Summary of Contents for Bromic Heating SMART-HEAT CONNECT
- Page 1 BROMIC SMART-HEAT CONNECT SETUP AND USER MANUAL IMPORTANT READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL. KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE. Version 1.0 (AU & UK)
- Page 2 CONTENTS IMPORTANT NOTES & WARNINGS HOW IT WORKS TECHNICAL SPECIFICATIONS GETTING READY DEVICE SETUP USER OPERATION 9-11 TROUBLESHOOTING IMPORTANT IMPORTANT NOTES & WARNINGS This manual contains important information about the configuration, and operation of the Bromic Smart-Heat Connect. Please pay close attention to the important safety information shown throughout this instruction manual.
- Page 3 • This device is not suitable for outdoor uses. • The Smart-Heat Connect requires the use of an AC • Do not install the device directly near high humidity to DC 5V power supply (provided).
- Page 4 AU: 916 MHz; UK: 868 MHz Bluetooth Module Bluetooth 4.1 at 2.4GHz Bluetooth Range (to Smart device) max 10m Number of Heaters per Smart-Heat Connect Up to 50 Heaters Ingress Rating IP20 (Indoor use ONLY) UV Rating Not suitable for direct UV exposure Operating Temperature - 20°C to 50°C...
- Page 5 Connect, which will allow the user to operate Bromic Heater(s) using a smart device. You will need the following: - Bromic Smart-Heat Connect for your region (refer to table on page 4 for part number). - An iOS or Android smart device with Bluetooth function and access to the App Store or Google Play Store.
- Page 6 5. Enter a new name and click “OK“. click “CONNECT” to pair the device. Note: The unique 4-character code can be found on the label at the back of the Smart-Heat Connect. 7. Successful pairing is indicated once the version is automatically populated.
- Page 7 Note: Hold and swipe left to delete a listed Room or Heater. Note: Each Smart-Heat Connect can control up to 50 Heaters provided all Controllers are within 30m. Follow steps in section 1 to add additional Smart-Heat Connect if required.
- Page 8 DEVICE SETUP Section 3A - Pairing with Remote Each App Heater needs be paired with the respective Controller. To pair your App Heater with the Controller, follow the steps below: 1. Locate the P3 Button on the Remote. Note: For standard ON/OFF or Dimmer Remote, the P3 button is located inside the Remote. Open the Remote cover by inserting a small flat screwdriver into bottom recess left and right side tabs.
- Page 9 4. Enter the unique 4-character code and click “CONNECT”. The version will appear to indicate successful connection. Note: The Smart-Heat Connect can only be connected to one smart device at a time. Ensure Bluetooth is disabled on other pre-paired devices.
- Page 10 Important Note: Always verify the device status after any operation. The App does not provide feedback on the status of the Heater(s). Important Note: Ensure the Bluetooth symbol is on. This indicates communication is good between Smart-Heat Connect and the smart device. bromic.com...
- Page 11 USER OPERATION Section 2 (Optional) –Send A Scenario The Scenario feature allows multiple Bromic Heaters to be set at preferred settings with a single tap. Refer to section 4 under “DEVICE SETUP” for instructions to create Scenario(s). 1. Tap on the Scenario icon from the Home page. 2.
- Page 12 Smart-Heat Connect with no obstacles. Check if the Bluetooth symbol on the top right corner is present to indicate device connected. Connect the Smart-Heat Connect to a power supply Device out of closer to the Controller and try again. range...
