Essentials EL00121 Quick Manual

PIR SENSOR ALARM
PIR Alarm with IR Key Fob Activation Product Code: EL00121

Introduction

A remote control operated PIR alarm which uses motion detection to alert users of movement by
sounding a powerful 105dBs alarm.

Contents:

1 x PIR Alarm Unit
2 x Remote Controls with Keychain (20m line of sight range)
1 x Fixing Bracket
Note:
4 x AA and 6 x LR44 batteries included, on first use please remove the battery tabs which are
provided to prevent battery leakage.

Installation

The alarm can be used freestanding for flexible use or can be fixed to a wall using the fixing
bracket. The bracket uses a ball joint to pivot the unit in any direction you require. The corner of a
room will provide the most coverage. Recommended installation height is 1 - 2m.
The PIR detection range is 5m at a 110x45 degree angle.
To mount it to a wall, select your desired location and secure the bracket to the wall with screw
and wall plug. Once secure, slide the alarm unit onto the bracket and lock in place.

Battery installation/replacement

Alarm Unit
It is recommended that the alarm is tested regularly. If the alarm sounds weak, the batteries
should be replaced.
The alarm unit requires 4 x AA batteries (supplied). On first use please remove the battery
tab which is provided to prevent battery leakage. To replace the batteries, simply remove the
battery compartment by sliding off the cover in the direction of the arrow. Replace with 4 x AA
batteries noting the correct polarity.
Remote Control
The remote control requires 3 x AG-13 cell batteries. On first use please remove the battery
tab which is provided to prevent battery leakage. Once in use, if the remote control range is
too low, it is time to replace the batteries. Remove the battery compartment by unscrewing
the cover and replace with 3 x AG-13 cell batteries noting the correct polarity.

Operation

Point the remote control in the direction of the alarm and press the ARM / DISARM button. The
alarm will sound a tone and the red indicator light on the remote control will flash once. The
alarm unit will display a green light for 30 seconds. Once the green light turns off the device is
active.
