IDX Motix IM-220G/98G User Manual

Rechargeable Li-ion Battery Pack
IM-220G/98G
Ver:C
Congratulations on your purchase of this product. Please read this user manual carefully.

Warning

Keep in mind the following precautions to avoid fire and other safety hazards ！
Do not use battery in fire or hot places to prevent overheating,
●
cracking and other hazards.
Please do not pierce the battery shell or try to open the shell and
●
decompose the battery.
Do not use battery beyond charge, discharge and storage
●
environment temperature.
Do not charge the battery in the car or in direct sunlight.
●
Do not use damaged battery.
●

Description of appearance

Caution
Fully charged battery will discharge naturally and please use it as
●
soon as it gets charged.
The battery may become warm in use or while being charged.
●
This is normal.
Never expose the battery to temperature above 60℃.
●
Keep the battery terminals clean and never short-circuit the
●
battery terminals.
When stored for a long time, please keep the battery power
●
between 50% and 90%.
Battery will automatically enter the sleep mode if rest in 10 days,
●
the output will be shut off. Press the button to restore output.

Features

High performance rechargeable lithium ion battery, no memory
●
effect.
OLED screen display battery capacity and remaining running time.
●
Built in multiple control circuit, to protect the battery all-round
●
regarding temperature, voltage and current.
D-tap DC output, to power the camera and other equipment
●
simultaneously.
USB 5V/2A output, which can be used to charge mobile phones,
●
tablets and other portable devices.
USER MANUAL
I DX S y s t e m Te c h n o l o g y, I n c .
●
●
●
●
Fig 1: IM-220G
Do not squeeze the battery shell which may cause physical damage.
Make sure the power-consuming equipment(s) meet the battery
specifications.
Use MOTIX charger or IDX recommended charger to charge the battery
to avoid overheating or break.
Keep out of the reach of children.

Charging

After the battery is plugged into the charger, a lightning icon will
●
appear in the OLED to indicate that it enters the charging state.
The battery can be charged at a temperature range of 0~40℃, but
●
we recommend charging at a temperature range of 10~30℃ to
ensure the best performance of the battery.
During battery charging, press the button to turn on the USB
●
output.

Discharging

The battery can discharge at a temperature range of -20℃~50℃,
●
but it is suggested to discharge at a temperature range of -10~40℃
for the best performance of the battery.
During the battery discharge, ,OLED displays the remaning time
●
and turns on USB output after pressing the button.Press the
button briefly to switch to display the percentage of battery power,
and press the button long to display the battery cycle times from 0
to 999.
In low temperature, the internal resistance of the battery will
●
increases, the discharging time will be shortened, and the load
may be automatically cut off when the load is heavier.
The USB output will shut off if the load is too heavy, press the
●
button to restore.
Service Center Location
IDX System Technology
24422 S Main St Suite #502
Carson,CA 90745
TEL:1-310-328-2850
www.idxtek.com
① D-TAP socket
② Button
③ USB socket
④ OLED screen
⑤ Electrode interface
⑥ Gold-mount shape lock
