- Page 1 Hi-Vision TV Box High Resolution TV BOX OWNERS MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Content …………………………………………………….……..…………. 1 About The TV BOX……………………………………………………………………...… 2 Front & Rear Panels…….……………………………………………………………….…3 Illustration of Basic Connection.…………………………………………………..………4 Procedure of Set Up.……………………………………..……………………………… 5-7 Remote Controller Description………………….…………………………….…………...8 Operation……………………………………………………………….…………….……9-12 Specification ……………………………………………………..…………………………13 Trouble Shooting …………………………………………………………………..………14 User Information ………………………………………………………………..………….14 PACKAGE CONTENT Before the installation, please check the package of content. ●... -
Page 3: About The Tv Box
ABOUT THE TV BOX *For the best performance of this product, we strongly recommend you to read this operation manual thoroughly and keep this manual properly for further reference Preface: The imaging method of the CRT or LCD monitor is quite different from the traditional TV Set. -
Page 4: Front & Rear Panels
FRONT & REAR PANELS Front Panels: Power Semi-transparent cover Input CH+/- Volume+/- Audio Input Input VIDEO Input S-VIDEO Rear Panels: CABLE IN F (or IEC) connector for ANTENNA or CATV signal input VIDEO OUT Video output (only for TV) SPEAKER 3.5mm Stereo connector for AUDIO IN connecting to Speaker... -
Page 5: Illustration Of Basic Connection
ILLUSTRATION OF BASIC CONNECTION Front View DVD/VCD GAMECUBE HiFi-VC Camcorder X-Box Back View Antenna or CATV Audio Cable Sound Card Audio Cable Speaker VGA Cable VGA Card VGA Cable Monitor or LCD Power Adaptor Back Panel of a PC *All brand names and trademarks stated or illustrated are related to their respect owners. -
Page 6: Procedure Of Set Up
SET UP PROCEDURE (1.) Connection to LCD or CRT ( In This section, after finishing the installation you will have a TV function only) a. Take the TV BOX main unit, let it upright or horizontally placed beside your CRT or b. - Page 7 (2) Connection to Computer ( In this section, after finishing all the installation, you will have a TV function and you can also use your Take the TV BOX main unit, let it upright or horizontal placed beside your CRT or Connect the Antenna or CATV cable to the “CABLE IN”...
- Page 8 (3) Connection to TV Game Console, V8 or another Video Appliances, Please follow the previous procedure first ( If your Video Source is only RCA Output, please follow the steps) a. Connect the RCA connector to the output of your TV Game, DVD or VCR (Please note the connection cable should be color coded, yellow for Video, White for Audio R, Red for Audio L) b.
-
Page 9: Remote Controller Description
REMOTE CONTROLLER DESCRIPTION Illustration of remote controller Power TV/PC mode selection MUTE: Mute key for audio muting Numeric Key: 0~9 PIP: Start the PIP 1--: when the function, please be channel number noticed this key only upto 100, you need valid when the TV to press this key first box is in the PC... -
Page 10: Operation
First time use(Watch TV on your monitor) There is no channel plan inside this box, when you finished all the connections and power on the TV box, at this time, TV box is under TV mode. Please use channel scan to scan all the channels available in your area. Step 1: press the “MENU”... - Page 11 Hue: change the color tone of the TV box Color Temperature: change the color temperature of the TV Picture mode: There are 4 selections, normal/user/bright/soft , to Change the picture mode. 2. Search : Auto scan 1. Picture 2. Search 1.Auto Scan Fast Scan 3.
- Page 12 4. Setup: System settings 1. Picture 1.OSD setting Language English 2. Search Bright Normal/Bright/Gloom 3. Audio Normal/Heavy/Light 4.Setup Background Gradual/Normal/Mix 5. Time 2.Display mode Signal source TV / AV /SV 6. Access. Colour system AUTO/PAL Monitor type 4:3 / 16:9 / 16:10 800*600 60/75Hz 1024*768 60/75Hz 1280*1024 60/75Hz...
- Page 13 NOTE: wrong setting will cause serious distortion on image. Monitor Type: Change the monitor aspect ratio, there are 3 selections, 4:3/16:9/16:10 Display ratio: Change the resolutions of the VGA output, there are 13 selections, 800*600 60/75Hz 1024*768 60/75Hz 1280*1024 60/75Hz 1600*1200 60Hz 1366*768 60Hz 1920x1080 60Hz...
-
Page 14: Specification
SPECIFICATION Item Specification CATV/TV Input 75 Ohm F female or IEC female Frequency range 48~862MHz Video Input Video, S-Video Audio Input (Signal Source) Stereo RCA Left, Right Audio Input (PC) 3.5mm Stereo VGA In HD-15 Female 5 VDC 1A Power- AC/DC adaptor UL-listed for USA, CE certified for Europe VGA Output HD-15 Female... -
Page 15: Trouble Shooting
TROUBLE SHOOTING 1.No picture a. The connection could be not correct, please contrast the connection with illustration. b. Check the power plug whether it is firmly connected and the supplied voltage meets the adapter rating. c. Make sure that the selected mode is the same as input signal, and then perform AUTO SCAN again.
