- Page 1 SVF144 Series SerVICE MANUAL Ver.2 2013J revision History revision History • Design and specifications are subject to change without notice. PerSOnal cOMPuTer 9-890-973-02...
- Page 2 1. Obey precautionary markings and battery pack of equipment or in both the operat- instructions Sony, VAIO and CLIE are trademarks or regis- ing and the service instructions. tered trademarks of Sony. Microsoft, Windows, After servicing, inspect to make sure that all...
- Page 3 2. FraMe HarneSS DiaGraM ............... (to 2-1) cHaPTer 3. eXPlODeD VieWS Screws S-1 ................................3-2 Palmrest • History of the changes is shown as the “Revision P-1 ................................3-3 History” at the end of this data. Mother Board M-1 ................................3-4 Bottom B-1 ................................3-5 Optical Drive D-1 ................................3-6 H-1 ................................3-7 L-1 ................................3-8 L-2 ................................3-9 Accessories A-1 ................................3-10 (to 3-10) Sony Confidential - 3 - SVF144 Series (9-890-973-XX)
- Page 4 SD Card Audio CODEC SPI ROM ALC233-CG G Sensor Lid Switch LIS331DLHTR NPCE985L Power LED Button PS2/SMBUS Charge LED ASSIST# Click Pad HDD Status LED Power SW Caps Lock LED Num Lock LED Back Light Keyboard Sony Confidential SVF144 Series (9-890-973-XX) (END)
-
Page 5: Frame Harness Diagram
USB 2.0 FFC NFC-MB FFC MB-USB USB 2.0 FFC CP-MB NFC MODULE NFC MODEL BATTERY BOTTOM BOTTOM CLICK PAD FROM BOARD TO CONNECTOR (DIRECT CONNECTION) HARNESS (CONNECTOR AT BOTH END) HARNESS (SOLDERED AT ONE END) BUTTON Sony Confidential SVF144 Series (9-890-973-XX) (END) -
Page 6: Exploded Views
CHAPTER 3. EXPlodEd ViEWS Section Page Palmrest Screws S-1 ..................3-2 Palmrest P-1 ..................3-3 Mother Board M-1 ..................3-4 Bottom B-1 ..................3-5 Optical Drive D-1 ..................3-6 Mother Board H-1 ..................3-7 L-1 ..................3-8 L-2 ..................3-9 accessories A-1 ...................3-10 Bottom Sony Confidential SVF144 Series (9-890-973-XX) - Page 7 S-1 Screws M1.6XL3 M2XL2.5 M2.6XL8 M2XL5.5 M3XL3.5 M2XL3 M2XL4 M2XL2 M2XL2 M2XL1.7 M2XL8 M2XL5 M2XL3 Black Silver Black Black Silver Black Silver Black Black Black Black Black Black Sony Confidential SVF144 Series (9-890-973-XX)
- Page 8 P-1 Palmrest L-1/2 L-1/2 Back Light L-1/2 L-1/2 KB Model Model Sony Confidential SVF144 Series (9-890-973-XX)
- Page 9 ( 1) L-1/2 L-1/2 L-1/2 L-1/2 Back Light KB Model Memory x 2 Model (● 1) When heat sink is removed from CPU, clean off thermal grease and put the Ref. No. 306. Sony Confidential SVF144 Series (9-890-973-XX)
- Page 10 Sony Confidential SVF144 Series (9-890-973-XX)
- Page 11 Sony Confidential SVF144 Series (9-890-973-XX)
- Page 12 H-1 Hdd Sony Confidential SVF144 Series (9-890-973-XX)
- Page 13 1000 1005 1001 1002 1004 1009 1008 M-1 M-1 101 1 1003 100 6 1016 101 3 1016 1016 1012 1017 1007 1015 1014 1016 Sony Confidential SVF144 Series (9-890-973-XX)
- Page 14 Touch 1100 1001 1005 1002 1109 1109 P-1G 1104 1101 1110 1006 1110 1107 1112 1110 1106 1103 1003 1112 1013 1102 1110 1108 1015 1007 1111 1105 Sony Confidential SVF144 Series (9-890-973-XX)
- Page 15 2005 2009 2013 2017 AC Adaptor Power Cord Power Cord Power Cord Power Cord 2002 2006 2010 2014 2018 Battery (VGP-BPS35A) Power Cord Power Cord Power Cord Power Cord 2003 2007 2011 2015 Power Cord Power Cord Power Cord Power Cord 2004 2008 2012 2016 Power Cord Power Cord Power Cord Power Cord Sony Confidential 3-10 SVF144 Series (9-890-973-XX) (END)
- Page 16 SVF144 Series This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. English 2013JQ00-1 © 2013 Sony Corporation Sony corporation 9-890-973-02 Published by Sony Corporation VAIO & Mobile Business Group - 16 - CS & Quality Div. VAIO Global CS Dept.
- Page 17 History Suffix Ver. Date contents QM no. Ver.1 2013.08.30 First Edition Ver.2 2013.10.23 [CHG] page 3-3, page 3-8, page 3-9, [ADD] page 3-9 <Remarks> [Sony Confidential] SVF144 Series (9-890-973-XX)
