti (Plastic Anchors). 3. Put the TV set on the label table on which the pad cloth or other soft material and support enough weight.
Page 26 4. Hinge the whole unit with hanging wheels on the ﬁxed wall bracket at the top of which was tightened with screws M4 X 35 Tc avoid the accidental fall of the whole unit oﬀ the wall bracket. 1. Do not attempt to install the TV by yourself. Refer all installation Tc qualiﬁed service personnel. 2.
Page 27 43" SIZE LED Type 109 cm TFT LED Display Resolution 1920 X 1080 (FHD) Contrast Ratio 1200:1 6 ms Response Time 178 (H)° / 178 (V)° Viewing Angle Lamp Life Time 30,000 Hours Minimum PAL/SECAM, BG/DK NTSC (3.584/4.43) Receiving System In playback only.
