Summary of Contents for Manley Langevin Series
- Page 1 MANLEY LABORATORIES, INC. OWNER'S MANUAL LANGEVIN STUDIO HEADPHONE SYSTEM MANUFACTURED BY: MANLEY LABORATORIES, INC. 13880 MAGNOLIA AVE. CHINO, CA. 91710 USA TEL: (909) 627-4256 FAX: (909) 628-2482...
-
Page 2: Table Of Contents
CONTENTS SECTION PAGE INTRODUCTION MAINS CONNECTIONS OPERATIONAL NOTES SPECIFICATIONS WIRING PIN LISTS / TECH INFO WIRING NOTES BLOCK DIAGRAM / INTERNAL LAYOUT WARRANTY WARRANTY REGISTRATION NOTES... -
Page 3: Introduction
SERVICING The user should not attempt to service this unit beyond that described in the owner's manual. Refer all servicing to Manley Laboratories. THANK YOU Congratulations on the purchase of the LANGEVIN STUDIO HEADPHONE SYSTEM. With this... -
Page 4: Mains Connections
MAINS CONNECTIONS Your unit has been factory set to the correct mains voltage for your country. The voltage setting is marked on the serial badge, located on the rear panel. Check that this complies with your local supply. The voltage changeover switch is located inside the unit in the middle of the PCB near the power transformer. -
Page 5: Operational Notes
OPERATIONAL NOTES SWITCHING ON The power switch and fuse are located on the remote power supply. Do not hot plug the station while the power is on. It is possible to get temporary contact of non-compatible pins while aligning the power connectors. - Page 6 Another typical CUE problem is leakage from the headphones into the mic. It can happen with quiet instruments and loud headphones. Leakage often is a problem with vocals and more so with harmony vocals. The usual fix is in the mix. We use gates and automation and phase reverse tricks and plenty of time to try to eliminate the leakage.
- Page 7 On the topic of hints - here's a few things to try sometime. Some singers and drummers have a real problem with headphones. If these artists are veteran stage performers they are probably more comfortable with stage monitors. You can set up speakers instead of headphones if you are careful and do it right.
- Page 8 OTHER HEADPHONE STATION TRICKS Another drum trick where these stations are useful is in the mix. We set up a snare drum in a live room without the rest of the kit. We place a pair of drum sticks about 4 inches apart across the rim. Then we put an Auratone facing down on the sticks.
-
Page 9: Specifications
SPECIFICATIONS SPECIFICATIONS: INPUTS: All inputs on 56 way ELCO/EDAC multi-pin connectors 1 - 4 -balanced line-level mono - 60 mm fader - pan pot 5 - 6 -balanced line-level stereo - 60 mm fader - switchable Mono, Stereo or Stereo Image Manipulation (SIM) - paralleled on 25 pin SUB-D connector Electrical - 40 Kohm input impedance -... - Page 10 PIN-OUT OF MULTIPIN CONNECTORS THE +4 BALANCED LINE INPUTS USE AN ELCO 56 CONNECTOR AND ROUGHLY FOLLOW STANDARD "ADAT" PINOUTS. STANDARD ADAT CABLES WILL WORK. OUTPUTS ARE PIN-OUT STANDARD BUT OF COURSE ARE NOT DESIGNED TO INTERFACE WITH A TAPE MACHINE. LOGIC SWITCHED MONITOR L...
-
Page 11: Wiring Notes
WIRING NOTES Help!... It hums when we plug in the inputs. Every studio should have several of those AC adapters that convert a 3 pin AC plug into a 2 pin plug. Try 'em. Resist the temptation to break off the ground pin on the AC cable. - Page 12 4) Most users do not get involved with the routing of control room mic to headphone stations in any tricky or involved way. Most simply use the built in CUE system of the recording console to feed a basic mix into the station's (stereo) input 6. This is sometimes the monitor mix and sometimes a basic headphone mix to which the musicians add a whole bunch more of themselves.
-
Page 13: Warranty
If you believe this to be a new unit then please contact the factory with the details of purchase. This warranty is provided by the dealer where the unit was purchased, and by Manley Laboratories, Inc. Under the terms of the warranty defective parts will be repaired or replaced without charge, excepting the cost of tubes. -
Page 14: Warranty Registration
Registration entitles you to product support, full warranty benefits, and notice of product enhancements and upgrades. You MUST complete and return the following to validate your warranty and registration. Thank you again for choosing to use Manley Laboratories. MODEL ____________________ SERIAL No.
