3.4. Power

POWER INPUT

Bright sunlight
Overcast sky
Department store
Grocery store
Meeting rooms
Office space
Warehouse
Examples:
Let's say your unit is charged up to 33% . 1/3 of a battery of 500mA battery means you have 167 mA in your battery and you still need 333
mA to reach full charge. On an overcast day, we can estimate a charging rate of 10 mA per hour. If not in use, the solar cell will require 33.3
hours to produce the 333 mA at 10 mA per hour. When in use, the power drain is 0.25 mA per hour. This means that the lling capacity will
be 10 - 0.25 mA per hour which equals 9.75 mA per hour. In this scenario, to reach full charge (100%, 500 mA) it would take 34 hours while
in use.
ULTRASONIC Portable Solar
User manual
W/m
2
1000
100
10
1
BATTERY STORAGE
mA
+22 mA/h
500
NORMAL MODE
· Data rate: 1Hz
+10 mA/h
50
SLEEP MODE
Advertising information (BLE signal).
12.5
SAFETY MODE
Battery damage prevention.

POWER OUTPUT

% load
battery
100%
-0.25 mA/h
10%
2.5%
OFF
