ADJUST-A-WINGS HELLION DE Setup Instructions

HELLION
SETUP INSTRUCTIONS (Onboard Ballast)
Unpack and check that you have all the below listed items with your Hellion
• Hellion DE Ballast, Hanging Bracket & Power Input Cable
®
• 2 x Adjust-A-Wings Reflector Sheets
• Hellion DE Lamp
®
• Hellion DE Lamp Adaptor
®
• Hellion Reflector Connector
®
STEP 1 Connect Wings
Connect Wings by aligning
button rivets with keyhole slots.
Slide to lock in place.
STEP 4 Form Wing Shape
While holding the opposite end of the
Adjustment Wire (end with 2 stoppers)
carefuly flex the wings into shape and lock the
End stopper into the single keyhole provided.
Repeat steps 3 & 4 at the other end.
®
DE ILLUMINATION KIT
STEP 2 Attach DE Adaptor
Place the DE Lamp Adaptor
against the under side of the Wings
and attach using the thumb screws
and hanging brackets provided.
Combo.
®
• Hellion DE Super-Spreader
®
• 1 x IEC Extension Cable
• 2 x Reflector Hanging Brackets
• 6 x Knurled Thumb Screws
• 2 x Reflector Adjustment Wires
STEP 3
Select one Adjustment Wire and thread
end portion (end with single stopper)
through first keyhole, then thread
it back through one of the other
keyholes as shown.
This action locates the wire and presets
the reflectors width.
You have now completed
and your Adjust-A-Wings
Hellion
To adjust Reflector Width,
choose a different keyhole
Insert Wire
the "Reflector Setup"
DE should now
®
look like this.
position in Step 4.
Note: Adjust one
wire at a time.
