INTRODUCTION
Thank you for choosing MUSON Smile Key aromatherapy diffuser with
white noise and mood lights. Please read the manual carefully, and
keep it for future reference. If you need any assistance, please contact
our customer support team by emailing support@musonworld.com.
PRODUCT DESCRIPTION
/VOL+
/VOL-
MIST
LIGHT
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smile Key and is the answer not in the manual?

Questions and answers

Summary of Contents for MUSON Smile Key

  • Page 1 INTRODUCTION Thank you for choosing MUSON Smile Key aromatherapy diffuser with white noise and mood lights. Please read the manual carefully, and keep it for future reference. If you need any assistance, please contact our customer support team by emailing support@musonworld.com.
  • Page 2 /VOL+ /VOL- MIST LIGHT 1. Last Button 2.Play / Pause Button 3. Next Button 4.MIST Button 5. LIGHT Button 6.1 Hour Timer Indicator 7. 2 Hours Timer Indicator 8. 4 Hours Timer Indicator 9. Continuous Mist Indicator 10. Mist Mouth 11.

  • Page 3: Operation

    OPERATION 1. Please remove the upper cover. /VOL+ /VOL- MIST LIGHT 2. Add the moderate amount of water (no more than 500ml) and a drop of essential oil into the water tank. /VOL+ /VOL- MIST LIGHT...
  • Page 4 3. Close the cover in the direction. /VOL+ /VOL- MIST LIGHT 4. Please connect the AC adapter to the DC jack at the base of the main body. /VOL+ /VOL- MIST LIGHT Note: If the amount of added water is over the max line, there will be less mist sprayed out.

  • Page 5: Using Guide

    USING GUIDE /VOL+ /VOL- MIST LIGHT MIST BUTTON: 1. Short press the MIST button the first time, the aromatherapy machine works for one hour with One Hour Timer Indicator lights up in orange and then turns off automatically. 2. Short press the MIST button a second time, the aromatherapy machine works for two hours with Two Hours Timer Indicator lights up in orange and then turns off...

  • Page 6: Light Button

    7. In the power-on state, press the MIST button for 1.5 seconds to adjust the concentration of spraying MIST. When shift into comparatively dense mist mode, the buzzer sends out 2 buzzing sounds; When shift into Mid cont mode, the buzzer sends out 1 buzzing sound.

  • Page 7: Next Button

    PLAY PAUSE BUTTON: 1. In the off state, short pressing or long pressing this button can open the machine. (When plug in, you hear a voice prompt “Power-ON” ) 2. In the power-on state, short press to pause music, short press again to play music.

  • Page 8: Troubleshooting

    TROUBLESHOOTING Is there enough water in the tank？ -Please add enough water but don't exceed the Can't maximum tick mark. tum on Is the AC adapter connected correctly? -Please unplug, check and re-plug correctly. Not enough water or too much water? -Add the right amount of water but don't exceed the maximum tick mark.
  • Page 9 Q: Why can't I smell anything? A: The intensity of scent from different essential oils may vary. Choose a strong scented oil and don't put the diffuser near the air conditioner, fan or window. Q: Can I turn the light off and just use the mist? A: Yes.
  • Page 10 PRECAUTION To prolong the life span of the diffuser, do not use mineral water. Do not exceed the maximum tick mark when filling water. If the diffuser runs out of water, it will shut off automatically. Please only use 100% essential oil with this diffuser. Low quality oil that contains chemicals, spices, or impurities may cause malfunction.

  • Page 11: Maintenance

    MAINTENANCE Please clean the product as following after using 5-6 times (or 2-3 days): Turn off the power, unplug the power cord, and remove the upper lid. Pour out all the remaining water in the tank. Put a few drops of neutral kitchen detergent into warm water and clean the product with a soft rag.

  • Page 12: Specification

    SPECIFICATION Dimensions 150×150×214mm Weight 464g Color Wood grain Input Power AC 100-240V 50/60Hz Output Power DC 24V 650mA Adapter Line Length 170CM The Amount of Mist 30-45mL/h Water Tank Capacity 500ml Spray Mode 1h /2h /4h / On Control Mode Mechanical Power Consumption 15-19W...

  • Page 13: Warranty And Support

    Damage resulted from misuse and abusive action. Damage resulted from chemical, fire, radioactive substance, poison, liquid. Damage resulted from natural disaster. Damage caused to any third party / person / object and beyond. Please do not return the product without seller / MUSON authorization.
  • Page 14 STATEMENT We can only provide after sale service for products purchased directly from MUSON or MUSON authorized distributor. If you have purchased from a different seller, please contact them for any exchange or refund request.
