- Page 1 CARRIER CHAS5 VERTICAL ECONOMIZERS I/O/M MANUAL PD 11/04/2021 - v 1.00 PN IOM-0038-CHAS5V...
- Page 2 Table of Contents Carrier Economizer Description............3 Chassis 5 Vertical Submittal............... 4 Chassis 5 Vertical Install..............5 Additional Install Notes ................6 For information on iAIRE’s Economizer Controls Package, please refer to IOM-0014 iAIRE, LLC iAIRE Carrier Economizers I/O/M...
- Page 3 HVAC system by up to 2/3 and will improve indoor air quality. This reduction in system operation creates on-going utility savings. Payback on capital equipment costs with an iAIRE economizer can be realized in fewer than three years. These packages are designed to work directly on existing rooftop HVAC systems.
- Page 4 Economizers with Indoor Air Quality control are Title 24 compliant by meeting section 120.2(i) for the required controls and the efficiency requirements in 140.4(e). They also meet California ozone emissions requirements to be CARB certified. iAIRE, LLC | 2100 Consulate Drive, Suite 102, Orlando, FL 32837 SUB-0024-CHAS5V PD 09/15/2021 - v 1.00...
- Page 5 8. Refer to page 5 in IOM-0014 Economizer Controls Installation Manual for installation of the various sensors and actuators. Connect wires according to the wiring diagram on page 8. 9. Slide the filter access door back into the place above the economizer. iAIRE, LLC iAIRE Carrier Economizers I/O/M...
- Page 6 2. Ensure that equipment transformer is sized to handle the extra load of the economizer and actuator. 3. When using a heat with defrost feedback, add an isolation relay between O and C. (Field provided and installed). iAIRE, LLC iAIRE Carrier Economizers I/O/M...
