CMS Velocity Series Hardware Installation Manual

Removable backup system
Hide thumbs

Advertisement

Quick Links

Download this manual
Removable Backup System
Hardware Installation Guide
Changing Your Computer's Setup Configuration ........................... 7-9
CMS Support .................................................................................11

Advertisement

loading
Need help?

Need help?

Do you have a question about the Velocity Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CMS Velocity Series

  • Page 1: Table Of Contents

    Installing the Velocity Series Removable Backup System ..2-3 Connecting the Velocity Series Removable Backup System ..4-5 Setting Up the Velocity Series Removable Backup System ... 6 Changing Your Computer’s Setup Configuration ......7-9 Removing the Velocity Series Removable Drive ......10...

  • Page 2: Installing The Velocity Series Removable Backup System

    Installing the Velocity Series Removable Backup System Your new CMS Velocity Series Removable Backup System comes fully assembled. A 4-pin power connector and Serial ATA cable are included for the connection of the Removable Serial ATA hard drive into your computer. The...
  • Page 3 Installing the Velocity Series Continued... Mounting the Removable Backup System with screws: If the selected drive bay will require screws to mount the Removable Backup System, you will find four screw holes, two on each side of the unused bay.

  • Page 4: Connecting The Velocity Series Removable Backup System

    Removable Backup System’s Serial ATA connector to your Serial ATA PCI Controller Card. Before you close your computer, please make sure you have completed all the necessary steps for installing the Velocity Series Removable Backup System. Use the provided check list.
  • Page 5 Locate an unused 5.25” drive bay and remove it’s face plate. Mount the Velocity Series Removable Backup System into the selected unused drive bay and secure it into place using either the screws or guide rails as detailed in the instructions.

  • Page 6: Setting Up The Velocity Series Removable Backup System

    To verify that the Velocity Series has been installed properly, follow these steps: • Click Start and then My Computer. The Velocity Series Serial ATA hard drive should now be listed in your device list. If so, you can now begin the installation of the BounceBack Professional Software (see Installing the BounceBack Professional Software).

  • Page 7: Changing Your Computer's Setup Configuration

    Changing Your Computer’s Setup If the Velocity Series is not recognized by your computer (in the “My Computer” folder) in the device list you will need to enter your computer’s setup. The following steps will guide you through this process.
  • Page 8 Changing Your Computer’s Setup Continued... Check to see what your current configuration is below (A, B or C). In this example our computer is configured like Configuration A below, where Yes means enabled or in use and No means not in use or unknown device. Configuration A Configuration B Configuration C...
  • Page 9 Changing Your Computer’s Setup Continued... Select Drive Type and then press the Enter key . Use the + or – key to scroll through the options. Make sure the Drive Type is set to AUTO as in the example. Use the Esc key to exit and save your new settings.

  • Page 10: Removing The Velocity Series Removable Drive

    Removing the Velocity Series Removable Drive The Velocity Series Removable hard drive can be ejected from Figure 8: Ejected Velocity Removable the front of the computer. Hard Drive Always turn off your computer before ejecting the drive. Pull the handle on the Velocity Series outward and...

  • Page 11: Cms Support

    • Contact CMS Customer Service at (714) 424-5520 or e-mail cs@cmsproducts.com for warranty issues. • Contact Technical Support (714) 424-5520 or e-mail support@cmsproducts.com for assistance with the installation of your Velocity Series Backup System or help with a technical problem.
