Condensate pump for A/C
MRC19 19" wall-mounted case
Operation manual
ACMW-PC-12B
ACMW-PC-36B
Thank you for choosing MW POWER product. Please read this instruction before
using product and keep this manual for future reference.
www.mwpower.pl
21.10.2020
1
ACMW-PC-manual_EN-R1
Advertisement
Summary of Contents for MW POWER ACMW-PC-12B
- Page 1 Condensate pump for A/C MRC19 19” wall-mounted case Operation manual ACMW-PC-12B ACMW-PC-36B Thank you for choosing MW POWER product. Please read this instruction before using product and keep this manual for future reference. www.mwpower.pl 21.10.2020 ACMW-PC-manual_EN-R1...
- Page 2 Condensate pump for A/C MRC19 19” wall-mounted case 1. Important notes - Before caryying out any operation on the pump, make sure that the air conditioner is switch off from the power supply. - The pump has been evaluated for use with water only - Risk of electric shock.
- Page 3 Condensate pump for A/C MRC19 19” wall-mounted case 3. Dimension drawing 4. Technical parameters ACMW-PC-12B ACMW-PC-36B Zasilanie 100-230VAc 50/60Hz Zasięg pionowy (max) Pojemność zbiorniczka 35ml Pobór mocy Temp pracy C … +50 Wydajność Max 18l/h Max. 36l/h Głośność 19dB (1m) 21dB (1m) 5.
- Page 4 Condensate pump for A/C MRC19 19” wall-mounted case 6. Preventing siphoning advice 1 – false ceiling, 2 – end of discharge tube, 3 – Water level in drain tray, 4 – Air break, 5 – top of breather tube Cut discharge tube above water level of evaporator tray and direct end into large pipe, allowing air breaks (as shown on picture above).
- Page 5 Condensate pump for A/C MRC19 19” wall-mounted case 7. Installation procedure a. Ensure float is positioned in tank with magnet part uppermost, the filter is in correct place and the lid is clipper firmly onto tank base. b. Secure tank horizontally using velcro strips for the inline reservoiruse the inlet hose to connect firmly to drainage pipe c.
- Page 6 Condensate pump for A/C MRC19 19” wall-mounted case d. Instal; pump drive unit above the ceiling where possible. e. Anti-vibration assembly. f. Note direction of water flow g. Push the 9mm/6,, tube onto the tank and the pump. Secure with cable-ties.
- Page 7 Condensate pump for A/C MRC19 19” wall-mounted case h. Connect 9mm/6mm vinyl discharge tube to the outlet barb on the pump and secure with a cable tie. Channel discharge tube to an appropriate drain. Avoiding restrictions. i. Power supply wiring, in order to avoid leakage of condensate pump, please connect the signal line and the „Normally close”...
- Page 8 Condensate pump for A/C MRC19 19” wall-mounted case If the air conditioner hasn’t got an internal liquid level switch, it can also be connected to the pump together with a contactron, as shown on a schema below. j. Test ump operation by pouring water into evaporator tray. Check for leaks.
- Page 9 In no case can labour costs and any consequential damage be cited as a basis for a complaint. Any returned units must be complete. MW POWER is unable to accept any liability in case of nonconfirming installation or noncompliance with the specifications or maintenance recommendations.
