NEXTAV BTH-600R ESChat User Guide
Manual
Enter Pairing mode:
a. Audio pairing mode, turn on BTH-600R press Power/pairing button for 6 seconds. Blue/Red is flashing find "BTH-PTT" on your cellphone and pair it.
b. PTT pairing mode. After audio paired, press PTT button for 10 seconds then release. Find "bluPTT" on your cellphone and pair it.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BTH-600R and is the answer not in the manual?

Questions and answers

Summary of Contents for Nextav BTH-600R

  • Page 1 Enter Pairing mode: a. Audio pairing mode, turn on BTH-600R press Power/pairing button for 6 seconds. Blue/Red is flashing find "BTH-PTT" on your cellphone and pair it. b. PTT pairing mode. After audio paired, press PTT button for 10 seconds then release. Find "bluPTT" on your cellphone and pair it.
  • Page 3 How to use BTH-600R Power S/W long held( >= 1sec) Device on Power S/W long held( >= 2.5sec) Device off Power S/W long press >6sec Enter pairing mode from power off CELL short press Answer incoming call...
  • Page 4 VOL- short press Volume down VOL- long held( >=0.8sec) Volume down continuously BTH-600R State and LED Flashing Pattern statement LED state Blue led on : 2 sec , off : 1 sec , repeat All profiles are standby but not connected with any Cellphone device yet.
  • Page 5 Red led On Battery Charging Red led Off Battery Full Screenshot on cellphone POC setting The audio device name could be "BTH-PTT" or "BTHR-PTT"...
  • Page 9 A. Change BTH-600R pairing to a new phone: ...1. In phone A, forget(un-pair) the BluPTT/BTHR-PTT in "Setting" -> "Bluetooth" ...2. Turn on BTH-600R, make sure it is NOT connected to any phone..3. Press PTT button for 10 seconds then release (like in PTT Pairing process).

  • Page 10: Specification

    BTH-600R Specification Specification <Product Descriptions> Heavy duty speaker microphone for POC APPs. Volume control buttons, cell phone answering / hanging up button, and PTT button are built in. Embedded 3.5mm jack for external earphone. Built-in Micro USB for charging. <Specification>...
  • Page 11 HSP / HFP / A2DP / AVRCP profile supports Speaker Output: 2W PTT function: built-in Talking Range: Bluetooth class 2, 10 meters Display LED: Blue and Red DC Input: 5 Vdc (std.) DC Current: 25 mA (Average) Battery: 1000mAH, BL-5C replaceable Talk Time: 40 Hours Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 12 including interference that may cause undesired operation. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting...
