H-9996
LED WALL PACK
TOOLS NEEDED
Phillips Screwdriver
LED Wall Pack x 1
WARNING! This product may present a shock or
fire hazard if improperly installed or attached
in any way. Product should be installed in
accordance with these instructions, current
electrical codes and/or the current National
Electric Code (NEC).
CAUTION! Ensure supply voltage is the same as
the rated luminaire voltage. Do not operate in
ambient temperatures above those indicated
on the luminaire nameplate. Do not install
where operating temperatures exceed
ambient temperature range. To avoid the risk
of fire, explosion or electric shock, this product
should be installed, inspected and maintained
by a qualified electrician only in accordance
with all applicable electrical codes. Be certain
electrical power is off before and during
installation and maintenance.
PAGE 1 OF 9
1-800-295-5510
uline.com
Drill
Drill Bit
Mounting Screw x 3
PARTS
Plastic Anchor x 3
SAFETY
For supply connections, use wire rated for at least 194°F.
NOTE: Input is 120-277VAC.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired
operation.
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
Wire Nut x 3
0322 IH-9996

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-9996 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U-Line H-9996

Summary of Contents for U-Line H-9996

  • Page 1 Para Español, vea páginas 4-6. Pour le français, consulter les pages 7-9. H-9996 1-800-295-5510 uline.com LED WALL PACK TOOLS NEEDED Phillips Screwdriver Drill Drill Bit PARTS LED Wall Pack x 1 Mounting Screw x 3 Plastic Anchor x 3 Wire Nut x 3...

  • Page 2: Installation

    SAFETY CONTINUED NOTE: This equipment has been tested and WARNING! Turn off main power at circuit found to comply with the limits for a Class B breaker before installing fixture in order to digital device, pursuant to part 15 of the FCC prevent possible electric shock.

  • Page 3: Junction Box Mount

    INSTALLATION CONTINUED 5. Ensure power is off from circuit breaker or fuse. Feed 2. Drill four holes on the back plate needed to install power supply wires through conduit inlet on back junction box. Using Phillips screwdriver remove center plate. Connect the wires using wire nuts. (See Figure 3) knockout.

  • Page 4: Herramientas Necesarias

    H-9996 800-295-5510 uline.mx LÁMPARA LED DE PARED PARA EXTERIORES HERRAMIENTAS NECESARIAS Desarmador de Cruz Taladro Broca PARTES 1 Lámpara LED de 3 Tornillos de Instalación 3 Anclajes de Plástico 3 Capuchones para Pared para Exteriores Cables SEGURIDAD ¡ADVERTENCIA! Este producto puede causar Para conectarse al suministro, use cables clasificados una descarga eléctrica o riesgo de incendio...

  • Page 5: Instalación En Pared

    CONTINUACIÓN DE SEGURIDAD NOTA: Este equipo ha sido probado y cumple ¡ADVERTENCIA! Apague el interruptor de energía con los límites de un dispositivo digital de Clase principal en el cortacircuitos antes de instalar B, de acuerdo con la parte 15 de la Normativa el aparato para prevenir una posible descarga de la FCC (EUA).
  • Page 6 CONTINUACIÓN DE INSTALACIÓN 5. Verificar que el cortacircuitos o fusible esté 2. Taladre la placa posterior en los cuatro lugares desconectado. Pase el cableado a través del orificio necesarios para instalar la caja de conexiones. Use de la placa posterior. Conecte los cables usando los el desarmador de cruz para quitar el orificio central.

  • Page 7: Outils Requis

    H-9996 1-800-295-5510 uline.ca ÉCLAIRAGE À DEL MURAL OUTILS REQUIS Tournevis Perceuse Mèche de cruciforme perceuse PIÈCES Éclairage à DEL mural x 1 Vis de montage x 3 Ancrage en plastique x 3 Capuchon de connexion x 3 SÉCURITÉ AVERTISSEMENT! Cet appareil peut présenter Un fil conçu pour une température minimale de 194 °F...

  • Page 8: Fixation Murale

    SÉCURITÉ SUITE REMARQUE : Cet appareil a été testé et jugé AVERTISSEMENT! Coupez l'alimentation principale ARRÊT conforme aux limites d'appareils numériques au disjoncteur avant d'installer l'appareil afin de classe B en vertu de la section 15 de la d'éviter tout risque de choc électrique. réglementation de la FCC.
  • Page 9 INSTALLATION SUITE 5. Vérifiez que l'alimentation est coupée au niveau 2. Percez quatre trous sur la plaque arrière pour du disjoncteur ou du fusible. Faites passer les fils l'installation de la boîte de jonction. À l'aide du d'alimentation par l'entrée du conduit de la plaque tournevis cruciforme, retirez l'entrée défonçable se arrière.
