Installing the Turbo Floor Model System

Location
1.
Locate as close as possible to water supply source.
2.
Locate as close as possible to a three-prong grounding receptacle.
3.
Locate the System on a smooth and level floor.
4.
Allow sufficient space around the System for easy servicing.
5.
Provide a non-switched 110/120V, 60Hz power source for the System.
6.
Make sure the System is not moved, tilted or shaken.
7.
Do not locate the System where the environment would offer any risk of water
contamination.
8.
Do not locate the System within or directly adjacent to toilet facilities.
9.
Do not put any other liquid than water into the System.
10. Do not lay the System on its side.
11. Do not leave the System on without water supply line running.
12. Do not use an extension cord. The outlet must be within reach of the power cord.
13. Make sure The System has a 2" clearance on all sides to insure ventilation
14. Make sure to install the auto shut-off valve to control and reduce the cold water supply line
pressure to keep at 25 psi to avoid busting.
15. Hot tank must be filled with water before the System is plugged into a three-prong ground
type receptacle.
All equipment needs to be plumbed into the water system by a licensed plumber.
©
Copyright
2008 filterwater.com
FilterWater.com
800-439-0263
http://www.FilterWater.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Turbo Floor and is the answer not in the manual?

Questions and answers

Summary of Contents for FilterWater Turbo Floor

  • Page 1 FilterWater.com 800-439-0263 Installing the Turbo Floor Model System Location Locate as close as possible to water supply source. Locate as close as possible to a three-prong grounding receptacle. Locate the System on a smooth and level floor. Allow sufficient space around the System for easy servicing.
  • Page 2 20 amps or less. Turn on the hot and cold tank switches. 10. Do not use the first three reservoirs of water; these are meant to flush the System. 11. Recheck the System for water leaks. © Copyright 2008 filterwater.com http://www.FilterWater.com...
  • Page 3 FilterWater.com 800-439-0263 © Copyright 2008 filterwater.com http://www.FilterWater.com...
  • Page 4 Make sure to install the System on cold potable water supply. Install a pressure regulator, such as a slow flow regulator on the tubing in front of unit’s water inlet to regulate the water pressure could exceed 60 P.S.I.G. © Copyright 2008 filterwater.com http://www.FilterWater.com...
  • Page 5 B. Hold valve saddle against tubing in a position directly opposite back plate. C. Tighten screw enough so valve saddle and back plate are held securely against tube. D. Tighten screw firmly. Do not crush tube. © Copyright 2008 filterwater.com http://www.FilterWater.com...
  • Page 6 If contamination still exists, flush the reservoir and use chlorine test kit again. • Clean the outside of the cabinet and the drip tray using a mild cleaning agent. • Reconnect the power supply to the cooler. • © Copyright 2008 filterwater.com http://www.FilterWater.com...
