- Page 1 Dishwasher User Manual DISHWASHER USER MANUAL NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM...
- Page 2 Dishwasher User Manual The brief introduction of TT-K122 Dishwasher’s structure and installation. Note: This installation and the operation must be operated by the professional person. Please read the instruction before installation and operation. Model and name Model：TT-K122 Name：Dishwasher Specialty The machine use rotate washing arm and make sure the best washing purpose. In electricity, it has electro CMOS clip control system and newly operation panel.
- Page 3 Dishwasher User Manual Installation and adjustment Check-up: Whether the connection is firm. Adjustment: Adjust the four feet of the product. Use the level machine adjusts the product from horizontal and vertical direction, and put the product at a steady situation. (The height doesn’t above 2500m) The wire connection: AC380V, 50Hz, 40A electric protector switch.
-
Page 4: Enter Key
Dishwasher User Manual Key function table Key name Current condition Finish function Connect the electric Turn on the machine, show the current mode, add water automatically Trouble condition Turn off ON/OFF key (4) Turn on the machine Turn off all the equipment, show the current temperature Connect the electric Turn off the machine, useless... - Page 5 Dishwasher User Manual During waiting time, press the mode key to choose washing mode. The mode can be memorized automatically. Press the set key chooses the distributor mode. If you don’t choose, it will continue according to the primary mode. (Note: refer to the distributor setting mode) After washing, it will rinse automatically.
-
Page 6: Troubleshooting
Dishwasher User Manual J. Trouble-shooting When there have something with wrong, the left window will show ‘一一’，right window show the code “XX”. After dealing with the troubles connect the electricity. Note: The vat will heat when the water reach the setting situation. Suggest start after the temperature is satisfied. -
Page 7: Installation
Dishwasher User Manual Be carefully when open the cover. Don’t add any dose into the water to prevent blast. Sanitation Don’t wash the machine shell during the using time. Storage and installation area If the storage or installation temperature is below 0℃, please eject the sewage after washing. If the water is frozen in the machine, the spare parts will be damaged, such as water pump, valve and heater. - Page 8 Dishwasher User Manual Stop working after open the door. Continue working after close the door. (5) Water situation switch The switch is closed when the water reach the setting situation. (6) The control of the temperature The temperature control automatically when press the on/off key. When the water reaches the setting situation, it starts heating.
- Page 9 Dishwasher User Manual Every key has an indicator. After choosing the key, the water will be heated and added to the washing vat. The preparation time of the washing is decided on the water temperature and the heating ability of the rinse heater.
- Page 10 Dishwasher User Manual The washing effect is connected to the cleaner. Please Check the requirements during using. Adding the cleaner automatically If the machine has cleaner distributor, the distributor will add proper cleaner automatically according to the water capacity and water’s dirty. Adding the cleaner manual If the machine doesn’t have cleaner distributor, add 36g cleaner in the water, then add 24g in every five-water circle.
- Page 11 Dishwasher User Manual Don’t put the knives and chopsticks together. The handle must insert below. Don’t pile the dishes. Put the wash basket on the bracket Close the cover Choose the washing circle time Press th enter key The washing and rinsing circle are working automatically. The indicator shows the working condition.
- Page 12 Dishwasher User Manual G. Turn off the machine Press the “4” key, and open the overflow stick. H. Distributor setting (1) During the waiting condition, press mode set key (heavy washing/set key) over 3 seconds, the left nixie tube show distributor “ux(x=1,2,3)” mode, the right nixie show the distributor time mode, the setting range: “00~40 seconds”...
- Page 13 Dishwasher User Manual switch and the water situation switch are closed. All the operation must be operate at indicator light condition. (3) Press the enter key, the machine start the setting washing mode. (They can washing if it doesn’t reach the setting temperature, suggest start working when it reaches the setting temperature).
- Page 14 Dishwasher User Manual The water pump isn’t rotate, and the machine isn’t work. The fuse is broken. Check the fuse, and if there is something wrong change the fuse. The rinse spout can’t sprinkle water. The waterpower isn’t open, and open the waterpower The spout or valve is block.
- Page 15 Dishwasher User Manual NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM...
