IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be
faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• Not suitable for use in bathrooms.
PRODUCT INFORMATION
• Made from MDF with a painted finish.
• Made in China.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching or
damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
FITTINGS
889951 SOPHIE CABIN BED-CHEST
ASSEMBLY INSTRUCTIONS.
Page 1 of 6

Advertisement

loading

Summary of Contents for Next SOPHIE 889951

  • Page 1 889951 SOPHIE CABIN BED-CHEST ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 PARTS (3) Middle Divider Panel x 1 STEP ONE 1. Insert 2 x wooden dowels (C) into middle divider panel 3. 2. Attach 2 x supporting rails 7 to middle divider panel 3 with 2 x screws (H) and tighten. STEP TWO 1.
  • Page 3 STEP THREE 1. Insert 4 x cambolts (A) and 4 x wooden dowels (C) into side panel 2-L. 2. Attach side panel 2-L to the assembled unit. 3. Insert 4 x camlocks (B) into supporting rail 6, 2 x supporting rails 7 and back supporting rail 8. Ensure the arrow indicator is pointing towards the panel edge before tightening with a screwdriver.
  • Page 4 STEP SIX 1. Attach back panel 4 and back panel 5 to the assembled unit with 20 x screws (D) and tighten. STEP SEVEN 1. Attach drawer back panel 16 to drawer side panels 12 (both L&R) with 4 x screws (E) and tighten. 2.
  • Page 5 STEP NINE Insert drawers into the unit. STEP TEN Position as shown Page 5 of 6...
  • Page 6: Packaging Layout

    PACKAGING LAYOUT Page 6 of 6 Next Retail Ltd, Desford Road, Leicester, LE19 4AT...
