Summary of Contents for Atmos EasySolar
- Page 1 Atmos EasySolar User Operating Instructions Atmos EasySolar Atmos Heating Systems TBS Building Supplies Ltd Hackwood Road Daventry Northants NN11 4ES Tel: 01327 871990 Fax: 01327 871905 e-mail: sales@atmos.co.uk internet: www.atmos.co.uk Issue 1.6.13...
- Page 2 Keep it in a place where you will find it easily when you need it. The EasySolar hot water system uses sunlight to heat the water for domestic hot water use. Heating your hot water with sunlight will reduce your energy bills. You will also reduce your CO emissions and so help to save the environment.
-
Page 3: How Does It Work
2 How does it work? The EasySolar system consists of a collector (A) and an insulated storage tank (B) which contains 100 litres of water. The collector is fitted on the roof and the storage tank is fitted inside the house. -
Page 4: Yearly Maintenance
3 Use Once installed the system works automatically. The following points need to be considered: • The best time to use hot water is in the afternoon or evening when the storage tank is warmest. • Set the hot water temperature no higher than 60° on your combi boiler or hot water cylinder in order to minimise energy use. - Page 5 3. Are the wires from the collector thermostat and the 12V feed to the tank connected correctly? Yes=>6. No=>5 4. The 12V adaptor is faulty. Atmos can supply a replacement. 5. Ensure the wires are connected correctly. The wires from the collector thermostat are interchangeable.
- Page 6 4 Materials The collector and the storage tank can easily be disassembled and the components recycled. Evacuated tube collector Glass Borosilicate Collector tubes Copper Frame material Aluminium Header Aluminium & Copper Flat plate collector Collector tray Insulation Rockwool Pipe insulation EPDM Absorber Copper...
-
Page 7: Warranty
If the fault is not of original manufacturing origin then the replacement part will be chargeable. 5. Any warranty provision shall not apply if Atmos determine that the fault is due to improper application, improper use, neglect, accidental damage or injudicious treatment, non-observance of instructions contained in Atmos manuals or due to improper repair, adjustment, installation or maintenance.
