Summary of Contents for BE Ag & Industrial BE-P2BFK
- Page 1 FIXED MOULD BOARD PLOUGH BE-P2BFK OPERATIONS & PARTS MANUAL FOR MODELS: • BE-P2BFK PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TECHNICAL DATA Introduction USAGE INSTRUCTIONS Before Use Attaching Plough to the tractor Note TRACTOR PREPARATION Instructions for Tractor Preparation Adjustments Warning for the Driver Danger Draft of the M.B. Plough Adjustments for Deeper Ploughing MAINTENANCE Maintenance Instructions Storage of Machine after Work Instruction for Driver EXPLODED VIEW &... - Page 3 (The BE AG & INDUSTRIAL Factory may inspect equipment or parts before warranty claims are honored.) 5. All costs incurred by the dealer for traveling to or transporting the equipment for warranty inspection and claims will be borne by the customer. BE-P2BFK USER MANUAL...
-
Page 4: Technical Data
Readjust the plough alignments if need be. The first bar point will pick up a lot or a little soil depending on how far or near the rear wheel is to the furrow respectively BE-P2BFK USER MANUAL... -
Page 5: Tractor Preparation
2. Reducing or increasing, as per the soil, the tilt angle. A correctly tilted plough tends to penetrate better. 3. If the ground is covered with trash, set the plough in almost vertical position and add weight to the plough. In such soils notched plough gives better results. BE-P2BFK USER MANUAL... -
Page 6: Maintenance
1. When M.B. plough is ready to use don’t stand between M.B. plough & the tractor. 2. Properly fit the three point linkage as mentioned above & lock with the lynch pin. 3. Never turn or reverse the tractor when the plough is engaged in the soil. BE-P2BFK USER MANUAL... -
Page 7: Exploded View & Part Lists
EXPLODED VIEW & PART LISTS Fixed Mould Board Plough (USA Type) 2 Bottom 1.14 1.13 1.12 2.12 BE-P2BFK USER MANUAL... - Page 8 10270005 NYLOCK NUT M16X2MM 10280005 HEX HEAD BOLT M16X90X2MM (8.8 GRADE) 10260393 CONNECTING ROD Ø25X425 L 71600015 NYLOCK NUT M18X2.5MM 10280020 SPRING WASHER 18 MM 10270006 HEX HEAD BOLT 16X65X2MM (8.8 GRADE) 10260378 HITCH PIN 20MM 10020013 BE-P2BFK USER MANUAL...
- Page 9 COLTER FLAT R.H.S (ROUND TYPE) 79490015 COLTER HOLDING THREADED BUSH 79490017 HEX HEAD BOLT M10X25X1.5MM (8.8 GRADE) 10260361 HEX HEAD BOLT M18X160X2.5MM (8.8 GRADE) 10260402 SPRING WASHER 18 MM 10270006 NYLOCK NUT M18X2.5MM 10280020 R PIN 3/8 10020076 BE-P2BFK USER MANUAL...
- Page 10 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-P2BFK USER MANUAL...
