Mania MEGAHORN Instruction Manual

INSTRUCTION MANUAL
MEGAHORN AIR HORN
PACKAGE CONTENTS
•
Air horn with mounts
•
Air compressor
•
Air hose
•
Bag of fixings
TECHNICAL SPECIFICATIONS
•
Power supply: 12 V car battery (not
included)
•
Working voltage: 12 V
•
Working current: 20 A
•
Maximum volume: 150 dB
•
Size: 9 × 10 × 44.5 cm
COMPONENTS
(1) Horn
(2) Horn mounts
(3) Air input nozzle
(4) Air hose
(5) Air compressor wire connectors
(6) Air compressor
(7) Air compressor output nozzle
(8) Air compressor mount
(9) Horn mounting pads
(10) Air compressor mounting bolt and nut
(11) Horn mounting bolts and nuts
BEFORE INSTALLATION
•
Installing the Megahorn requires a few
extra components, which can be bought in
any automotive store.
•
Required materials: Megahorn and all its
components (included), 2.05 mm wire (12
AWG) that can handle a 20 A current, 20–
40 A inline fuse, 20 A switch/button. You
will also be required to drill a few holes to
fix the horn to your vehicle. The wires,
switches and fuses are not supplied in the
package.
•
Our recommendation is that you find an
auto electrician to install the Megahorn for
you.
•
Make sure your vehicle is powered off.
•
Decide where to put the horn and the air
compressor (make sure there is enough
space, and that the components are not in
direct contact with a source of heat).
•
The air compressor should be installed
vertically.
•
Read the whole instruction manual before
you begin!
HOW TO INSTALL
•
Screw the air compressor and the horn in
place where you want to install it and make
sure that the wires that will be connected
to the compressor are as short as possible,
and that the tube that will be connecting
