Summary of Contents for Renogy RSHSRZ02P
- Page 1 VERSION A0 Smart Relay (Zigbee) User Manual...
- Page 2 Thanks to its built-in Zigbee 3.0 communication module, Smart Relay works with Renogy ONE to create a Zigbee LAN where you can control other connected devices intelligently and enable scene synchronization. This User Manual contains instructions for Smart Relay. Please read the User Manual carefully before using the device.
- Page 3 WARNING Do NOT disassemble Smart Relay because no parts inside it require maintenance or repair. Smart Relay can only be powered by a DC power supply (8V-30V); otherwise Smart Relay will be damaged. Risk of electric shock! Make sure the power supply is powered off...
-
Page 4: Product Overview
Product Overview Wiring holes Function Smart Relay power supply hole, connecting to the positive/negative V+/V- terminal of a DC power supply (8V-30V). Connecting to a push button switch to turn devices on or off. Connecting to a rocker switch to turn devices on or off. - Page 5 LED light Button Part Function It displays the current operating status of Smart Relay. Flashing: Restoring to factory settings and waiting for network LED light distribution, flashing for 3 minutes. On: Relay status-ON. Off: Relay status-OFF.
-
Page 6: Wiring Diagram
Part Function Press: Power on/off Smart Relay. Button Long press for 5s: Factory reset. Wiring Diagram AC Load Positive Negative Rocker switch Push button switch AC load Power Power Supply Supply... - Page 7 WARNING Connect the AC Power Supply to OUT/IN only; otherwise Smart Relay may be damaged. The input voltage of AC Power Supply shall not exceed 250 V. For an AC load, operating voltage: ≤ 250 V; operating current: ≤ 16 A. You can choose to connect your switch(es) to either, neither, or both of S1 and K1 to your circuit on demand.
- Page 8 DC Load Positive Negative Rocker switch Push button switch DC load Power Supply WARNING The input voltage of DC Power Supply shall not exceed 30 V. For a DC load, operating voltage: ≤ 30 V; operating current: ≤ 16 A.
-
Page 9: Factory Reset
Add Smart Relay (Zigbee) to Renogy ONE. Smart Relay should be used in association with Renogy ONE. For more detailed instructions, please refer to the User Manual of Renogy ONE. Factory Reset Method 1: Long press the Button for 5s until the LED indicator flashes. -
Page 10: Technical Specifications
Technical Specifications Parameter Value Model Name RSHSRZ02P Zigbee IEEE 802.15.4 2.4GHz Power Supply 8-30V DC Load 250V AC/30V DC, 16A Max Operating -20°C-40°C (-4°F-104°F) Temperature Operating 0-90%RH Humidity 20 x 40 x 44 mm Dimensions (0.79 x 1.57 x 1.73 in) -
Page 11: Maintenance
Make sure that Smart Relay is in normal state. Ensure there is no any corrosion, insulation damage, or discoloration marks of overheating or burning. Technical Support For additional support, contact the Renogy technical support team through renogy.com /contact-us. Have the following information available when contacting Renogy. - Page 12 User Manual. Renogy is not responsible or liable for the failures, damages, or injuries resulting from repair attempted by unqualified personnel or improper installation and operation.
- Page 13 Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
- Page 14 "Contact Us". Renogy reserves the right to change the contents of this manual without notice. Join the Renogy Power Plus Community by downloading the DC Home App. Find your e-warranty here, and more.
