XSONIC AIRSTEP Spk Edition User Manual

AIRSTEP Spk Edition User Manual
Index
Quick Start
•
•
1. Current Channel Indicating
•
2. Toggle Effects Indicating
•
3. Charging
•
4. Upgrade Firmware Mode
•
5. USE The JIMI HENDRIX PACK Including TOGGLE THE J.H. Legendary
Wah
•
6. USE AIRSTEP Spk Edition and the Spark App At The Same Time(iOS Only)
Firmware update
•
Looper Mode
•
•
1. For Loopy HD(iOS)
•
2. For Mobius Looper(Computer)
FAQ
•
Quick Start
Step 1. Turn on the power switch of the Spark 40 amp.
When AIRSTEP Spk Edition controlling Spark amp, you can still use all the functions in
Spark App except preset editing. Connect to the Spark 40 Audio in the system Bluetooth
setting to use with Spark App's function or Bluetooth audio function.
If you don't need to edit preset before using AIRSTEP Spk Edition, click skip in the Spark
App's Startpage and go to Step 2
If you need to edit presets before using Spark amp with AIRSTEP Spk Edition, please make
sure AIRSTEP Spk edition is power off, then click connect in the Spark App's Startpage.
After editing, please make sure that the hardware connection with the Spark App has been
ejected or forgotten as in the picture shown below, then go to Step 2.
How to eject/forget your Spark from the iOS app;
1. Click the profile in the Spark app, enter hardware settings.(P1)
2. Click"Eject"(P2)
How to eject/forget your Spark from the Android app;
1. Click"
2. Click"Forget this devices"(P4)
3. Do not forget the Spark 40 Audio, click"Close"(P5)
"(P3)
