Medax 12801 Instruction Manual

Specimen Stage-Stretching Table

Heating and Drying Table

1
12801, 13801, 14801, 15801, 17801, 12501, 13501, 14501, 15501 und 12895
1. Connect the power cable.
2. Power-switch "1" on. The control-lamp lights up.
3. Temperature-setting will be done by pressing SET – button and simultaneous pressing UP
or DOWN – button. Stop pressing the UP or DOWN - button, when you read the desired
temperature in the display.
4. The buttons UP or DOWN should always release before you stop the SET - button. The
desired temperature can be read in the display while the SET - button will be pressed.
5. If you stop pressing the SET - button the measured temperature of the warming-plate will
be displayed.
The predialed temperature will be stored, even while the equipment is turned off.
6. Turn off only by using Power-switch "1".
This equipment should not used in explosion-endangered areas.
MEDAX GmbH & Co. KG
Kieler Str. 211, D-24768 Rendsburg, Germany
Tel.: +49-(0)4331-136-870, Fax: +49-(0)4331-136-838
e-mail: info@MEDAX-Kiel.de
www.MEDAX-Kiel.de
Subject to technical change, Dec. 05
