RTA SICILIA MLM 3330 Assembly Instructions Manual

RTA SICILIA MLM 3330 Assembly Instructions Manual

For countertop with left sink

Advertisement

Quick Links

15
INSTALACIÓN A LA PARED

FIXING THE CABINET TO THE WALL

* Herramientas
NO incluidas/
Tools not
included
Utilizar una broca
de 5/16" para hacer
las perforaciones
en el muro/
Use a 5/16" drill bit
to drill the wall.
16,2
28,8
28,8
6,38
11,34
11,34
* Centímetros / Inches
Al finalizar el ajuste, cubra
las cajas con las tapas
adhesivas/ After tightening all
the panels, cover the minifix
cams with the adhesive caps.
Tornillo 2" +
Chazo Mariposa/
Drywall Screw +
Wall Anchor
30,2
32
14
11,89
12,6
5,51
Al terminar de armar, desprenda
los adhesivos (en caso de que
queden residuos de pegamento,
limpie la superficie con alcohol) /
After finishing the assembly, take off
the adhesives. (In case of glue
residues, wipe them with alcohol)
8,5
3,35
Alto/
Height:
60 cm /
23,62 in
Ancho/
Width:
150 cm /
59,06 in
Fondo/
Depth:
33,5 cm /
LOTE No:
By:
TEL (572) 691 17 00
PBX (572) 695 91 81
CALI - COLOMBIA
www.rta.com.co
INSTRUCCIONES DE ENSAMBLE
ASSEMBLY INSTRUCTIONS
13,19 in
PARA MESÓN CON POZUELO IZQUIERDO
FOR COUNTERTOP WITH LEFT SINK
MUEBLE SUPERIOR
COCINA 1.50 SICILIA
/Sicilia Kitchen Wall Cabinet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SICILIA MLM 3330 and is the answer not in the manual?

Questions and answers

Summary of Contents for RTA SICILIA MLM 3330

  • Page 1 PBX (572) 695 91 81 After finishing the assembly, take off the panels, cover the minifix COCINA 1.50 SICILIA the adhesives. (In case of glue CALI - COLOMBIA cams with the adhesive caps. residues, wipe them with alcohol) www.rta.com.co /Sicilia Kitchen Wall Cabinet...
  • Page 2 Do not drag thefurniture. Lift it between two people. BISAGRA VIDRIO/ Glass Hinge HERRAJES BÁSICOS PARA MUEBLES RTA BASIC HARDWARE FOR RTA FURNITURE 3. Separe los herrajes para 1. Abrir la caja del mueble facilitar su identificación y buscar la bolsa con los...
  • Page 3 RECOMENDACIONES DE ENSAMBLE ASSEMBLY RECOMENDATIONS El buen funcionamiento del mueble depende de un adecuado ensamblaje An excellent furniture´s performance relies on a solid and a suitable assembly. MINIFIX / CONNECTOR - DOWELS 180° PDC/PIC Entrepaño móvil PIEZA U. Sistema de unión compuesto por un perno (A) y una caja minifix (B). Bisagra Parche (1) Se inserta la caja minifix dentro de la perforación ubicada en la cara de la pieza, la flecha debe apuntar siempre a la dirección de la perforación por donde entrará...
  • Page 4 HERRAJES PARA ARMADO ASSEMBLY HARDWARE Tapa Adhesiva Tarugo/ Perno minifix/ Minifix/ Minifix/ Fluted Dowel Pin Spreading Bolt Minifix Cams Cover Caps Tornillo 2 1/2" + Tornillo de Ensamble 2"/ Tornillo Lámina/ Bisagra Parche/ Chazo Mariposa/ 2" Drywall Screw Sheet Screw Full Overlay Hinge Refuerce los fondos Drywall Screw+...
  • Page 5 HERRAJES PARA ARMADO ASSEMBLY HARDWARE Tornillo Ensamble/ Drywall screw 2" Soporte entrepaño/ Bisagra puerta Tiradera puerta Vaivén Magnético Shelf Support de vidrio/ de vidrio/ (incluye tornillos) / Glass Door Hinge Glass Door Handle Magnetic Touch Latch Perfil en H/ Puerta de Vidrio/ H Profile Glass Door TENER PRECAUCIÓN AL ABRIR LA BOLSA DE HERRAJES PARA NO EXTRAVIAR NINGUNO.
  • Page 6 PIEZAS DE ARMADO ASSEMBLY PARTS Girar 180° / Rotate 180° perfil en H FM x2 Vidrio Vidrio ANTES DE EMPEZAR A ARMAR EL MUEBLE LEA DETENIDAMENTE LAS INSTRUCCIONES. SE RECOMIENDA ARMAR EL MUEBLE SOBRE LA CAJA O SOBRE UNA SUPERFICIE LISA Y CUBIERTA, Deslice los fondos dentro PARA NO RAYARLO / BEFORE STARTING TO ASSEMBLE THE CABINET, CAREFULLY READ THE del mueble / Slide the...
  • Page 7 *(Herramientas NO incluidas) *Tools NOT Included PI PD Tornillo Ensamble/ Drywall screw 2"...
  • Page 8 SE RECOMIENDA ARMAR EL MUEBLE ENTRE DOS PERSONAS / IT IS RECOMMENDED TO ASSEMBLE THE PRODUCT BETWEEN TWO PEOPLE VOLTEAR Soporte bisagra parche VOLTEAR VOLTEAR...
