Compact 18Gbps HDMI 2.0 over HDBT Transmitter 1. Product Introduction This product is an HDMI 2.0 HDBT extender transmitter. Supports HDMI 2.0b, 4K@60 4:4:4, HDR, HDCP 2.2 It extends 1080p/4K HDMI signal over CAT6a cable up to 70m/40m(PoC) and enables IR and RS232 pass-through to control source or display device remotely. -
Page 6: Packing List
Compact 18Gbps HDMI 2.0 over HDBT Transmitter 1.2 Packing List 1x EXT-H101L2-TX-HDBT ⚫ 2x Mounting Ears with 2x Screws ⚫ 1x DC power adapter with EU plug (24v1.25A) ⚫ 4x Plastic Cushions ⚫ 1x 3-Pin terminal block ⚫ 1x User Manual ⚫... -
Page 7: Specification
Compact 18Gbps HDMI 2.0 over HDBT Transmitter 2. Specification Model Transmitter Spec Input HDMI IN Output HDBT OUT Control Ports IR IN, IR OUT, RS232 General Transmission Mode & HDBaseT: 1080p ≦ 70m; 4Kx2K ≦ 40m Distance Resolution Up to 4K×2K@60Hz 4:4:4 Bandwidth 18Gbps HDMI Standard... -
Page 8: Panel Description
Compact 18Gbps HDMI 2.0 over HDBT Transmitter 3. Panel Description ① Power LED: 1x Green LED. The LED illuminates green when it is powered on and light off when power off. ② MODE Switcher: ⚫ CTRL: RS232 pass-through control mode. UPDATE A: Update Valens IC program, connect a PC to the RS232 port, and ⚫... -
Page 9: System Connection
Compact 18Gbps HDMI 2.0 over HDBT Transmitter 4. System Connection The following diagram illustrates input and output connections that can be utilized with the HDBT 2.0 Transmitter and Receiver (EXT-H101L2-TX-HDBT and EXT-H101L2-RX- HDBT):... -
Page 10: Panel Drawing
Compact 18Gbps HDMI 2.0 over HDBT Transmitter 5. Panel Drawing...
