- Page 1 USER MANUAL eBS-5030A www.esslsecurity.com...
-
Page 2: Important Safeguards And Warnings
Important Safe guards and Warnings Safety Precautions Before using the Machine, operators must be trained with radiation protection knowledge according to local laws and regulations, and have basic skills in using the Machine. Before the Machine is supplied with power, make sure that the power supply voltage ... -
Page 3: Safety Instructions
Overview The Machine inspects the baggage and items by using X-ray’s penetrability without opening them. It adopts digital image processing and computer image display technologies, and has a built-in semiconductor detector. These attributes come together to make an efficient, reliable and high- quality image processing system. This manual introduces the base functions of the Machine and provides guidance on operating and maintaining the Machine. -
Page 4: Power-On And Startup
Structure The Machine consists of an inspection tunnel and a tray. The figure is for reference only. Slight differences might be found between the model and the actual product. Figure 3-1 Model Table 3-1 Structure No. Description The inspection tunnel. Items on the conveyor belt that are in the tunnel are scanned and then images are generated. - Page 5 Make sure that it is functioning normally at 220 V and the power source is properly grounded. Check the emergency stop button. The button is not pressed down by default. If it is pressed, rotate the button clockwise to return theoriginalstate.
-
Page 6: Working Status
Normally the calibration lasts 3 to 5 seconds. Step 2 Click to run the roller. Step 3 Place items at the entrance of the tunnel, and scanned images will be displayed on the system interface as they pass through the tunnel. Step 4 Turn off the software system. - Page 7 Table 5- 1 Area Description Device information area Device operating area Image processing functions area 5.2 Device Information Area Figure 5- 2 Device information : Displays the connection status of the detection card. The icon is highlighted when the connection is normal. : The icon is highlighted when IR is covering an item.
- Page 8 5.2.4 Navigating Images Click to view previous and next images. 5.2.5 Image Zooming Out/In Click to zoom in and out of (maximum x8) images. 5.2.6 Image Processing Function Shortcut Keys Combine image processing functions through buttons 5.3 Image Processing Functions Area In the image processing functions area, you can view and edit currently displayed images.
- Page 9 with an effect similar to the negative film. The function displays objects with high absorption rate in bright colors and objects with low absorption rate in dark colors without changing the current color tone. Brightness Adjustment: Increase or reduce image brightness. The grade in the ...
-
Page 10: System Menu Settings
5.4 System Menu Settings 5.4.1 System Menu Function Click to view the system menu interface, which includes user management, parameter settings, curve, image browsing, function key settings, and system information. 5.4.2 User Management : Click Account and the prompt box for the user management is displayed. Operator: Operators have permissions to modify parameters including roller energy-saving ... - Page 11 5.4.3 Image Browsing : Browse, search, and copy previously scanned images. : The folder name format is YYMMDD and the file name format is hhmmss. You can copy the whole folder or a single file. : Search forpreviouslyscanned images by date. ...
- Page 12 6. Routine maintenance work In order to ensure the long-term stable operation of the equipment, the operator should pay attention to the regular inspection and daily maintenance of the equipment. During the equipment maintenance process, it can only be carried out after the power is cut off. The basic contents of daily maintenance work are as follows: 1.
