MASTER PNEUMATIC-DETROIT BFCD201 Installation And Maintenance

BFCD201 Installation and Maintenance
MASTER PNEUMATIC - DETROIT, INC.
. |
6701 -18 Mile Rd
PRODUCT NUMBERS:
BFCD201-10
BFCD201-12
NOTE:
Read Warning Stuffer STU-A019 included in box with product before proceeding.
INSTALLATION:
1. Depressurize and lockout air pressure.
2. Upstream pipes must be free of excessive dirt and liquids.
3. A conventional M/P Filter with standard 5 micron filter element should be installed immediately ahead of Coalescing Filters
to maximize the life of the coalescing element.
4. Install the Coalescent Filter as near as possible to the device it is to serve.
5. Install the Coalescent Filter so that air flows from inlet to outlet as shown on the head.
6. The Coalescent Filter must be installed vertically with drain mechanism at the bottom.
7. Coalescent Filters should be installed upstream of any Regulators or Lubricators in the airline.
OPERATION:
1. For Manual Drain models: Periodically drain to discharge accumulated liquids by turning Draincock clockwise.
2. For Automatic Drain models: Flexible tubing (3/16" ID) may be installed on the Drain Stem to remove discharges. Turn
Drain Knob counter-clockwise until it stops, push up to expose the Drain Clip. Remove Drain Clip and Drain Knob, and push
tubing onto Drain Stem. The drain may be adjusted to compensate for differing operating conditions by adjusting the Drain
Knob. For low flow or low pressure drop, turn the Drain Knob until the drain just closes. For high flows or high pressure
drop, turn the Drain Knob clockwise if reduced drain action is required. Turning the Drain Knob clockwise to the stop puts
the drain in a manual shutoff position. Turning the Drain Knob counter-clockwise will manually drain the filter.
3. Replace Coalescent Element when the pressure differential reaches 8 to 10 psid (0.55 to 0.69 bar).

TO CLEAN OR REPAIR:

1. Depressurize and lockout air pressure.
2. Remove Bowl Ring and Bowl Assembly by turning counter-clockwise.
3. Remove Lower Baffle by turning counter-clockwise.
4. The Coalescent Element can now be removed. Do NOT clean elements, they must be replaced.
5. To service Automatic Drain, turn Drain Knob counter-clockwise until it stops. Then push Drain Knob up to expose Drain Clip.
Remove Drain Clip and pull off Drain Knob.
6. Remove Drain Nut by turning counter-clockwise. The Automatic Drain can now be removed from Bowl and disassembled.
7. The Automatic Drain and Bowl can now be cleaned with soap and water.
8. When re-assembling, be sure all o-rings are correctly located. Lubricate o-rings with Lithium grease. Torque Drain Nut 5-15
in-lbs. Torque Lower Baffle 50-75 in-lbs. Torque Bowl Ring hand tight.
9. If the Coalescent Filter cannot be repaired by cleaning with soap and water, the parts should be replaced.
DESCRIPTION
AID Metal Bowl Assembly
AID Metal Ext. Bowl Assembly
Manual Metal Bowl Assembly
Manual Metal Ext. Bowl Assembly
Differential Pressure Gauge
Sterling Heights, MI 48314 | Phone: (586) 254-1000 | Fax: (586) 254-6055 | Email: mp@masterpneumatic.com
You have just purchased a quality Coalescent Filter from Master Pneumatic.
With care in its installation and maintenance, you can expect it to have a long and economical service life.
Before you go any further, please take a few minutes to look over this information,
then save it for future reference and for the useful service information it contains.
Installation & Operation Procedures

Replacement Parts

PART NUMBER
ABFD114-100
ABFD114-100H
ABF114-100
ABF114-100H
106-35
THANK YOU!
DESCRIPTION
Element Kit - 0.3µm
Ext. Bowl Element Kit - 0.3µm
Element Kit - 0.01µm
Ext. Bowl Element Kit - 0.01µm
Automatic Drain Kit
Manual Draincock
STU-5015
JAA 6-29-06
REV 08-29-08
(ECN 4460)
PART NUMBER
A114-112
A114-113
A114-112E8
A114-113E8
D380
103-51SP
