Page 1: Table Of Contents
10. Certification and EU Declaration of Conformity 11. Troubleshooting 12. Spare Parts & Accessories NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 2: Section 1 - Product Information
NEOS 30 is comprehensively better than the market leader at all distances. Frequency and Long Range Static Neutralisation It is useful to repeat these notes, as they are essential for understanding the benefits of the NEOS 30 OEM and where it fits into the NEOS range.
Page 3: Key New Features
2. KEY NEW FEATURES The essential and unique feature of a NEOS 30 OEM Bar is that it receives a signal from the PLC of the machine which indicates the distance between the charged material and the Bar. This tells the NEOS 30 OEM to adjust the frequency to the optimal setting for that distance.
Page 4 Winders and unwinders are found on hundreds of different types of production machinery. NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 5: Position In The Neos Range
4. WHERE DOES NEOS 30 OEM FIT INTO THE NEOS RANGE? NEOS 30 OEM does not replace the existing NEOS 30 Bar, but provides a powerful new ionisation system to cope with the difficult applications where the target distance changes substantially.
Page 6 PLC. With the same M12 x 5 pin connector. In all other ways the NEOS 30 OEM is externally the same as the standard NEOS 30: • same compact profile (half the size of the Simco ThunderION) •...
Page 7: Performance
The NEOS 30 OEM has slightly better performance to the M1, M2 and M3 manual settings on the standard NEOS 30. This is because, although the frequencies may be similar, the NEOS 30 OEM changes gradually, not in steps of 0.5 Hz, 1.0 Hz, 1.5 Hz etc.
Page 8: Section 2 - Technical & Installation
SECTION 2 - TECHNICAL & INSTALLATION 1. INTRODUCTION This manual applies to the NEOS 30 OEM Static Eliminator Bar supplied from December 2018. It is essential that you read and understand the complete manual before installing and using this equipment. This is important for safety and for warranty cover.
Page 9: Safety
It is for this reason that the signal cable must not be removed or reconnected when the bar is powered. NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 10: Use
3. USE The NEOS 30 OEM is a long range static eliminator designed to neutralise electrostatically charged surfaces at distances between 200mm and 1500mm. A signal on the 4-20mA current loop input allows the bar frequency to be varied as distance to the charged material varies, such that optimal electrostatic neutralisation can occur.
Page 11: General Specification And Dimensions
Environmental: 0-55 °C Max. Dry: max 70% RH, non condensing. Length: NEOS 30 OEM available at 600 mm, then 750 mm to 5000 mm in 250 mm steps. Weight: NEOS 30 OEM - 3.6 kg/m. Mounting: M6 x 40 mm Fixing slides and Flange Nut.
Page 12: Positioning
NEOS 12 L Area to be free of all ground references NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk W www.fraser-antistatic.com...
Page 13: Operation & Control
0 V / GND, connected internally to power supply 0 V *Pin 2 numbered pin 4 by some cable suppliers. NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 14 0 V & Earth Black Attention Grey or Green / Yellow Disable NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk W www.fraser-antistatic.com...
Page 15 Do not connect the open collector outputs directly to 24 V. NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 16 ±0.01mm WWW.FRASER-ANTISTATIC.COM PROJECTION MATERIAL DRAWING No. TEL: 44-(0) 1398 331114 0-100mm ±0.25mm Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK FAX: 44-(0) 1398 331411 100-500mm ±0.4mm THIRD ABOVE 500mm ±0.75mm ANGLE T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 17 FAX: 44-(0) 1398 331411 100-500mm ±0.4mm THIRD ABOVE 500mm ±0.75mm ANGLE NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk W www.fraser-antistatic.com...
Page 18 Ground. With this optional supply an interface cable is required to access the remote monitor feature. NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 19 DISABLE signal active (3 - 28 V) IONISATION NOT ACTIVE IN THIS STATE NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk...
Page 20: Mechanical
Cleaning is the only maintenance required. Dirt around the emitters will reduce efficiency and result in unsatisfactory performance. Our Fraser cleaning kit (Part Number 81220) is ideal for use, alternatively a toothbrush or nail brush can be used. Do not use a wire brush as this could damage the Bar.
Page 21: Certification And Eu Declaration Of Conformity
Check positioning of Bar & Green Bar incorrectly positioned Check emitters for damage NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk W www.fraser-antistatic.com...
Page 22: Spare Parts & Accessories
10 m cable M12 female, bare ends. 81202 90º socket. NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk W www.fraser-antistatic.com...
Page 23 Spare NEOS 20 & 30 Emitter & Key kits 342022 Fraser Cleaning Kit 81220 NEOS 30 OEM-DM-Iss.2 Fraser Anti-Static Techniques, Scotts Business Park, Bampton, Devon EX16 9DN, UK T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk W www.fraser-antistatic.com...
