Formax FD 452 Operator's Manual

Envelope opener

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

FD 452

Envelope Opener

Operator Manual

Second Edition

4/2022

Table of Contents

Need help?

Do you have a question about the FD 452 and is the answer not in the manual?

Questions and answers

Summary of Contents for Formax FD 452

Page 1 FD 452 Envelope Opener Operator Manual Second Edition 4/2022...
Page 2 MINUTES TO SET UP AND DISCOVER Overview of the envelope opener 1. Power cable 2. Extension arm 3. Power switch 4. Transport rollers 5. Pressure arm 6. User’s guide 7. Catch tray 8. Basic unit 9. Counter The power cable and user’s guide are delivered with the basic unit.
Page 3 MINUTES TO SET UP AND DISCOVER Installation of the envelope opener 1. Place the envelope opener on a firm, level surface. 2. Lift the right side of the basic unit in order to place it on the two pins of the catch tray.
Page 4 RUNNING A JOB 1. Switch on the envelope opener (power switch on the rear side of the unit). 2. Sort out any unsuitable mail pieces (e.g. plastic bags and envelopes that are thicker than 4 mm, or made from synthetic materials).
Page 5 RUNNING A JOB Use the indicators on the letter supporting surface for the thickness of the stack of envelopes. The maximum thickness is determined by the envelope size. Do not process more envelopes than indicated in one batch. 6. Press the green button to start the process. 7.
Page 6 SAFETY Before switching on your letter opener, please read this document and keep it near the machine as a reference. The letter opener complies with standard safety regulations for office equipment of this type. Before operating it, read the following tips to assure safe operation: Carefully follow the instructions for installation and operation •...
Page 7 TROUBLESHOOTING PROBLEM SOLUTION Apply a slight amount of pressure to the The letter opener pressure arm or stack of envelopes until the does not feed letters are fed again one by one. letters into the cutting unit. Envelopes are 1. Remove the stack of letters, which are not jammed in the jammed, from the feeder.
Page 8 MAINTENANCE AND SPECIFICATION Maintenance Periodically, clean the feed rollers with a moistened cloth or a cleaning liquid that is recommended by your dealer. Specification Dimensions Basic unit with catch tray Length: 825 mm (32.5") Depth: 388 mm (15.3") Height: 230 mm (9.1") Weight approximately 7 kg (15.5 lb) Power source...
