- Page 1 ATIM Cloud Wireless Modbus PLC connector DINRSM / RS485 User Guide Concerned models: ACW/LW8-DINRSM ACW/SF8-DINRSM ATIM Radiocommunications www.atim.com Chemin des Guillets contact@atim.com 38250 Villard-de-Lans, France...
-
Page 2: Table Of Contents
ABLE ONTENTS Document version history ............................... 2 Disclaimer ....................................2 Trademarks and copyright ............................... 2 Declaration of compliance ............................... 3 Environmental recommendations ............................3 Environment Radio Technical specifications ................................5 Installation ....................................6 Positioning Connecting the modem Push button Interpreting the indicator lights Normal start-up behavior ................................ -
Page 3: Document Version History
ATIM. Trademarks and copyright ® ® ATIM, ACW ATIM Cloud Wireless and ARM Advanced Radio Modem are registered trademarks of ATIM SARL in France. The other trademarks mentioned in this document are the property of their respective owners. -
Page 4: Declaration Of Compliance
Declaration of compliance ® All ACW Atim Cloud Wireless products comply with the regulatory requirements of the R&TTE Directive (1999/5/EC), article 3: 1 SAFETY (Article 3.1a of the 1999/5/EC Directive) NF EN60950-1 Ed. 2006/A1:2010/A11:2009/A12:2011 (health) EN62479: 2010 (power <20mW) or EN62311:2008 (power > 20mW) 2 Electromagnetic Compatibility (Article 3.1b of the 1999/5/EC Directive) -
Page 5: Radio
General hazard – Failure to follow the instructions presents a risk of equipment damage. Electrical hazard – Failure to follow the instructions presents a risk of electrocution and physical injury. WARNING: do not install this equipment near any source of heat or any source of humidity. WARNING: for your safety, it is essential that this equipment be switched off and disconnected from mains power before carrying out any technical operation on it. -
Page 6: Technical Specifications
Technical specifications Dimensions 90 x 57 x 17.9 mm Antenna External via SMA connector -20°C to +55°C (operation) Temperature -40°C to +70°C (storage) Mounts to DIN rail Power supply 1x power supply, 10-30 V DC Frequency 865 – 870 MHz Power 25 mW (14 dBm) Sigfox: 100 bps... -
Page 7: Installation
Space requirements and mounting Dimensions indicated in mm. ‘Circuit-breaker’-style ACW DIN modems are mounted on a DIN rail. Installation c. Positioning This version was designed for installation in an electrical box made of PVC or metal. If the box is made of insulating material (PVC, ABS, fibreglass), you can also simply use a small ½... -
Page 8: Connecting The Modem
d. Connecting the modem Terminal blocks Name Description Input / Output Earth/Ground (Gnd) Earth Power supply between 10 V 10/30V Input (power supply) and 30 V Not connected Tx/BZ RS485 BZ Bidirectional/differential Rx/AY RS485 AY Bidirectional/differential Not connected Antenna (SMA) Before connecting the product to mains power, connect the antenna: either a ½... -
Page 9: Push Button
NOTE To configure the device, it must be connected to power at 10/30 V DC. c. Push button The push button located on the front panel of the housing can be used to initiate a Modbus/Radio cycle. This lets you test the Modbus configuration and radio connectivity. -
Page 10: Normal Start-Up Behavior
Normal start-up behavior GREEN When the device is switched on, after a brief delay, the light flashes rapidly for about ½ second to indicate that the device has started up correctly. The periodic frame is then sent out, based on the statement period specified GREEN in the settings. - Page 11 Frame period A complete radio cycle is composed of two phases: 1/ sending requests to one or several Modbus slave(s), 2/ broadcasting retrieved Modbus data via radio communication. During requesting phase, up to 49 Modbus request frames are sent through serial link to slave Modbus equipment, which return data requested by the ACW-DINRSM.
- Page 12 Therefore, you must configure the following parameters: Modbus function code The following function codes are available: Function code Name 0x01 Read Coils 0x02 Read Discrete Inputs 0x03 Read Holding Registers 0x04 Read Input Registers Concatenation with previous frame This parameter provides the option to not create a new radio frame and to include the result of the Modbus frame with the result of the previous Modbus/radio frame.
-
Page 13: Configuration Via Usb
b. Configuration via USB For a DINRSM with application software version Use ACW configuration tool version V3.0 or earlier V3.7.15 or later V3.2 or later V4.4.0 or later V3.3.5 or later V4.5.9 or later Download and install the configuration tool “setupACW.exe” at: https://www.atim.com/wp-content/uploads/documentation/CONFIGURATEUR/ACW/configurateur-acw.exe Connect the ACW-DINRSM to your computer with a micro-USB cable, then start the ACW configuration tool. - Page 14 Four major sections can be distinguished here. The ‘Serial parameters’ section is at the top left, “Other parameters” at the center left, the Modbus configuration section at the right and the debugging area at the bottom. Parameter settings for Radio and Modbus frames In the Modbus section at the right, you can add radio (network) and Modbus frames, add a Modbus frame to a radio (network) frame, edit a Modbus frame as well as delete and test Modbus frames.
- Page 15 Testing Modbus frames Before testing a Modbus frame, you must connect the ACW-RSM to your Modbus slave device. Next, configure the parameters for the serial link and click ‘Apply’ to apply the serial parameters. Create a Modbus frame by pressing ‘A’, clicking the ‘Add’ button or by right-clicking and selecting from the context menu.
- Page 16 Configuration example In this example, we have 3 radio frames with headers of 40, 41 and 90 plus 7 Modbus frames. Radio frame 40 contains 4 Modbus frames; radio frame 41 contains 2 Modbus frames; and radio frame 90 contains just one Modbus frame. The figure below shows the radio frames that will be sent out (if the Modbus slaves respond): Radio frame 40 Byte...
- Page 17 Radio frame 90 Byte 3, ..., 36 Values of the 17 registers Data 0x03 from frame 7 ATIM_ACW-DINRSM_UG_EN_V2.8...
-
Page 18: Transmitting Information On Iot Networks (Sigfox/Lorawan)
Transmitting information on IoT networks (Sigfox/LoRaWAN) a. Keep-alive frame This frame is sent to the network instead of the periodic frames if no Modbus frame is configured. Frame format: Byte Power supply voltage of radio Power supply voltage of radio Data 0x01 core on standby (millivolts –... - Page 19 The parameters of the Modbus frame are sent back to identify which frame failed. An error code is also included to tell you which error occurred, so that you can correct your configuration if necessary. The error codes are explained below: Error code Description...
-
Page 20: Receiving Information From Iot Networks (Sigfox/Lorawan)
Receiving information from IoT networks (Sigfox/LoRaWAN) You can use this feature if your product includes a compatible radio version. • Sigfox radio firmware: Version 5931 or later • LoRaWAN radio firmware: Version 2.3.3 or later The document ATIM_ACW-DLConfig_UG_EN.pdf explains how exchange frames work for this function. NOTE IMPORTANTE When you send the command to request the ACW configuration, several uplink frames will be sent. - Page 21 • 0x50 = 38400 bps • 0x60 = 57600 bps • 0x70 = 115200 bps Serial link parity – Byte 3 – bits 0 to 1 The possible values in byte 3 for these bits are: • 0x00: No parity. (default) •...
- Page 22 Statement Period parameter (Code 14) Size and Code (Byte 1) Value (Bytes and 3) 0x40|14=0x4e 0xYYYY The value (0xYYYY) is indicated directly in minutes ( low byte / LSB first). The default configuration and minimum value is 10 minutes (0x000a). The maximum value is 40320 minutes, i.e. 4 weeks. Modbus frame parameters (Code 30 to 61) These parameters are ‘buffered’...
- Page 23 Concatenation – Byte 1 – bit 7 This parameter is masked with the function code parameter to concatenate multiple registers from multiple Modbus frames in a single radio frame. The possible values in byte 1 for these bits are: • 0x00 = No concatenation or creates a new radio frame.
-
Page 24: Commands
b. Commands Restart To restart the ACW-DIN-RSM remotely, you must send it the following command: Byte 1 Byte 2 0x01 0x01 The ACW will restart and will not send a confirmation. About To obtain information about the ACW-DINRSM, you must send it the following command: Byte 1 Byte 2 0x01... - Page 25 Restore default parameter settings To restore the default parameter settings, you must send the following command: Byte 1 Byte 2 0x01 0x03 The ACW will return a confirmation in the following format: Description and value Byte 1 Response to command frames: 0x07 Byte 2 ‘Default settings’...
- Page 26 The ACW will return the version number in the following format: Description and value Byte 1 Response to command frames: 0x07 Byte 2 ‘Protocol version’ command: 0x07 Byte 3 Protocol version (LSB) Byte 4 Protocol version (MSB) Modbus request To achieve a Modbus request, you would need to send the below command: Byte 1 Byte 2 Byte 3...
- Page 27 Function code - Byte 5 The possible values for the function code are: − 0x01 = Function code 0x01, Read Coils. − 0x02 = Function code 0x02, Read Discrete Inputs. − 0x03 = Function code 0x03, Read Holding Registers. − 0x04 = Function code 0x04, Read Input Registers −...
- Page 28 The ACW will return a response to the "Modbus Request" command, as described : Description and value Byte 1 Answer to frames of command: 0x07 Byte 2 Modbus request command: 0x7F Byte 3..n Function Byte(s) including the reading of requested bits. The code number of Bytes turned back dealing with the number of multiples of 8 from the number of requested bits plus 1.
- Page 29 Example of commands Modbus request • Reading request of bits on the slave from bit Request: 0xc1 0x06 0x7F 0x01 0x01 0xd3 0x00 0x09 Answer: 0x07 0x7F 0bX 0b0000000X With X : value of the bit y • Reading request of registers on the slave from register...
-
Page 30: Troubleshooting
Troubleshooting a. The modem cannot be configured via USB or the configuration tool page does not refresh • Check whether the power supply is correctly connected to the modem • Check whether the light is flashing • Make sure that Windows Update is activated, the PC is connected to the Internet and driver installation has completed. -
Page 31: Technical Support
Technical support For any further information or technical question, you can open a ticket on our technical support dedicated webpage. ATIM_ACW-DINRSM_UG_EN_V2.8...
