Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before using the product. Please keep instructions for future reference.
Warranty
• This Electronic Dimmer is covered by a 12 month warranty. The warranty is from date of purchase, not the date of
installation.
• If the Electronic Dimmer is not assembled and installed by a licensed electrician the warranty will be void.
• Please retain proof of purchase and evidence of installation by a licensed electrician for any warranty enquiries.
• Warranty will be void if there is any damage due to improper usage or modification to the Electronic Dimmer.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void warranty.
Installation Requirements
•
Must be installed by a licensed electrician and in accordance to AS/NZS3000 (the latest edition).
•
This LEDlux LED Dimmer is designed for use with LEDlux brand family dimmable LED lighting equipment.
Where the loads are on the same electrical circuit, it must be Mains 240V dimmable LED retrofit luminaries
which have a dimmable LED driver. (Note: A dimmable electronic transformer is not considered to be a
dimmable LED Driver).
•
Problems encountered when using other types of dimmable 240V luminaires NOT recommended in this
installation guideline are NOT covered by the Lucci LEDlux guarantee.
•
Do not exceed the rated output load listed below:
- For Mains 240V LEDlux dimmable LED globes and downlights: Max. 200W;
- For Mains Halogen globes: Max. 200W;
- ELV halogen with dimmable transformer: Max. 200W
•
Not suitable for use with ferromagnetic transformers.
•
Do not exceed rated power input specification.
•
This product is suitable for indoor use only.
Installation Preparation
Before carrying out the installation the following must be considered.
- Wall plate or wall mounting box (not supplied) will be required for installation pending on where the dimmer will be
located e.g. behind a wall or surface mounted.
- A wall switch is required (not supplied) when using with this dimmer to provide ON/OFF and isolation to the
electrical lighting equipment circuit. The dimmer MUST not be used as an ON/OFF switching device. Only use as
a dimmer.
- Ensure the power to the electrical circuit is switched OFF.
- All electrical wiring connection & disconnection must be in accordance with Australian & New Zealand wiring rules
e.g. AS/NZS 3000 (the latest edition).
CAUTION: For your safety, this LEDlux LED electronic dimmer must be installed by a licensed electrician.
1 | P a g e
Lucci LEDlux – Electronic LED Dimmer
SKU# 290998
Rated Voltage 220-240V~ 50/60Hz
V e r s i o n 3 . 0 ( 2 0 1 9 / 0 8 )
