Mitchell Amino 540 Quick Manual

Advertisement

Programming Remote
Amino 540 and 140
Note: These instructions are to be used if you have the remote and the box like the pictures above.
1. Power on your TV
2. Press TV once; it will blink once.
3. Press and hold SETUP until the TV button blinks twice.
4. Type 9 9 1 then the TV button will blink twice.
5. Make sure you aim the remote control at the TV and press POWER once.
6. Press and release the CH+ key continuously until the TV powers off.
7. Press POWER to turn on the TV, then press SETUP once to lock in the code.
The LED will blink twice to indicate the code is saved.
a. NOTE: If the TV does not turn on during step 6, slowly press and release
CH- to go back through the codes, then press SETUP when the TV turns
on.
8. Press STB
9. Press and hold SETUP until the STB button flashes twice
10. Press 9 9 5
11. Press Power
12. Press TV button
13. Press SETUP until TV flashes twice
14.
Important
you press the STB button to go back into that mode

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Amino 540 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitchell Amino 540

  • Page 1 Programming Remote Amino 540 and 140 Note: These instructions are to be used if you have the remote and the box like the pictures above. 1. Power on your TV 2. Press TV once; it will blink once. 3. Press and hold SETUP until the TV button blinks twice.
  • Page 2 Programming Remote Amino Kamai Note: These instructions are to be used if you have the remote and the box like the pictures above. 1. Power on your TV 2. On the remote control like in the picture, press STB then press and hold 7 plus the SETUP button until the STB light blinks twice.
