- Page 1 TCB(L) SERIES VER 101 CRANE SCALE OPERATIONAL MANUAL - 1 -...
- Page 2 (4) To improve the product performance, functions can be changed with no notice. (5) Please understand that TMT does not have responsibility for a demand related to loss, lost profit etc. caused by operating the product, regardless of the third clause.
-
Page 3: Table Of Contents
INDEX 1. Precautions .....................4 2. Main Features ....................4 3. Specifications ....................5 4. Description of Panels and Symbols ..........7 5. Rechargeable Battery ................8 6. General Functions for Weighing Mode .........9 7. Setting Mode ..................... 10 8. Test Mode ....................15 9. IR Remote Controller ................ -
Page 4: Precautions
1. Precautions ◆ Do not put too much pressure to keys. Light touching is enough to operate products. ◆ Do not use inflammable substances for cleaning. ◆ Do not use the product in the rain. Keep it dry. ◆ Avoid sudden changes of temperature if possible ◆... -
Page 5: Specifications
3. Specifications ◆ Overall view ◆ Dimensions DIMMENSION (UNIT: mm) e=d= Weight MODEL (kg) (kg) (kg) TCB-1T(L) 1,000 TCB-3T(L) 3,000 15.2 TCB-5T(L) 5,000 16.7 TCB-10T(L) 10,000 26.9 - 5 -... - Page 6 ◆ Specifications MODEL TCB (FND TYPE) TCB-L (LCD TYPE) Display 5 digit FND 30.4mm 6 digit FSTN LCD 30mm Operating time Approx. 150hr Approx. 300hr Battery 7.4V 3.7V Power adaptor Display lamp Low battery, Zero, Tare, Hold, Stable ON/OFF, Zero, Tare, HOLD, * Function -20℃~60℃...
-
Page 7: Description Of Panels And Symbols
4. Description of Panels and Symbols LCD Type FND Type ◆ Display 888888 Display the weight data & message Indicates when the weight is stable Indicates when the weight is zero Indicates when the tare is included Indicates when the hold function is set Indicates when a battery has to be recharged (B type) Indicates when the ZigBee communicates data (L type) ◆... -
Page 8: Rechargeable Battery
5. Rechargeable Battery (1) Method of recharge battery ■ Check the power supply voltage. ■ If adaptor is still being charged, the RED lamp is on as below picture. ■ If a charging is completed, the RED lamp is off. The battery charging time takes about 6 hr. -
Page 9: General Functions For Weighing Mode
6. General Functions (1) Zero function Use to correct drifted zero value when the scale is unloaded, and motion is not detected. This function works when ZERO KEY is pressed, and the ZERO LAMP is on. (2) Setting tare weight function. Press the TARE KEY. -
Page 10: Setting Mode
7. Setting Mode (1) How to enter this mode Press the ON/OFF KEY while pressing the TARE KEY. Changed values are saved after run to the final menu. (2) Keyboard : Used to set up an initial zero value (0). : Used to move the input value to the left or right by one place. - Page 11 ■ F04 : Automatic Zero Condition (00~99) Setting Menu Description F04-00 No compensation F04-23 Compensation for gradual change below 1d for 3 sec. F04-99 Compensation for gradual change below 4.5d for 9 sec. ■ F05 : Adjustment the hold speed (1~9) Setting Menu Description F05-1...
- Page 12 ■ F09 : Item number (Identification number of each Item) (0~9) Setting Menu Description F09-0 Item No.0 F09-5 Item No.5 F09-9 Item No.9 ■ F10 : Weighing data send format (0~5) Setting Menu Description F10-0 Not used F10-1 Not used F10-2 Send the print format by automatically at stable F10-3...
- Page 13 ④ Format (18byte) Start Code Blank Lamp Status Weighing data Unit Stop code 1 byte 7 byte ※ Start code : ST (Stable) / US (Unstable) ※ Lamp status byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Three decimal decimal decimal Stable...
- Page 14 ■ F13 : Initialization of number measured daily (weigh No.) (0,1) Setting Menu Description F13-0 Maintain current number F13-1 Initialization (starting from No.1) Maximum of weighing number is 999, and if it exceeds the number is initialized to 1. ■ F14 : Stream wireless mode (0~3) Setting Menu Description F14-0...
-
Page 15: Test Mode
8. Test Mode (1) How to enter this mode Press the ON/OFF KEY while pressing the ZERO KEY. (2) Menu ■ TEST 1 : Display test Display Description TEST 1 runs automatically and a display is on. If press ENTER KEY, move into next menu. ■... - Page 16 ■ TEST 4 : Back light test (LCD Type) Display Description If you press the ZERO KEY once, back light LIGHT turns on and once again, back light is turns OFF. If press ENTER KEY, move into weighing mode. - 16 -...
-
Page 17: Ir Remote Controller
9. IR Remote Controller ■ OFF : Use to power off the scale (Power-ON is available only on scale.) ■ ZERO : Same as Scale keyboard ■ TARE : Same as scale keyboard ■ HOLD : Same as scale keyboard ■... -
Page 18: Zigbee Wireless (Option 1)
10. ZigBee Wireless (Option 1) The OP-01 is communicates with our wireless display and controller. If you are using a wireless dongle, you can communicate with PC and printer. RF frequency range 2400 ~ 2483.5 MHz Output power Max. 4dBm Channel width 2 MHz Frequency offset... -
Page 19: Real Time Clock (Option 1)
12. Real Time Clock (Option 1) (1) How to enter this mode Press the ON/OFF KEY while pressing the ZERO KEY. (2) Keyboard : Used to move the input value to the left or right by one place. : Used to increase the setting constant one by one. : Used to save the value and to move next menu. -
Page 20: Check Message
13. Check Message Data in an internal storage value are erased owing to any electronic impact. Please contact us to resolve this technical problem. Something wrong in a Load cell connection or in an A/D conversion. Please contact us to resolve this technical problem. When a thing is over-weighed within the maximum weight value, the error message is displayed. - Page 21 MEMO - 21 -...
